PRODUCT NO.
BASE MODEL NO.
FRT18KB2CW0
FRT18KB2C
MARKET
North America
WIRING DIAGRAM - # 240379010
OWNER'S GUIDE - # 240400109
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
white
Publication No.
5995389029
030415
-EN/SERVICE /ECL
390
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18KB2C
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18KB2C
Summary of Contents for Frigidaire FRT18KB2C
- Page 1 PRODUCT NO. BASE MODEL NO. FRT18KB2CW0 FRT18KB2C MARKET North America WIRING DIAGRAM - # 240379010 OWNER’S GUIDE - # 240400109 SERVICE DATA SHEET - # 240379010 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a white...
- Page 2 Publication No. FRT18KB2CW0 5995389029 DOOR 04/03...
- Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT18KB2CW0 DOOR PART NO DESCRIPTION 240542103 Gasket-frzr door,white ,magnetic 240542106 Gasket-refr door,white ,magnetic 240534901 Rack-door 240534701 Rack-door,4B 240337701 Door-dairy,w/o graphics ,white 240534801 Rack-door 240381301 Plug-button,white ,hinge brg hole ,(2) 240412501 Door,frzr ,white ,complete assy 240415201 Label-nameplate,white...
- Page 4 Publication No. FRT18KB2CW0 5995389029 CABINET 03/02...
- Page 5 POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18KB2CW0 CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462010 Cover-evap coil 240568601 Seal-coil cover...
- Page 6 Publication No. FRT18KB2CW0 5995389029 SHELVES 04/03...
- Page 7 POS. NO 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18KB2CW0 SHELVES PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 5303282284 Shelf-freezer,"table type" 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 241500701 Socket-light/lamp 240352701...
- Page 8 Publication No. FRT18KB2CW0 5995389029 SYSTEM 04/03...
- Page 9 POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18KB2CW0 SYSTEM PART NO DESCRIPTION 240406406 Condenser,static 5303208866 Spacer,condenser tube ,black 5308000296 Bracket,condenser mtg ,(4) 5308009617 Washer,ext tooth lock ,#10 ,grounding 218944001...
-
Page 10: Wiring Schematic
Publication No. FRT18KB2CW0 5995389029 WIRING SCHEMATIC 04/03... -
Page 11: Wiring Diagram
FRT18KB2CW0 Publication No. 5995389029 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
