Frigidaire FRT18G5A Factory Parts Catalog
Top-mount refrigerator
Hide thumbs
Also See for FRT18G5A:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT18G5AQ1
FRT18G5A
FRT18G5AW1
FRT18G5A
MARKET
North America
WIRING DIAGRAM - # 240379007
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995368684
020319
-EN/SERVICE /BLT
357
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18G5A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18G5A
Summary of Contents for Frigidaire FRT18G5A
- Page 1 PRODUCT NO. BASE MODEL NO. FRT18G5AQ1 FRT18G5A FRT18G5AW1 FRT18G5A MARKET North America WIRING DIAGRAM - # 240379007 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379007 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR...
- Page 2 Publication No. FRT18G5A 5995368684 DOOR 03/02...
- Page 3 A = FRT18G5A (FRT18G5AQ1) B = FRT18G5A (FRT18G5AW1) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT18G5A DOOR PART NO DESCRIPTION 240514605 Gasket-frzr door,white ,magnetic 240514608 Gasket-refr door,white ,magnetic 240331401 Rack-door,20.27" x 1.72" 240311502 Support-door rack,2 liter ,RH...
- Page 4 Publication No. FRT18G5A 5995368684 CABINET 03/02...
- Page 5 A = FRT18G5A (FRT18G5AQ1) B = FRT18G5A (FRT18G5AW1) POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18G5A CABINET PART NO DESCRIPTION 240355401 Cover-fan 240433201 Screw,hex washer head ,8-18 x 0.375 240367001 Knob-damper control 5303001028 Nut,push-on...
- Page 6 Publication No. FRT18G5A 5995368684 SHELVES 03/02...
- Page 7 A = FRT18G5A (FRT18G5AQ1) B = FRT18G5A (FRT18G5AW1) POS. NO 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18G5A SHELVES PART NO DESCRIPTION 215667501 Tray-ice,plastic 240358002 Shelf-freezer,full width 5303299664 Spacer,shelf 240362502 Diffuser-air,top 240362601 Diffuser-air,bottom 240505801...
- Page 8 Publication No. FRT18G5A 5995368684 SYSTEM 03/02...
- Page 9 A = FRT18G5A (FRT18G5AQ1) B = FRT18G5A (FRT18G5AW1) POS. NO 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18G5A SYSTEM PART NO DESCRIPTION 240444401...
-
Page 10: Wiring Schematic
Publication No. FRT18G5A 5995368684 WIRING SCHEMATIC 03/02... -
Page 11: Wiring Diagram
FRT18G5A Publication No. 5995368684 WIRING DIAGRAM # = Fast-moving Parts 03/02 * = Non-Illustrated Parts...
