SERVICE MANUAL
MODEL NAME
KDF-55XS955
KDF-60XS955
9-965-974-05
All manuals and user guides at all-guides.com
REMOTE COMMANDER
RM-Y915
RM-Y915
KDF-55XS955
LA-3
DESTINATION
US/CND
US/CND
LCD PROJECTION TELEVISION
Self Diagnosis
Supported model
CHASSIS
RM-Y915

Advertisement

Table of Contents
loading

Related Manuals for Sony KDF-55XS955

Summary of Contents for Sony KDF-55XS955

  • Page 1 All manuals and user guides at all-guides.com Self Diagnosis Supported model LA-3 SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION KDF-55XS955 RM-Y915 US/CND KDF-60XS955 RM-Y915 US/CND KDF-55XS955 RM-Y915 LCD PROJECTION TELEVISION 9-965-974-05...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 TABLE OF CONTENTS SECTION TITLE PAGE SECTION TITLE PAGE Specifi cations ................. 4 SECTION 3: DIAGRAMS..............33 Warnings and Cautions ..............6 3-1. Circuit Boards Location ............33 Safety Check-Out ................7 3-2.

  • Page 3: Specifications

    Inc. and are licensed by BBE Sound, Inc. under U.S. CineMotion, Memory Stick, Memory Stick Duo, Patent No. 4,638,258 and 4,482,866. Memory Stick PRO, Memory Stick PRO Duo, MagicGate, MID and Twin View are trademarks of Sony Manufactured under license from Corporation. Dolby Laboratories Licensing Corporation.
  • Page 4 ANSI/SCTE 07 2000 QAM on cable Channel coverage Terrestrial 2-69/ Cable TV: 1-125 (analog) Terrestrial: 2-69/ Cable TV: 1-135 (digital) Screen Size (measured diagonally) 55 inches (KDF-55XS955 Only) 60 inches (KDF-60XS955 Only) Antenna 75-ohm external antenna terminal for VHF/UHF Projection System...

  • Page 5: Warnings And Cautions

    Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance est critique pour la securite du fonctionnement sont identifi...

  • Page 6: Safety Check-Out

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 SAFETY CHECK-OUT The AC leakage from any exposed metal part to earth ground and After correcting the original service problem, perform the following from all exposed metal parts to any exposed metal part having a safety checks before releasing the set to the customer: return to chassis, must not exceed 0.5 mA (500 microamperes).

  • Page 7: Self-Diagnostic Function

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 Self Diagnosis SELF-DIAGNOSTIC FUNCTION Supported model The units in this manual contain a self-diagnostic function. If an error occurs, the POWER/STANDBY or LAMP LED will automatically begin to fl ash. The number of times the LED fl ashes translates to a probable source of the problem. A defi nition of the POWER/STANDBY or LAMP LED fl ash indicators is listed in the instruction manual for the user’s knowledge and reference.
  • Page 8 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 Display of POWER/STANDBY or LAMP LED Flash Count For KDF-XS955 series Screen POWER/STANDBY POWER STD/DUO LAMP TIMER Projection lamp Indicators under the panel - Oneflash is not usedfor self-diagnosis . - Example...
  • Page 9 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 Clearing the Result Display To clear the result display to “0”, press the buttons on the Remote Commander sequentially when the diagnostic screen is displayed, as shown below: 1. If the screen is already displayed, proceed to step 3. If not, Power off (Set to Standby model).
  • Page 10 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 Self-Diagnosis Block Diagram G2 board IC6902 H3(WE)/H4(WF/XS) Display Engine u-com board CN6000 4:Fan IC41 Fan1 FAN PROT FAN1-PRT Temp 4:Temp IIC-E Fan2 sensor FAN2-PRT Fan3 FAN3-PRT Fan4 FAN4-PRT T board CN6022 S8001...
  • Page 11 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 Reading Lamp and Panel time Use the following to determine the lamp and panel time of a set. Screen Display Method In standby mode, press the buttons on the Remote Commander sequentially, in rapid succession, as shown below: 1.

  • Page 12: Section 1: Disassembly

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 SECTION 1: DISASSEMBLY 1-1. REAR COVER REMOVAL Rear cover Eleven screws (+BVTP 4x16) 1-2. CENTER PILLAR REMOVAL 4 Gently lift the Center Pillar up then out from the bottom bracket. Three screws from the top of the center pillar...

  • Page 13: Chassis Assembly And Fan Removal

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 1-3. CHASSIS ASSEMBLY AND FAN REMOVAL Disconnect one connector and one ground wire Four screws Chassis assembly (Washer Head +P 4x16) Four screws (+BVTP 3X12) One screw (+PWH 4x16) 1-4. SERVICE POSITION...

  • Page 14: Power Supply Block Removal (Lamp Drive Unit)

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 1-5. POWER SUPPLY BLOCK REMOVAL (LAMP DRIVE UNIT) CAUTION: When removing the Power Supply Block be careful not to move the Optical Unit Block Unhook the antenna cable Pull forward to remove...

  • Page 15: U Board, H4 Board, And Fan Removal

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 1-7. U BOARD, H4 BOARD, AND FAN REMOVAL U board Gently pull back on tab to release U board One screw (+BVTP 3X12) Four screws (+BVTP 3X12) Gently pull back on tabs...

  • Page 16: A Board And Kd Board Removal

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 1-9. A BOARD AND KD BOARD REMOVAL Disconnect three connectors (CN4701, CN4705, and CN4702) Disconnect three connectors (CN8003, CN8004, and CN8008) and coax cable from tuner Unfasten two Circuit Board Supports Gently pull back...

  • Page 17: G2 Board Removal

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 1-11. G2 BOARD REMOVAL Disconnect 6 connectors (CN6000, CN6024, CN6028, CN6021, CN6023, and CN6022) Disconnect 2 ground wires (CN6013 and CN6015) G2 board Gently pull back on the two clips while slowly lifting the G2 Board.

  • Page 18: Optics Unit Block Assembly And D.c. Fan Removal

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 1-13. OPTICS UNIT BLOCK ASSEMBLY AND D.C. FAN REMOVAL Three screws (+BVTP 3x12) Disconnect two connectors D.C. Fan Optics Unit block assy Two screws Pull forward to remove Special (+PW4X30) 1-14. T BOARD REMOVAL...

  • Page 19: Front Cover Assembly And H1 Board Removal

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 1-15. FRONT COVER ASSEMBLY AND H1 BOARD REMOVAL Disconnect one connector (CN171) H1 Board H1 Button Two screws H1 Bracket (+BVTP 4X16 TYPE2 IT-3) One screw One Ornamental screw (+BVTP 3X12 TYPE2 IT-3) Pull forward on the Front Cover Assembly 1-15-1.REPLACING THE LAMP...

  • Page 20: H3 Board And Speaker Removal

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 1-17. H3 BOARD AND SPEAKER REMOVAL 1 Seventeen screws (+BVTP 4X16 TYPE2 TT(B)) Speaker Box (R) 2 Four screws Disconnect one connector (+BVTP 4X16 TYPE2 IT-3) (CN43) 3 Four screws (+BVTP 4X16 TYPE2 IT-3)

  • Page 21: Mirror Cover Assembly Removal

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 1-19. MIRROR COVER ASSEMBLY REMOVAL Four screws (+BVTP 4X16) Sixteen screws (+BVTP 4X16) 1-19-1.DIFFUSION PLATES (SCREENS) TAPE METHOD The following diagram illustrates the taping method when replacing the Diffusion Plates. For Part Numbers refer to section 6-1. Cover.

  • Page 22: Wire Dressing

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 WIRE DRESSING [F] EMI Shield wire around 2nd post Make sure purse lock is completely seated to [G1] Tie btwn 1st & 2nd posts USB cable must stay to right Blk/Wht to the right...
  • Page 23 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 Detail of front side ATSC Box - LVDS Cables dresses behind [C1] LVDS dressing purse lock Emi Tape added to Sub Tuner cable Detail of front side ATSC Box Top connector wires must be to...
  • Page 24 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 Sensor wire should be in left Tape must avoid OP Block Label three purse locks Purse Lock must be to the right of Loop sensor wire at the 2nd purse the cable tie position...
  • Page 25 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 Right Side Coated Lead Pins details Twist Coated Lead inward to avoid contact with fan assembly after installation KDF-55XS955/60XS955...

  • Page 26: Section 2: Circuit Adjustments

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 SECTION 2: CIRCUIT ADJUSTMENTS 2-1. SETTING THE SERVICE ADJUSTMENT SERVICE MENUS MODE (CATEGORIES ONLY) PANEL WEM 2 To adjust various set features, use the Remote Commander to put the (DISPLAY ENGINE) Q BOX (WEGA ENGINE) set into service mode to display the service menus.

  • Page 27: Memory Write Confirmation Method

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 2-3. MEMORY WRITE CONFIRMATION METHOD 1. After completing all adjustments turn the set off with the Remote Commander and WAIT for the fans to turn off before proceeding to the next step.

  • Page 28: H/V Center Confi Rmation And Adjustments

    All manuals and user guides at all-guides.com .');6;6  +9&(17(5&21),50$7,21$1'$'-8670(176 3OHDVHFKHFNWKHSLFWXUHKRUL]RQWDOYHUWLFDOFHQWHUDIWHUWKHUHSODFHPHQWRIWKH2SWLFV8QLW%ORFN$VVHPEO\RUDQ\SDUWRIWKH7RSDVVHPEO\  &KHFNWKH+9FHQWHUZLWKLPRQRVFRSHVLJQDOLQ³)XOO´PRGH  ,IWKHFHQWHULVVKLIWHGDGMXVWXVLQJWKHIROORZLQJVHUYLFHLWHPV  127(3OHDVHUHFRUGWKHVWHSVVKLIWHGDV 0'+3DQG 0'93            &KDQJHWKH:,'(PRGHWR³1RUPDO´DQGFKDQJHWKHUHJLVWHUGDWDDVIROORZV -)$ 8  -$(0 -$(0 $ONgT CHANGE THE -$60 DATA  'LVSOD\WKH7ZLQ3LFWXUHZLWKWKH³VSOLW´EXWWRQRIWKHUHPRWHFRPPDQGHUDQGFKDQJHWKHUHJLVWHUVGDWDDVIROORZV -)$ 8  -$(0 -$(0  -$60 -$60  3UHVV³)DYRULWHV´EXWWRQDQGFKDQJHWKHUHJLVWHUVGDWDDVIROORZV...

  • Page 29: Service Data

    A complete set of the service data, Fixed and Adjustable, can be downloaded at: http://www-ec.sdp.sel.sony.com/padics/Model_Data_List.htm Only Sony authorized Service Technician can access this site. To request a complete list of the service data in PDF format please contact the Service Promotion Department at Service_Promotion@am.sony.com.
  • Page 30 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 WEGA ENGINE SERVICE DATA SERVICE DATA (dec) CATEGORY # ITEM DESCRIPTION CONDITION DCP_ADJ1 11 SCOL Component-480i Component-480p Component-1080i Component-720p ATSC-480i ATSC-480p ATSC-1080i ATSC-720p ATSC-TEXT HDMI-480i HDMI-480p HDMI-1080i HDMI-720p HDMI(VGA etc) MemoryStick(MPEG1) MemoryStick(MPEG2)

  • Page 31: Id Map Table

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 LCD ENGINE SERVICE DATA SERVICE DATA (dec) CATEGORY # ITEM DESCRIPTION CONDITION A7001R RGAINA RGAINB ROFSETA ROFSETB RVCOM RSIDLVL A7001G GGAINA GGAINB GOFSETA GOFSETB GVCOM GSIDLVL A7001B BGAINA BGAINB BOFSETA BOFSETB BVCOM...

  • Page 32: Section 3: Diagrams

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 SECTION 3: DIAGRAMS 3-1. CIRCUIT BOARDS LOCATION Q Box C (Part of Optics Unit Block Assembly Assembly Cannot be ordered separately) Power supply block RF antenna switch 3-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS INFORMATION All capacitors are in µF unless otherwise noted.
  • Page 33 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REFERENCE INFORMATION Terminal name of semiconductors in silk screen printed circuit ( RESISTOR : RN METAL FILM Circuit Device Printed symbol Terminal name Collector : RC SOLID Transistor : FPRD NONFLAMMABLE CARBON...

  • Page 34: Block Diagrams

    All manuals and user guides at all-guides.com...

  • Page 35: Schematics And Supporting Information

    All manuals and user guides at all-guides.com...

  • Page 36: A Board Schematic Diagram (2 Of 3)

    All manuals and user guides at all-guides.com...

  • Page 37: A Board Schematic Diagram (3 Of 3)

    All manuals and user guides at all-guides.com...
  • Page 38 All manuals and user guides at all-guides.com SDAT SCLK GND(PR) Q8401 HDMI-RESET A-GND GND(R) GND(PB) GND(L) GND(Y) V2-S2 D8027 V2-C R8002 D8026 V2-Y V2-V R8001 D8702 D8028 V2-L V2-R R8012 C8018 R8018 TU8001 C8030 C8037 C8016 C8032 L8006 L8004 CN8040 C8024 L8008 +1.8V...
  • Page 39 All manuals and user guides at all-guides.com +1.8V TEXT_BLK GND(PR) SCLK SDAT HDMI-RESET A-GND GND(PB) GND(R) H.P-MUTE GND(Y) GND(L) +11V +33V JL8073 D8025 STBY5V R8042 SDA-PF JL8075 C8706 R8007 V2-S2 HDMI-RST V2-C SUB-H JL8065 V2-Y SUB-PR V2-V MAIN-PR SDAT-TV JL8071 V2-L F-MONO V2-R...

  • Page 40: B Board Schematic Diagram (1 Of 6)

    All manuals and user guides at all-guides.com...

  • Page 41: B Board Schematic Diagram (2 Of 6)

    All manuals and user guides at all-guides.com...

  • Page 42: B Board Schematic Diagram (3 Of 6)

    All manuals and user guides at all-guides.com...

  • Page 43: B Board Schematic Diagram (4 Of 6)

    All manuals and user guides at all-guides.com...

  • Page 44: B Board Schematic Diagram (5 Of 6)

    All manuals and user guides at all-guides.com...

  • Page 45: B Board Schematic Diagram (6 Of 6)

    All manuals and user guides at all-guides.com...
  • Page 46 All manuals and user guides at all-guides.com R3138 C3066 C3042 C3105 C3045 C3107 FL3003 R3137 C3108 L3009 R3130 C3075 FL3004 C3099 L3008 L3013 R3140 C3044 JL3003 L3005 RB3012 RB3001 RB3003 RB3005 C3063 RB3011 RB3002 RB3004 RB3013 RB3014 C3079 R3155 C3021 R3152 RB3021 C3095...
  • Page 47 All manuals and user guides at all-guides.com R3170 Q3015 IC3007 R3109 R3107 C3104 R3120 R3146 C3114 R3108 IC3002 L3010 C3109 FL3007 R3121 C3072 Q3021 R3117 R3767 R3769 R3145 C3073 R3142 C3074 IC3006 C3085 Q3001 Q3016 R3122 C3110 R3091 R3124 R3073 R3125 R3084 C3028...

  • Page 48: G2 Board Schematic Diagram (1 Of 2)

    All manuals and user guides at all-guides.com...

  • Page 49: G2 Board Schematic Diagram (2 Of 2)

    All manuals and user guides at all-guides.com...
  • Page 50 All manuals and user guides at all-guides.com...
  • Page 51 All manuals and user guides at all-guides.com...

  • Page 52: P Board Schematic Diagram

    All manuals and user guides at all-guides.com...

  • Page 53: Kd Board Schematic Diagram

    All manuals and user guides at all-guides.com...
  • Page 54 All manuals and user guides at all-guides.com...

  • Page 55: G1 Board Schematic Diagram (1 Of 2)

    All manuals and user guides at all-guides.com...

  • Page 56: G1 Board Schematic Diagram (2 Of 2)

    All manuals and user guides at all-guides.com...
  • Page 57 All manuals and user guides at all-guides.com...
  • Page 58 All manuals and user guides at all-guides.com...

  • Page 59: F Board Schematic Diagram

    All manuals and user guides at all-guides.com...
  • Page 60 All manuals and user guides at all-guides.com AC FILTER R1908 C1908 R1906 C1909 T1901 R1928 IC1900 D1914 C1907 C1906 C1905 T1900 R1909 C1902 D1900 C1916 C1914 C1904 T1902 C1901 C1903 CLP1900 R1918 JL1910 VD1902 D1908 RY1900 AC(N) R1901 C1919 D1913 RY1901 AC(L) JL1912...

  • Page 61: Hm Board Schematic Diagram

    All manuals and user guides at all-guides.com...
  • Page 62 All manuals and user guides at all-guides.com...

  • Page 63: H1 Board Schematic Diagram

    All manuals and user guides at all-guides.com...
  • Page 64 All manuals and user guides at all-guides.com...

  • Page 65: H2 Board Schematic Diagram

    All manuals and user guides at all-guides.com...
  • Page 66 All manuals and user guides at all-guides.com...

  • Page 67: H3 Board Schematic Diagram

    All manuals and user guides at all-guides.com...
  • Page 68 All manuals and user guides at all-guides.com...

  • Page 69: H4 Board Schematic Diagram

    All manuals and user guides at all-guides.com...

  • Page 70: U Board Schematic Diagram

    All manuals and user guides at all-guides.com...
  • Page 71 All manuals and user guides at all-guides.com J9401 J9402 CN9401...

  • Page 72: Semiconductors

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 3-5. SEMICONDUCTORS 2SA1162-G 2SA1576A-T106-R 2SA1611-M5M6 Ð 2SC1623-L5L6 TOP VIEW 2SC4081-R 2SD601A-Q 16Pin Ð DTA114EKA-T146 DTC114EK CXA2069Q DTC114EU NJW1149 PQ07VZ012ZP DAP202K DTC143EKA-T146 M1MA152WK-T1 DTC144EKA DTC144EUA-T146 SLR-325VCT31 TOP VIEW CXA2171AQ-T6 2SK2663 PQ30RV11 DE5SC3ML PQ30RV21...

  • Page 73: Section 4: Exploded Views

    All manuals and user guides at all-guides.com...

  • Page 74: Bottom Cabinet

    All manuals and user guides at all-guides.com...

  • Page 75: Chassis

    All manuals and user guides at all-guides.com...

  • Page 76: Section 5: Electrical Parts List

    All manuals and user guides at all-guides.com KDF-55XS955/60XS955 SECTION 5: ELECTRICAL PARTS LIST NOTE: The components identifi ed by shading RESISTORS Items marked with an asterisk are not stocked since they mark are critical for safety. Replace only are seldom required for routine service. Expect some delay •...
  • Page 77 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R9419 1-216-864-11 SHORT CHIP CONNECTOR R9420 1-218-665-11 METAL CHIP 0.50% 1/10W CN44 1-564-509-11 PLUG, CONNECTOR R9421 1-218-665-11 METAL CHIP 0.50% 1/10W...
  • Page 78 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C8083 1-162-968-11 CERAMIC CHIP 0.0047µF 10% C8036 1-162-966-11 CERAMIC CHIP 0.0022µF 10% C8084 1-165-908-11 CERAMIC CHIP 1µF C8037 1-117-681-11 ELECT CHIP 100µF...
  • Page 79 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C8231 1-162-923-11 CERAMIC CHIP 47pF C8342 1-164-156-11 CERAMIC CHIP 0.1µF C8232 1-137-190-91 FILM 0.22µF C8343 1-135-960-91 CERAMIC CHIP 10µF C8346...
  • Page 80 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C8512 1-128-992-21 ELECT CHIP 47µF C8554 1-128-992-21 ELECT CHIP 47µF C8513 1-136-497-81 FILM 0.1µF C8555 1-162-967-11 CERAMIC CHIP 0.0033µF 10%...
  • Page 81 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C8598 1-130-471-00 MYLAR 0.001µF 5% D8006 8-719-977-28 DIODE DTZ10B C8599 1-126-193-11 ELECT CHIP 1µF D8007 8-719-977-28 DIODE DTZ10B C8600 1-126-193-11 ELECT CHIP 1µF...
  • Page 82 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES L8308 1-424-789-41 INDUCTOR 10µH L8309 1-424-789-41 INDUCTOR 10µH IC8001 8-753-204-12 CXA2209Q-T6 L8310 1-400-397-11 INDUCTOR 10µH IC8002 6-706-805-01 TL52055DR L8311 1-412-005-11 INDUCTOR 8.2µH...
  • Page 83 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES Q8201 8-729-027-43 TRANSISTOR DTC114EKA-T146 R8013 1-216-821-11 METAL CHIP 1/10W Q8202 8-729-027-43 TRANSISTOR DTC114EKA-T146 R8014 1-216-821-11 METAL CHIP 1/10W R8015 1-216-821-11...
  • Page 84 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R8058 1-216-833-11 METAL CHIP 1/10W R8105 1-216-809-11 METAL CHIP 1/10W R8059 1-216-821-11 METAL CHIP 1/10W R8106 1-216-809-11 METAL CHIP 1/10W...
  • Page 85 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R8158 1-216-833-11 METAL CHIP 1/10W R8228 1-216-832-11 METAL CHIP 8.2K 1/10W R8159 1-216-849-11 METAL CHIP 220K 1/10W R8229 1-216-822-11 METAL CHIP 1.2K...
  • Page 86 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R8281 1-216-805-11 METAL CHIP 1/10W R8343 1-216-821-11 METAL CHIP 1/10W R8282 1-216-805-11 METAL CHIP 1/10W R8344 1-216-817-11 METAL CHIP 1/10W...
  • Page 87 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R8442 1-216-825-11 METAL CHIP 2.2K 1/10W R8546 1-216-864-11 SHORT CHIP R8443 1-216-833-11 METAL CHIP 1/10W R8547 1-216-823-11 METAL CHIP 1.5K...
  • Page 88 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les mark are critical for safety. Replace only remplacer que par une piece portant le numero specifi...
  • Page 89 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les mark are critical for safety. Replace only remplacer que par une piece portant le numero specifi...
  • Page 90 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 F G1 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les mark are critical for safety. Replace only remplacer que par une piece portant le numero specifi...
  • Page 91 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les mark are critical for safety. Replace only remplacer que par une piece portant le numero specifi...
  • Page 92 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES Q1614 6-550-526-11 TRANSISTOR 2SK2842(LBS2SONY) R1680 1-216-864-11 SHORT CHIP Q1615 8-729-120-28 TRANSISTOR 2SC1623-L5L6 R1681 1-216-833-11 METAL CHIP 1/10W Q1616 8-729-026-49 TRANSISTOR...
  • Page 93 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les mark are critical for safety. Replace only remplacer que par une piece portant le numero specifi...
  • Page 94 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES CN6023 1-818-762-11 PIN, CONNECTOR (PC BOARD) FB6005 1-469-869-21 FERRITE 0µH CN6024 1-785-533-11 PIN, CONNECTOR (PC BOARD) FB6006 1-469-869-21 FERRITE 0µH...
  • Page 95 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES Q6902 8-729-028-28 TRANSISTOR 2SK2036(TE85L) R6039 1-216-833-11 METAL CHIP 1/10W Q6904 8-729-422-33 TRANSISTOR 2SD601A-Q-TX R6040 1-218-722-11 METAL CHIP 0.50% 1/10W Q6905...
  • Page 96 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R6102 1-216-864-11 SHORT CHIP R6164 1-216-864-11 SHORT CHIP R6103 1-216-864-11 SHORT CHIP R6165 1-216-864-11 SHORT CHIP R6105 1-216-864-11 SHORT CHIP...
  • Page 97 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R6883 1-216-864-11 SHORT CHIP R6932 1-216-833-11 METAL CHIP 1/10W R6884 1-216-864-11 SHORT CHIP R6933 1-216-809-11 METAL CHIP 1/10W R6885 1-216-864-11...
  • Page 98 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R6977 1-216-801-11 METAL CHIP 1/10W C4714 1-162-964-11 CERAMIC CHIP 0.001µF 10% R6978 1-216-845-11 METAL CHIP 100K 1/10W C4715 1-126-395-11 ELECT CHIP 22µF...
  • Page 99 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C4765 1-128-994-21 ELECT CHIP 47µF C4821 1-126-193-11 ELECT CHIP 1µF C4766 1-128-994-21 ELECT CHIP 47µF C4822 1-115-340-11 CERAMIC CHIP 0.22µF...
  • Page 100 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES CONNECTOR L4711 1-456-813-11 COIL, AIR-CORE L4712 1-456-813-11 COIL, AIR-CORE CN4701 1-785-701-11 PIN, CONNECTOR (PC BOARD) L4713 1-456-864-11 INDUCTOR 11µH CN4702...
  • Page 101 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R4720 1-216-837-11 METAL CHIP 1/10W R4770 1-216-813-11 METAL CHIP 1/10W R4721 1-220-281-11 RES-CHIP 4.7K 1/4W R4771 1-216-821-11 METAL CHIP 1/10W...
  • Page 102 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 KD P REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R4822 1-216-833-11 METAL CHIP 1/10W R4933 1-216-821-11 METAL CHIP 1/10W R4823 1-216-864-11 SHORT CHIP R4935 1-216-835-11 METAL CHIP...
  • Page 103 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C9537 1-107-826-11 CERAMIC CHIP 0.1µF C9726 1-126-394-11 ELECT CHIP 10µF C9538 1-162-964-11 CERAMIC CHIP 0.001µF 10% C9731 1-126-394-11 ELECT CHIP 10µF...
  • Page 104 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES D9502 8-719-977-28 DIODE DTZ10B IC9514 8-759-331-71 NJM4558E(TE2) D9503 8-719-977-28 DIODE DTZ10B IC9515 6-704-499-01 SII9993CTG100 D9506 8-719-404-50 DIODE MA111-TX IC9517 6-804-248-01...
  • Page 105 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R9510 1-218-665-11 METAL CHIP 0.50% 1/10W R9572 1-216-837-11 METAL CHIP 1/10W R9511 1-216-803-11 METAL CHIP 1/10W R9574 1-216-809-11 METAL CHIP...
  • Page 106 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R9854 1-216-845-11 METAL CHIP 100K 1/10W VARISTOR R9855 1-218-706-11 METAL CHIP 3.9K 0.50% 1/10W VD9500 6-500-701-01 DIODE PGB0010603NR R9856 1-216-829-11 METAL CHIP 4.7K...
  • Page 107 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C3011 1-164-943-11 CERAMIC CHIP 0.01µF C3061 1-125-777-11 CERAMIC CHIP 0.1µF C3012 1-164-943-11 CERAMIC CHIP 0.01µF C3062 1-128-993-21 ELECT CHIP 22µF...
  • Page 108 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C3118 1-117-681-11 ELECT CHIP 100µF C3256 1-164-943-11 CERAMIC CHIP 0.01µF C3201 1-164-943-11 CERAMIC CHIP 0.01µF C3301 1-164-943-11 CERAMIC CHIP 0.01µF...
  • Page 109 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C3344 1-164-943-11 CERAMIC CHIP 0.01µF C3389 1-164-943-11 CERAMIC CHIP 0.01µF C3345 1-125-777-11 CERAMIC CHIP 0.1µF C3390 1-164-943-11 CERAMIC CHIP 0.01µF...
  • Page 110 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C3515 1-164-943-11 CERAMIC CHIP 0.01µF C3558 1-137-710-11 CERAMIC CHIP 10µF 6.3V C3516 1-164-943-11 CERAMIC CHIP 0.01µF C3559 1-137-710-11 CERAMIC CHIP 10µF...
  • Page 111 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C3641 1-126-206-11 ELECT CHIP 100µF 6.3V C3808 1-164-842-11 CERAMIC CHIP 0.25pF 50V C3642 1-164-943-11 CERAMIC CHIP 0.01µF C3809 1-127-988-81 CERAMIC CHIP...
  • Page 112 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES D3808 8-719-050-38 DIODE M1MA152WK-T1 IC3305 6-707-044-01 CYISM560BSXT D3809 8-719-050-37 DIODE M1MA152WA-T1 IC3306 6-706-155-01 MT48LC2M32B2P-6-Y14W IC3307 6-706-155-01 MT48LC2M32B2P-6-Y14W IC3308 8-759-592-42 TC7SZ00FU(TE85R)
  • Page 113 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES L3204 1-469-549-21 INDUCTOR 1µH Q3006 8-729-117-73 TRANSISTOR 2SC4178-F14 L3205 1-469-549-21 INDUCTOR 1µH Q3007 8-729-122-63 TRANSISTOR 2SA1226-E4 L3206 1-469-549-21 INDUCTOR 1µH...
  • Page 114 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES Q3803 8-729-905-35 TRANSISTOR 2SC4081-R R3043 1-208-683-11 METAL CHIP 0.50% 1/16W Q3804 8-729-905-35 TRANSISTOR 2SC4081-R R3044 1-218-849-11 METAL CHIP 1.2K 0.50% 1/10W...
  • Page 115 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R3089 1-218-929-11 RES-CHIP 1/16W R3149 1-208-683-11 METAL CHIP 0.50% 1/16W R3090 1-218-953-11 RES-CHIP 1/16W R3150 1-208-683-11 METAL CHIP 0.50% 1/16W...
  • Page 116 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R3262 1-218-941-81 RES-CHIP 1/16W R3332 1-218-660-91 METAL CHIP 0.50% 1/10W R3264 1-218-947-11 RES-CHIP 1/16W R3333 1-218-664-11 METAL CHIP 0.50% 1/10W...
  • Page 117 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R3379 1-218-990-11 SHORT CHIP R3501 1-218-937-11 RES-CHIP 1/16W R3380 1-218-965-11 RES-CHIP 1/16W R3503 1-218-965-11 RES-CHIP 1/16W R3504 1-218-933-11 RES-CHIP 1/16W...
  • Page 118 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R3609 1-218-941-81 RES-CHIP 1/16W R3663 1-218-965-11 RES-CHIP 1/16W R3614 1-218-973-11 RES-CHIP 1/16W R3664 1-218-965-11 RES-CHIP 1/16W R3665 1-218-965-11 RES-CHIP 1/16W...
  • Page 119 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R3709 1-218-965-11 RES-CHIP 1/16W R3760 1-208-699-11 METAL CHIP 4.7K 0.50% 1/16W R3710 1-218-969-11 RES-CHIP 1/16W R3761 1-218-957-11 RES-CHIP 2.2K 1/16W...
  • Page 120 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R3823 1-218-941-81 RES-CHIP 1/16W R3868 1-218-957-11 RES-CHIP 2.2K 1/16W R3824 1-218-965-11 RES-CHIP 1/16W R3869 1-218-941-81 RES-CHIP 1/16W R3872 1-218-990-11 SHORT CHIP...
  • Page 121 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES RB3311 1-234-378-21 RES, NETWORK 10K (1005X4) RB3312 1-234-378-21 RES, NETWORK 10K (1005X4) RB3313 1-234-378-21 RES, NETWORK 10K (1005X4) A-1060-192-A T BOARD, MOUNTED...
  • Page 122 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES 1-216-864-11 SHORT CHIP IC4501 6-600-210-01 RPM7240-H8 1-216-849-11 METAL CHIP 220K 1/10W IC4502 6-706-481-01 TC7SET32FU(T5RSOJF) 1-216-849-11 METAL CHIP 220K 1/10W 1-218-665-11 METAL CHIP 0.50% 1/10W...
  • Page 123 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C7206 1-162-970-11 CERAMIC CHIP 0.01µF C7207 1-107-826-11 CERAMIC CHIP 0.1µF TRANSISTOR C7208 1-162-970-11 CERAMIC CHIP 0.01µF Q7201 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX...
  • Page 124 All manuals and user guides at all-guides.com KDF-55XS955/60XS955 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES VARISTOR VD171 1-803-974-21 VARISTOR, CHIP (1608) A-1060-183-A H1 BOARD, MOUNTED MISCELLANEOUS 1-500-249-11 BEAD, FERRITE (CASE) CAPACITOR 4-098-165-01 CLAMPER 4-662-796-01 CLIP, COACHING...
  • Page 125 4-097-659-01 BAG, PROTECTION 1-478-918-11 REMOTE COMMANDER (RM-Y915) 3-704-046-31 BAG, PREVENTION, ELECTRIFICATION 3-072-138-01 BATTERY COVER (FOR RM-Y915) (KDF-60XS955 ONLY) 2-048-993-01 CUSHION LOWER (KDF-55XS955 ONLY) 2-023-612-01 CUSHION LOWER (KDF-60XS955 ONLY) 2-048-992-01 CUSHION UPPER (KDF-55XS955 ONLY) 2-023-611-01 CUSHION UPPER (KDF-60XS955 ONLY) 2-059-371-12 GUIDE, QUICK START...
