POCKET GPRS WATER
Quick Guide ver. 1.0 03/2009
Thanks for purchasing a Digicom product.
Pocket GPRS Water is a monitoring and signalling terminal based on the
GSM technology. It is ideal in the remote control and remote reading of water
and liquid meters and it is able to send via SMS the information to a specific
service center.
It can read the pulse counter and detect the wire cut alarm on 4 meters; as well
as the antitamper alarm of the device itself.
If an alarm is detected, Pocket GPRS Water will send immediately a notification
SMS to the Control Center, otherwise, depending on the factory setting, it will
send the meters reading every 15 days. Pocket GPRS Water is equipped with
an output to control an electrovalve.
PACKAGE CONTENT
• 1 Pocket GPRS Water
• 1 GSM Antenna
• 6 female clips with 3 contacts
• 1 O-Ring washer for GSM antenna
• 4 closing caps
• 1 Installation Guide
GSM MODEM TECHNICAL FEATURES
• Industrial Modem for GSM/SMS applications
• Quad-Band 850-900/1800-1900 MHz GSM module
• Ideal for application in water meters reading
• Management up to 4 local meters via wire
• Management of 1 digital input
• Management of command for bistable solenoid/hydrovalve
• Signalling of device tampering (magnetic contact)
• Signalling of meter wire cut
• Security based on CLI
• Remote configuration via SMS
• Power supply with removable built-in battery: Li-Thionyl 3,6V – 14Ah
• Operating temperature: from -20°C to +55°C
• Led for device status
• CE Mark
MECHANICAL FEATURES
• Plastic case IP 67 protection
• Size: 137 x 70 x 100 mm (antenna excluded) – 137 x 70 x 160 mm (antenna included)
• External Antenna on SMA connector
• 5 cable glands for min 2,5mm
• 6 female clips with 3 contacts, pin spacing 3,5 mm; 250V – 10A; cables: 0,08mm
2
2
– max 6,5mm
cables
2
2
– 1,5mm
(AWG 28-14), stripped 7 mm
Quick Guide
1
