Fujitsu LifeBook P Series BIOS Guide LifeBook P Series Model: P7120/P7120D Document Date: 11/3/2005 Document Part Number: FPC58-1425-01 F U J I T S U C O M P U T E R S Y S T E M S C O R P O R A T I O N...
To enter the BIOS Setup Utility do the following: 1. Turn on or restart your notebook. 2. Press the [ ] key once the Fujitsu logo appears on the screen. This will open the main menu of the BIOS Setup Utility with the current settings displayed.
MAIN MENU - SETTING STANDARD SYSTEM PARAMETERS The Main Menu allows you to set or view the current system parameters. Follow the instructions for Navigating through the Setup Utility changes. The following tables show the names of the menu fields for the Main menu and its submenus, all of the options for each field, the default settings and a description of Main...
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S Menu Field Options Primary Master: Selects Primary Master submenu Serial ATA Port 0: Selects Serial ATA Port 0 submenu ■...
Page 5
Primary Master Submenu of the Main Menu The Primary Master submenu identifies which ATA devices are installed. Main Advanced Primary Master [TOSHIBA MK6006GAH -(PM)] Type: Total Sectors: Maximum Capacity: Multi-Sector Transfers: LBA Mode Control: Transfer Mode: Ultra DMA Mode: Help Exit Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu Menu Field...
Page 6
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu Menu Field Options ■...
Page 7
Serial ATA Port 0 Submenu of the Main Menu The Serial ATA Port 0 submenu identifies which ATA/ IDE devices are installed. Main Advanced Serial ATA Port 0 [MATSHITADVD-RAM UJ-832S-PATA] Type: Help Select Item Exit Select Menu Menu Field Options ■...
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S ADVANCED MENU - SETTING DEVICE FEATURE CONTROLS The Advanced Menu allows you to: Select between the display panel and an external CRT ■...
Page 9
Table 4: Fields, Options and Defaults for the Advanced Menu Menu Field Description Miscellaneous When selected, opens the Miscellaneous Configurations submenu, which allows you to change the power button, Configurations Wake Up On LAN, and Volume settings. Event Logging When selected, opens the Event Logging submenu which lets you view and enable the event log. A d v a n c e d M e n u...
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S Keyboard/Mouse Features Submenu of the Advanced Menu The Keyboard/Mouse Features submenu is for setting the condition of the NumLock button. Main Advanced Keyboard/Mouse Features...
Video Features Submenu of the Advanced Menu The Video Features Submenu is for setting the display parameters. Main Advanced Video Features Display Compensation: Help Exit Table 6: Fields, Options and Defaults for the Video Features Submenu of the Advanced Menu Menu Field Options ■...
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S Internal Device Configurations Submenu of the Advanced Menu The Internal Device Configurations submenu allows the user to configure other internal devices. Main Advanced Internal Device Configurations...
CPU Features Submenu of the Advanced Menu The CPU Features submenu configures certain features of the CPU in the system. Main Advanced SpeedStep(R) Technology: On Battery: On AC: XD Bit functionality: Help Exit Table 8: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu Menu Field Options ■...
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S USB Features Submenu of the Advanced Menu The USB Features submenu configures the USB capabilities of the system. Main Advanced Legacy USB Support:...
Miscellaneous Configurations Submenu of the Advanced Menu The CPU Features submenu configures certain features of the CPU in the system. Main Advanced Miscellaneous Configurations Power Button: Wake up on LAN: Volume Setting: PCI Clock Run: Help Exit Table 10: Fields, Options and Defaults for the Miscellaneous Configurations Submenu Menu Field Options ■...
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S Event Logging Submenu of the Advanced Menu The Event Logging submenu is for setting up the logs for DMI event logging. Main Advanced Event Log Capacity:...
SECURITY MENU - SETTING THE SECURITY FEATURES The Security menu allows you to set up the data security features of your notebook to fit your operating needs and to view the current data security configuration. Follow the instructions for Navigating Through the Setup Utility to make any changes.
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S Table 12: Fields, Options and Defaults for the Security Menu Menu Field Options Supervisor –— Password is: User Password is: –—...
Hard Disk Security Submenu of the Security Menu The Hard Disk Security submenu is for configuring hard disk security features. Main Advanced Primary Master Password Is: Set Primary Master Password: Password Entry on Boot: Help Select Item Exit Select Menu Table 13: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu Menu Field Default...
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S Owner Information Submenu of the Security Menu The Owner Information submenu is for setting owner information. Main Advanced Owner Information...
Page 21
Security Chip Setting Submenu of the Security Menu The Security Chip Setting Submenu is for enabling or disabling the embedded security chip. Main Advanced Security Chip: Clear Security Chip: Help Exit Table 15: Fields, Options and Defaults for the Security Chip Setting Submenu of the Security Menu Menu Field Options Security Chip:...
Turns on and off booting with a truncated set of Power On Self Test. (Fewer tests mean faster turn on.) [Disabled] Turns on and off display of test results instead of Fujitsu logo screen during Power On Self Test. [Enabled] This field is not active unless the Supervisor’s Password has been...
Boot Device Priority Submenu of the Boot Menu The Boot Device Priority submenu is for setting the order of checking of sources for the operating system. Main Advanced Boot Device Priority +Floppy Disk Drive +Hard Disk Drive CD-ROM Drive Help Exit Table 17: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu Menu Field...
L i f e B o o k P 7 0 0 0 N o t e b o o k B I O S INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION The Info menu is a display-only screen that provides the configuration information for your notebook.
EXIT MENU - LEAVING THE SETUP UTILITY The Exit Menu is used to leave the setup utility. Follow the instructions for make any changes. The table shows the names of the menu fields for the Exit menu and a description of the field's function and any special information needed to help understand the field's use.
