- Page 1 WHT1114LSUK Washing Machine User’s Manual Document Number 2820524425_EN/ 18-12-14.(11:23)
- Page 2 Please read this user manual first! Dear Customer, Thank you for prefering a product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: General Safety Instructions
General safety instructions This section includes security instructions which may help prevent the injuries and material damage risks. All kinds of warranties shall be invalid if these instructions are not observed. 1.1 Life and property safety Never place the product on a carpet-covered floor. Electrical parts will get overheated since air cannot circulate from under the device. -
Page 4: Electrical Safety
Do not forget to close the loading door when leaving the room where the product is located. store all detergents and additives in a safe place away from the reach of the children by closing the cover of the detergent container or sealing the detergent package. -
Page 5: Important Instructions For Environment
Important instructions for environment 2.1 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. -
Page 6: Technical Specifications
Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark SMEG Model name WHT1114LSUK Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 1.210... -
Page 7: Appropriate Installation Location
5.1 Installation • Apply to the nearest authorized service agent for the installation of your product. • Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility. • Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures. -
Page 8: Connecting Water Supply
5.4 Connecting water supply The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly. Attach a pressure reducing valve if water pressure is higher. -
Page 9: Adjusting The Feet
5.6 Adjusting the feet CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing and vibration problems. -
Page 10: Important Fitting A Different Plug
Important Fitting a different plug As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals on your plug, proceed as follows: Connect the green - yellow or green (earth) wire to the terminal in the plug marked ‘E’... -
Page 11: Preparing Laundry For Washing
Preparation 6.1 Sorting the laundry * Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature. * Always obey the instructions given on the garment tags. 6.2 Preparing laundry for washing • Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons will damage the machine. -
Page 12: Using Detergent And Softener
6.6 Using detergent and softener When using detergent, softener, starch, fabric dye, bleacher and decolorant, descaling agents; read the manufacturer's instructions written on the package and follow the dosages specified. Use measuring cup if available. The detergent drawer is composed of three compartments: –... - Page 13 If the product does not contain a liquid detergent cup: • Do not use liquid detergent for the prewash in a programme with prewash. • Liquid detergent stains your clothes when used with Delayed Start function. If you are going to use the Delayed Start function, do not use liquid detergent.
-
Page 14: Tips For Efficient Washing
6.7 Tips for efficient washing Clothes Light Colours and Black/Dark Delicates/ Colours Whites Colours Woolens/Silks (Recommended (Recommended (Recommended temperature (Recommended temperature range temperature range based temperature range range based on soiling level: based on soiling level: cold -40 on soiling level: cold based on soiling 40-90 level: cold -30... -
Page 15: Operating The Product
Operating the product 7.1 Control panel 1 - Programme Selection knob 6 - On / Off button 2 - Spin speed adjustment button 7 - Start / Pause button 3 - Temperature Adjustment button 8 - End Time Setting button 4 - Display 9 - Auxiliary Function buttons 5 - Program Follow-up indicator... -
Page 16: Programme And Consumption Table
7.3 Programme and consumption table Auxiliary functions Selectable Programme temperature range °C 60** 1.21 1600 60-Cold Cotton Eco 60** 0.92 1600 60-Cold 40** 0.91 1600 60-Cold HygieneCare 2.70 1600 90-30 Shirts 1.40 • • • 60-Cold Mixed 0.90 1000 • •... -
Page 17: Programme Selection
Indicative values for Synthetics programmes (EN) Remaining Moisture Content Remaining Moisture Content (%) ** (%) ** ≤ 1000 rpm > 1000 rpm 1.04 / 120 Synthetics 60 0.81 / 110 Synthetics 40 * You can see the washing time of the programme you have selected on the display of the machine. It is normal that small differences may occur between the time shown on the display and the real washing time. - Page 18 • Synthetics You can wash your non-durable laundry in this programme. It washes with a gentle action and has a shorter washing cycle compared to the “Cottons” programme. It is recommended for your synthetic laundry (shirts, blouses, synthetic/cotton combinations, etc.). For curtains and tulle (if curtain programme is not available) using “Synthetic40˚C” programme with prewash and anti-creasing functions selected is recommended.
-
Page 19: Temperature Selection
CAUTION: Do not wash the items apart from duvets such as carpets, rugs and etc. in the machine. Permanent damage occurs in the machine. • Dark Wash Use this programme to wash your dark coloured laundry, or the coloured laundry that you do not want them get faded. -
Page 20: Spin Speed Selection
7.7 Spin speed selection Whenever a new programme is selected, the recommended spin speed of the selected programme is displayed on the Spin Speed indicator. It is possible that the recommended spin speed value is not the maximum spin speed that can be selected for the current programme. - Page 21 • Prewash A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy, water, detergent and time. • Extra Rinse This function enables you to wash and rinse your laundry with plenty of water in Cottons, Synthetics, Lingerie, and Woolens programmes.
-
Page 22: Starting The Programme
In order for the End Time function is activated and the programme is completed at the end of the specified time, you must press Start / Pause button after adjusting the time. 88:88 1888 If you want to cancel End Time function, press On / Off button to turn off and on the machine. Do not use liquid detergents when you activate End Time function! There is the risk of staining of the clothes. -
Page 23: Child Lock
7.12 Changing the selections after programme has started Adding laundry after the programme has started: If the water level in the machine is suitable when you press Start / Pause button, loading door symbol will flash on the display until the loading door is opened and will disappear when the loading door is opened. 88:88 1888 If the water level in the machine is not suitable when you press Start / Pause button, the loading door symbol... -
Page 24: End Of Programme
7.15 End of programme End symbol appears on the display when the programme is completed. If you do not press any button for 10 minutes, the machine will switch to OFF mode. Display and all indicators are turned off. Completed programme steps will be displayed if you press On / Off button. 7.16 Adjusting the VOLUME level Low volume and high volume Press and hold Auxiliary Function button 3 for 3 seconds to adjust the volume level. -
Page 25: Maintenance And Cleaning
Maintenance and cleaning Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 8.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time. Lift the rear part of the siphon to remove it as illustrated. -
Page 26: Cleaning The Water Intake Filters
8.4 Cleaning the water intake filters There is a filter at the end of each water intake valve at the rear of the machine and also at the end of each water intake hose where they are connected to the tap. These filters prevent foreign substances and dirt in the water to enter the washing machine. - Page 27 If the product does not have an emergency water drain hose, in order to drain the water: In order to collect the water to flow out of the filter, place a large vessel in front of the filter. Turn and loosen the pump filter until water starts to flow (counterclockwise).
-
Page 28: Troubleshooting
Troubleshooting Problem Reason Solution Program does not start after Start / Pause / Cancel button was not pressed. Š *Press the Start / Pause / Cancel button. closing the door. Programme cannot be started or Washing machine has switched to self protection Š... - Page 29 Problem Reason Solution Programme time does not Timer may stop during water intake. Š Timer indicator will not countdown until the countdown. (On models with machine takes in adequate amount of water. The display) (*) machine will wait until there is sufficient amount of water to avoid poor washing results due to lack of water.
- Page 30 Problem Reason Solution It does not rinse well. The amount, brand and storage conditions of the Š Use a detergent appropriate for the washing detergent used are inappropriate. machine and your laundry. Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
- Page 31 Problem Reason Solution Laundry remains wet at the end of Excessive foam might have occurred and automatic Š Use recommended amount of detergent. the programme. (*) foam absorption system might have been activated due to too much detergent usage. (*) Machine does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the machine and to its surrounding environment.
