Frigidaire PLHS269ZC Factory Parts Catalog

Frigidaire PLHS269ZC Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for PLHS269ZC:
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
PLHS269ZCB0
PLRS267ZA
MARKET
North America
ENERGY GUIDE - 240592243
OWNER'S GUIDE - # 240389311
SERVICE DATA SHEET - #240389610
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a Professio
stainless/black
Publication No.
5995389953
030502
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
PLHS269ZC
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire PLHS269ZC

Summary of Contents for Frigidaire PLHS269ZC

  • Page 1 SERVICE DATA SHEET - #240389610 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a Professio stainless/black SIDE BY SIDE REFRIGERATOR Publication No. 5995389953 030502 -EN/SERVICE/KHB ©2003 Electrolux Home Products, Inc. All rights reserved FACTORY PARTS CATALO VOLTS Model No. PLHS269ZC...

  • Page 2: Freezer Door

    Publication No. PLHS269ZCB0 5995389953 FREEZER DOOR 05/03...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS269ZCB0 FREEZER DOOR PART NO DESCRIPTION 240390606 Gasket-frzr door, black, magnetic 240334202 Bin-door, frzr-upper 240351602 Bin-door 240351702 Bin-door, frzr-dispenser 240554227 Door-frzr, stainless steel, complete assy 240581906 Door Stop, black ,frzr 240536801 Handle-door, stainless steel, with insert 240598401...

  • Page 4: Refrigerator Door

    Publication No. PLHS269ZCB0 5995389953 REFRIGERATOR DOOR 05/03...
  • Page 5 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts PLHS269ZCB0 REFRIGERATOR DOOR PART NO DESCRIPTION 240390605 Gasket-refr door, black, magnetic 240323002 Bin-door, pseudo, bottom 240326203 Door-dairy 240558801 Nameplate, aluminum 240581905 Door Stop, black, ref 240451981 Door-refr, stainless steel, complete assy...
  • Page 6 Publication No. PLHS269ZCB0 5995389953 CABINET 05/03...
  • Page 7 POS. NO 14A# 100* # = Fast-moving Parts * = Non-Illustrated Parts PLHS269ZCB0 CABINET PART NO DESCRIPTION 240435902 Cover-air duct 240475902 Cover-evap coil,lower 5303208309 Plug-hole,factory test 240505801 Switch,light/lamp 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701 Screw-#10-32 x 1/4 flat hd 240335501...
  • Page 8 Publication No. PLHS269ZCB0 5995389953 SHELVES 05/03...
  • Page 9 POS. NO 26A* 42A* 42A* 140A # = Fast-moving Parts * = Non-Illustrated Parts PLHS269ZCB0 SHELVES PART NO DESCRIPTION 240434604 Trim-basket 240350668 Shelf-freezer,glass ,lower 240350667 Shelf-freezer,glass ,upper 240324101 Shelf-pizza 240588001 Light Bulb 240436702 Light Bulb, A-15, clear, 40 W, 120 V, miniature 240590401 Socket-light 240587702...
  • Page 10 Publication No. PLHS269ZCB0 5995389953 CONTROLS 05/03...
  • Page 11 POS. NO 13 # 21 # 137* 139* 199* # = Fast-moving Parts * = Non-Illustrated Parts PLHS269ZCB0 CONTROLS PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240315802 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702...
  • Page 12 Publication No. PLHS269ZCB0 5995389953 SYSTEM 05/03...
  • Page 13 POS. NO 14 # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS269ZCB0 SYSTEM PART NO DESCRIPTION 240333603 Condenser 218679607 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240346402 Harness-wiring,machine compt 240439901 Wiring Harness,controls 240449601...
  • Page 14 Publication No. PLHS269ZCB0 5995389953 DISPENSER 05/03...
  • Page 15 POS. NO 38A# 38C* # = Fast-moving Parts * = Non-Illustrated Parts PLHS269ZCB0 DISPENSER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 5304422012 Cover-module, black 5304433616...

  • Page 16: Ice Container

    Publication No. PLHS269ZCB0 5995389953 ICE CONTAINER 05/03...
  • Page 17 POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS269ZCB0 ICE CONTAINER PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 5304422805 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...

  • Page 18: Ice Maker

    Publication No. PLHS269ZCB0 5995389953 ICE MAKER 05/03...
  • Page 19 POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts PLHS269ZCB0 ICE MAKER PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 240561701...

  • Page 20: Wiring Schematic

    Publication No. PLHS269ZCB0 5995389953 WIRING SCHEMATIC 05/03...

  • Page 21: Wiring Diagram

    PLHS269ZCB0 Publication No. 5995389953 WIRING DIAGRAM # = Fast-moving Parts 05/03 * = Non-Illustrated Parts...
