Summary of Contents for Night Owl QSG-WCM-2FEIN
- Page 1 1080p Panoramic Camera Quick Setup Guide QSG-WCM-2FEIN.indd 1 2019/6/26 11:23...
-
Page 2: What's In The Box
Mounting Bracket Mounting Tape (includes extra screw) Testing with a Smart Device Note: For OPTION #2 setup, Night Owl recommends using your Smart Device to test the location for your Wi-Fi signal strength before installing the camera. Status Light Key... - Page 3 Add-On or Standalone Night Owl gives you options! Your camera can be used as an add-on to an existing Night Owl Wireless NVR or Hybrid DVR system or as a standalone camera that records to a microSD card. Note: The camera is compatible with Night Owl’s Wireless NVR (WNVRC20 Series) and Hybrid DVR (HC20X Series).
- Page 4 Wireless NVR. To pair an add-on camera to your Night Owl Wireless NVR, please use the following steps: Note: When pairing the camera to your NVR make sure you are in the same room as the NVR. ALWAYS test the camera locally before installing.
- Page 5 If you have not exceeded the channel limitation, the new camera appears in a vacant video field once paired. WooHoo! Your add-on camera has now been paired to the Wireless NVR using the Wireless NVR’s built-in Wi-Fi. QSG-WCM-2FEIN.indd 5 2019/6/26 11:24...
- Page 6 [D1-D4]. Notice that you will only see the “+” sign if there are wireless channels available. The following message appears with some When the following pop-up window additional pairing tips. Once you have opens, click “Add.” checked everything is okay, choose “Next.” QSG-WCM-2FEIN.indd 6 2019/6/26 11:24...
- Page 7 Please be patient while the camera is added to your Hybrid DVR. Once the pairing process is complete, you will be notified the camera was successfully added. Choose “OK.” QSG-WCM-2FEIN.indd 7 2019/6/26 11:24...
- Page 8 Note: If the camera is not in pairing mode, please refer to page 10 for pairing instructions. Know the name and password of the Wi-Fi network being used. Note: If you don’t know your Wi-Fi password, please contact your Internet Service Provider (ISP). Night Owl will not be able to provide this information.
- Page 9 Note: Setup is the same for Smartphone and Tablet. The Night Owl Connect App will guide you through the rest of the setup process. Note: Need more help? Check out the Night Owl Support Site for videos and tutorials on setting up the Night Owl Panoramic Camera.
- Page 10 Night Owl Connect CMS Software The Night Owl Connect CMS Software allows you to view your Night Owl Security system remotely from a PC or Mac . Additionally, you can playback recorded video, save video and images directly to your PC ®...
-
Page 11: Quick Tips
Using a microSD Card: Recommended Compatibility: Class 10, maximum space 128GB. • - If a microSD card is used, video files will be stored on the microSD card (not included). Slide microSD card into the camera. QSG-WCM-2FEIN.indd 11 2019/6/26 11:24... -
Page 12: Need Help
The Federal Communications Commission warns the user that changes or modifications to the unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment should be installed and operated with a minimum distance of 8 inches between the radiator and your body. Rev 190625 QSG-WCM-2FEIN.indd 12 2019/6/26 11:24...
