Frigidaire GLWS1349AS0 Installation Instructions

Full size automatic washer

Hide thumbs Also See for GLWS1349AS0:

Download this manual See also: Owner's Manual

Before beginning installation, carefully read these instructions. This will simplify the

installation and ensure the washer is installed correctly and safely. Leave these instructions

near the washer after installation for future reference.

NOTE: The electrical service to the washer must conform with local codes and ordinances

and the latest edition of the National Electrical Code, ANSI/NFPA 70.

Printed in U.S.A.

Contents

SUBJECT

Pre-Installation Requirements

Electrical Requirements

Grounding Requirements

Water Supply Requirements

Drain Requirements

Rough-In Dimensions

Location

Unpacking

Installation

Replacement Parts

Installation

Instructions

Full Size Automatic Washer

PAGE

3-4

P/N 131457800 (9506)

Page 1 Leave these instructions near the washer after installation for future reference. NOTE: The electrical service to the washer must conform with local codes and ordinances and the latest edition of the National Electrical Code, ANSI/NFPA 70.
Page 2: Electrical Requirements
Check with a licensed electrician if you are in doubt as to whether the appliance is properly grounded. 1. The washer MUST be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electrical shock by a path of least resistance for electrical current.
Page 3 2. Using a ratchet with 3/8" socket, remove the mechanism shipping bolt and plastic spacer block from the center of the base. NOTE: If the washer is to be transported at a later date, the tub blocking pad, shipping bolt, and plastic spacer block should be retained.
Page 4: Replacement Parts
5. Carefully move the washer to its final location. 6. To ensure the washer is level and solid on all four legs, open the lid, grasp the top panel and tilt the washer forward so the rear legs are off the ground.
