Product No.
GHSC39FTEB0 GHSC39FTES0 GHSC39FTEW0
Series
counter depth
Color
black
Volts
115
Wiring Diagram
241638600
Owner's Guide
241694601
Market
North America
Energy Guide
241649250
Service Data Sheet 241639000
Publication No.
5995463709
06/03/21
(EN/SERVICE/DCS)
137
counter depth
counter depth
stainless
white
115
115
241638600
241638600
241694601
241694601
North America
North America
241649250
241649250
241639000
241639000
SIDE-BY-SIDE
REFRIGERATOR
Model No.
GHSC39FTE
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire GHSC39FTE
Summary of Contents for Frigidaire GHSC39FTE
- Page 1 241638600 241638600 241638600 241694601 241694601 241694601 North America North America North America 241649250 241649250 241649250 241639000 241639000 SIDE-BY-SIDE REFRIGERATOR Model No. GHSC39FTE Publication No. 5995463709 06/03/21 (EN/SERVICE/DCS) © Copyright 2006 Electrolux Home Products, Inc. All rights reserved.
-
Page 2: Freezer Door
Publication No: 5995463709 03/06 GHSC39FTE FREEZER DOOR N58FKGBGA0... - Page 3 240352102 240411501 240552102 5303918256 # Functional Parts * Non-Illustrated Parts GHSC39FTE FREEZER DOOR A GHSC39FTE (GHSC39FTEB0) B GHSC39FTE (GHSC39FTES0) C GHSC39FTE (GHSC39FTEW0) DESCRIPTION A B - Gasket-frzr door, black, magnetic - - C Gasket-frzr door, white, magnetic A B C...
-
Page 4: Refrigerator Door
Publication No: 5995463709 GHSC39FTE REFRIGERATOR DOOR N58RKGCHB0 03/06... - Page 5 240430321 240430322 241508401 241515801 # Functional Parts * Non-Illustrated Parts GHSC39FTE REFRIGERATOR DOOR A GHSC39FTE (GHSC39FTEB0) B GHSC39FTE (GHSC39FTES0) C GHSC39FTE (GHSC39FTEW0) DESCRIPTION A B - Gasket-refr door, black, magnetic - - C Gasket-refr door, white, magnetic A B C...
- Page 6 Publication No: 5995463709 N58BABAAD4 03/06 GHSC39FTE CABINET...
- Page 7 100* 240350802 241591701 5303321321 5303321319 # Functional Parts * Non-Illustrated Parts GHSC39FTE CABINET A GHSC39FTE (GHSC39FTEB0) B GHSC39FTE (GHSC39FTES0) C GHSC39FTE (GHSC39FTEW0) DESCRIPTION A B C Cover-air duct A B C Cover-evap coil, lower A B C Plug-hole, factory test...
- Page 8 Publication No: 5995463709 03/06 GHSC39FTE SHELVES N58SDHLBE11...
- Page 9 241504701 241504702 241674401 241674402 240424502 240430505 # Functional Parts * Non-Illustrated Parts GHSC39FTE SHELVES A GHSC39FTE (GHSC39FTEB0) B GHSC39FTE (GHSC39FTES0) C GHSC39FTE (GHSC39FTEW0) DESCRIPTION A B C Trim-basket A B C Shelf-freezer, glass, lower A B C Shelf-freezer, glass, upper...
- Page 10 Publication No: 5995463709 03/06 GHSC39FTE CONTROLS N58TBAAAB3...
- Page 11 240397502 199* 240398401 241544902 # Functional Parts * Non-Illustrated Parts GHSC39FTE CONTROLS A GHSC39FTE (GHSC39FTEB0) B GHSC39FTE (GHSC39FTES0) C GHSC39FTE (GHSC39FTEW0) DESCRIPTION A B C Fan Blade, red, evaporator fan A B C Washer, "slinger", nylon, evap fan shaft A B C...
- Page 12 Publication No: 5995463709 03/06 GHSC39FTE SYSTEM N58CACBAA3...
- Page 13 5304421068 240553501 240409302 5303918222 5303918327 # Functional Parts * Non-Illustrated Parts GHSC39FTE SYSTEM A GHSC39FTE (GHSC39FTEB0) B GHSC39FTE (GHSC39FTES0) C GHSC39FTE (GHSC39FTEW0) DESCRIPTION A B C Condenser A B C Block-evap coil, styrofoam, (2) A B C Drier-filter, R134a System...
-
Page 14: Ice And Water Dispenser
Publication No: 5995463709 03/06 GHSC39FTE ICE & WATER DISPENSER N58XEBAAA1... - Page 15 5304421621 240411501 5303918256 5304426535 # Functional Parts * Non-Illustrated Parts GHSC39FTE ICE & WATER DISPENSER A GHSC39FTE (GHSC39FTEB0) B GHSC39FTE (GHSC39FTES0) C GHSC39FTE (GHSC39FTEW0) DESCRIPTION A B C Tube-water-DOOR A B C Tube-water inlet, inlet valve, to ice maker A B C...
-
Page 16: Ice Container
Publication No: 5995463709 03/06 GHSC39FTE ICE CONTAINER 37A 34 34 33 N58YDAAAC0... - Page 17 5304404361 5304404331 241504601 215005100 241551601 241504301 # Functional Parts * Non-Illustrated Parts GHSC39FTE ICE CONTAINER A GHSC39FTE (GHSC39FTEB0) B GHSC39FTE (GHSC39FTES0) C GHSC39FTE (GHSC39FTEW0) DESCRIPTION A B C Auger-ice A B C Cam-drive A B C Container-ice, bucket only A B C...
-
Page 18: Ice Maker
Publication No: 5995463709 GHSC39FTE ICE MAKER 03/06... - Page 19 55 # 240531101 218709100 240363601 # Functional Parts * Non-Illustrated Parts GHSC39FTE ICE MAKER A GHSC39FTE (GHSC39FTEB0) B GHSC39FTE (GHSC39FTES0) C GHSC39FTE (GHSC39FTEW0) DESCRIPTION A B C Tube-water-DOOR A B C Tube-water inlet, inlet valve, to ice maker A B C...
- Page 20 Publication No: 5995463709 GHSC39FTE ICE MAKER 03/06...
- Page 21 5304436612 218888001 241583301 241696501 # Functional Parts * Non-Illustrated Parts GHSC39FTE ICE MAKER A GHSC39FTE (GHSC39FTEB0) B GHSC39FTE (GHSC39FTES0) C GHSC39FTE (GHSC39FTEW0) DESCRIPTION A B C Cap-water valve A B C Screw, hex washer head, 8-18AB x 1.250, spacer, (2) A B C Clamp, 0.31 ID, steel, copper wtr line...
-
Page 22: Wiring Schematic
Publication No: 5995463709 GHSC39FTE WIRING SCHEMATIC 03/06... -
Page 23: Wiring Diagram
2416386 # Functional Parts * Non-Illustrated Parts GHSC39FTE WIRING DIAGRAM DISPENSER ASSY WIRING GRN/YEL BLU/WHT LT. BLU RED/BLK ORG/WHT BARE NATURAL WHT/YEL BRN/YEL BLK/YEL RED/YEL YEL/PNK ORG/WHT YEL/GRY GRN/YEL LT. BLU DIODE SPLICE TAN/YEL SPLICE SPLICE DIODE DIODES MUST BE...
