- Page 1 FD Trinitron Colour Television Instruction Manual KV-28EW20U © 2002 by Sony Corporation 4-091-583-12 409158312...
- Page 2 Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service centre. How to replace the Fuse Open the fuse compartment with a flat blade screwdriver, and replace the fuse.
-
Page 3: Table Of Contents
Introduction Thank you for choosing this Sony FD Trinitron Colour Television. Before operating the TV, please read this manual thoroughly and retain it for future reference. • Symbols used in the manual: • Important information • Information on a feature. -
Page 4: Safety Information
Safety Information This set is to operate on a 220-240V AC supply only. Take care not to connect too many appliances to the same power socket as this could result in fire or electric shock. Do not open the cabinet and the rear cover of the TV. -
Page 5: Overview
Overview of Remote Control Buttons Muting the Sound Press to mute TV sound. Press again to restore the sound. Displaying on Screen information Press to display all on-screen indications. Press again to cancel. Selecting channels Press numbered buttons to select channels. For double-digit programme numbers, e.g.23, press -/-- first then the buttons 2 and 3. -
Page 6: Overview Of Tv Buttons
Overview of TV Buttons Standby On/Off switch indicator Inserting Batteries into the Remote Control Make sure you insert the supplied batteries using the correct polarities. Always remember to dispose of used batteries in an environmental friendly way. Connecting the Aerial and VCR Connecting cables are not supplied. -
Page 7: First Time Operation
Switching On the TV and Automatically Tuning The first time you switch on your TV, a sequence of menu screens appear on the TV enabling you to: 1) choose the language of the menu screen, 2) adjust the picture slant 3) search and store all available channels (TV Broadcast) and 4) change the order in which the channels (TV Broadcast) appear on the screen. - Page 8 The Auto Tuning menu appears on the screen. Press the OK button to select Yes. The TV starts to automatically search and store all available broadcast channels for you. This procedure could take some minutes. Please be patient and do not press any buttons, otherwise the automatic tuning will not be completed.
-
Page 9: Menu System
Introducing and Using the Menu System Your TV uses an on-screen menu system to guide you through the operations. Use the following buttons on the Remote Control to operate the menu system: Press the MENU button to switch the first level menu on. •... -
Page 10: Sound Adjustment
Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Sound Adjustment Mode: Personal Treble Bass Balance Reset Dual Sound: Mono Detail Adjustment This menu also contains two submenus as following: Mode Detail Adjustment • Treble and Bass can only be altered if “Personal” mode is selected. •... -
Page 11: Sleep Timer
Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Timer Sleep Timer: Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Set Up Language/Country Auto Tuning Programme Sorting Progamme Labels AV Preset Manual Programme Preset Detail Set Up Picture Adjustment Mode: Personal Contrast... -
Page 12: Programme Sorting
Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Set Up Language/Country Auto Tuning Programme Sorting Progamme Labels AV Preset Manual Programme Preset Detail Set Up Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Set Up Language/Country Auto Tuning Programme Sorting... -
Page 13: Manual Programme Preset
Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Set Up Set Up Language/Country Language/Country Auto Tuning Auto Tuning Programme Sorting Programme Sorting Progamme Labels Progamme Labels AV Preset AV Preset Manual Programme Preset Manual Programme Preset Detail Set Up Detail Set Up Level 3 / Function... - Page 14 Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Set Up Language/Country Auto Tuning Programme Sorting Progamme Labels AV Preset Manual Programme Preset Detail Set Up Menu System Level 3 / Function Normally the automatic fine tuning (AFT) is operating, however you can manually fine tune the TV to obtain a better picture if the picture is distorted.
-
Page 15: Auto Format
Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Set Up Language/Country Auto Tuning Programme Sorting Progamme Labels AV Preset Manual Programme Preset Detail Set Up Even if you have selected “On” or “Off” in the “Auto Format” option, you can always modify the format of the screen by pressing formats: 14:9:... -
Page 16: Av2 Output
Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Set Up Language/Country Auto Tuning Programme Sorting Progamme Labels AV Preset Manual Programme Preset Detail Set Up If you select “AUTO”, the output signal will always be the same one that is displayed on the screen. If you have connected a decoder to the Scart remember to change back the “AV2 Output”... -
Page 17: Teletext
Teletext Teletext is an information service transmitted by most TV stations. The index page of the teletext service (usually page 100) gives you information on how to use the service. To operate teletext, use the remote control buttons as indicated below. Make sure to use a channel (TV Broadcast) with a strong signal, otherwise teletext errors may occur. -
Page 18: Additional Information
If you use a VCR that supports Smartlink, please connect the VCR by using a Scart lead to the Scart i2/r Additional Information “PlayStation”* Decoder * “PlayStation” is a product of Sony Computer Entertainment, Inc. * “PlayStation” is a trademark of Sony Computer Entertainment, Inc. Decoder Hi-fi continued... -
Page 19: Using Optional Equipment
Connecting to external Audio Equipment: Plug in your Hi-Fi equipment to the audio output sockets E if you wish to amplify the audio output from TV. Next, using the menu system, select the “Sound Adjustment” menu. Enter the “Detail Adjustment” option and set “TV Speakers”... -
Page 20: Specifications
Specifications TV system: Colour system: PAL, SECAM NTSC 3.58, 4.43 (only Video In) Channel Coverage: lI: UHF B21-B69 Picture Tube: Flat Display FD Trinitron WIDE 28” (approx. 71 cm. measured diagonally) Rear Terminals 21-pin scart connector (CENELEC standard) including audio/video input, RGB input, TV audio/video output. -
Page 21: Troubleshooting
• Using the menu system, select the “Set Up” menu. Then enter to “Detail Set Up” option and set “AV2 Output” to “TV”. • Replace the batteries. • Contact your nearest Sony service centre. Additional Information button on the... - Page 24 4-091-583-12 409158312 Trinitron Sony Corporation Printed in UK Recyclable...
