Frigidaire FRS26KF6E Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26KF6E:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
N58L00001.eps N58FCCBBB2.eps N58RCCBBB11.eps N58BAAAAA0.eps
N58SJCHAB11.eps N58TAAAAB4.eps N58CAAAAA5.eps N58XDAAAA1.eps
N58YBAAAA0.eps N58I115.eps W241526901A.eps S241526901A.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS26KF6EM1
Series
R134a
Color
silver mist
Volts
115
Wiring Diagram
241526901
Owner's Guide
241661500
Market
North America
Energy Guide
241615424
Service Data Sheet 240389616
Publication No.
5995447124
05/09/06
(EN/SERVICE/DCS)
357
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26KF6E
©
2005 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26KF6E

Summary of Contents for Frigidaire FRS26KF6E

  • Page 1 Color silver mist Volts Wiring Diagram 241526901 Owner's Guide 241661500 Market North America Energy Guide 241615424 Service Data Sheet 240389616 SIDE-BY-SIDE REFRIGERATOR Model No. FRS26KF6E Publication No. 5995447124 05/09/06 (EN/SERVICE/DCS) © Copyright 2005 Electrolux Home Products, Inc. All rights reserved.

  • Page 2: Freezer Door

    Publication No: 5995447124 FRS26KF6EM1 FREEZER DOOR N58FCCBBB2 09/05...
  • Page 3 POS. NO PART NO. 241569806 240334201 240351601 241668504 240581906 240359108 218781100 240598401 240521302 240328204 240328404 240359203 241525101 240421701 218396700 215503200 240352102 240552101 5303918256 # Functional Parts * Non-Illustrated Parts FRS26KF6EM1 FREEZER DOOR DESCRIPTION Gasket-frzr door, black, magnetic Bin-door, frzr-upper Bin-door Door-frzr, silver mist, complete assy Door Stop, black, frzr Handle-door, black, LH...

  • Page 4: Refrigerator Door

    Publication No: 5995447124 09/05 FRS26KF6EM1 REFRIGERATOR DOOR N58RCCBBB11...
  • Page 5 240359203 240356402 240421701 218396700 215503200 # Functional Parts * Non-Illustrated Parts FRS26KF6EM1 REFRIGERATOR DOOR DESCRIPTION Gasket-refr door, black, magnetic Bin-door, pseudo, bottom Door-dairy Door Stop, black, ref Door-refr, gray, complete assy Handle-door, black, RH Screw, pan head, 8-18 x 0.625...
  • Page 6 Publication No: 5995447124 FRS26KF6EM1 CABINET 09/05...
  • Page 7 POS. NO PART NO. 240435906 240475907 5303208309 240505801 241547901 218252200 240457702 240402701 240335501 241603701 241603702 240337603 240327201 240327007 241550801 241550701 240578901 240335003 241500301 218659500 218781100 240374301 66B* 240518802 240324406 5308016566 5304418225 5303316859 241574602 218249808 240380101 216850900 240423701 100* 240350802 240368701 240396801 240479601 240481601...
  • Page 8 Publication No: 5995447124 09/05 FRS26KF6EM1 SHELVES N58SJCHAB11...
  • Page 9 POS. NO PART NO. 241657602 241657502 241657504 240324101 240355208 240350702 240362101 240350902 240351005 240349801 240362201 240351206 240430706 240430702 240356501 240365401 240350633 240350603 240564401 240343002 240343102 240342806 5308016566 240545303 218493100 101* 215005000 215005100 241630701 241630702 240430501 # Functional Parts * Non-Illustrated Parts FRS26KF6EM1 SHELVES DESCRIPTION...
  • Page 10 Publication No: 5995447124 FRS26KF6EM1 CONTROLS 09/05...
  • Page 11 POS. NO PART NO. 5308000010 215474201 241563601 240369702 241517701 241555401 241513901 240317701 241537802 240360801 21 # 241586501 5304421067 218660702 23 # 241508001 5303001259 240369501 5308016566 241637201 241600902 240396401 137* 240396701 240397301 240396002 139* 240526901 241563501 149* 241528306 240394204 240373806 240397401 240397501 199* 240398401...
  • Page 12 Publication No: 5995447124 09/05 FRS26KF6EM1 SYSTEM N58CAAAAA5...
  • Page 13 POS. NO PART NO. 240333603 218679607 218944001 241586801 241537802 241651601 14 # 240316107 15 # 5303918284 5308000110 21 # 5303918214 240330008 218252200 218513300 240491501 241637401 29 # 5303918316 30 # 241524605 218973501 240405201 240555001 215174700 5308016566 218909913 240542601 218897002 5304430246 240346701 240359401 60 #...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995447124 FRS26KF6EM1 ICE & WATER DISPENSER 09/05...
  • Page 15 POS. NO PART NO. 218976409 218976901 218976903 218976907 240561701 5304433186 5304422013 5304426649 240570206 5304421616 240548901 5304421619 5304433185 241649003 5304422026 5304422025 5304421628 5304421624 5304421625 5304421629 5304421620 38A# 5304421617 38A* 5304430839 5304436275 38C* 5304430837 5304421627 5304421829 215296300 5304421830 240363401 5304421622 5304421621 5304421615 218515401 5303918256 # Functional Parts...

  • Page 16: Ice Container

    Publication No: 5995447124 FRS26KF6EM1 ICE CONTAINER 09/05...
  • Page 17 POS. NO PART NO. 5304428402 5304404343 218815300 5304404346 218815400 241624801 5304404359 241555401 241559801 5304404345 18 # 5304440392 18*# 240352601 5304404332 215285100 5304404347 5304404362 215503200 5304404351 5304404349 5304404353 5304404352 5304404348 5304404350 5304404356 5304404365 5304404358 218359200 45 # 5304404333 5304406816 5304406817 5304406818 5304406819 5304404341 5304404342...

  • Page 18: Ice Maker

    Publication No: 5995447124 FRS26KF6EM1 ICE MAKER 09/05...
  • Page 19 POS. NO PART NO. 218976409 218976901 218976903 218976907 240561701 5304420650 3206299 3206301 3206303 3206305 3206306 3206312 3206313 3206315 11 # 3206319 12 # 240352601 13 # 3206322 5304420652 15 # 3206324 5304420653 17 # 5303320545 3206328 3206330 5304408581 3206332 3206333 5304408582 3206335 3206336...

  • Page 20: Wiring Schematic

    Publication No: 5995447124 FRS26KF6EM1 WIRING SCHEMATIC 09/05...

  • Page 21: Wiring Diagram

    FRS26KF6EM1 Publication No: 5995447124 WIRING DIAGRAM 09/05 # Functional Parts * Non-Illustrated Parts...
