Frigidaire FRS24ZRG Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS24ZRG:
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRS24ZRGD1
FRS24ZRG
FRS24ZRGW1
FRS24ZRG
MARKET
North America
WIRING DIAGRAM - # 218875901
OWNER'S GUIDE - # 218854700
SERVICE DATA SHEET - # 218877000
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
This Publication Supercedes
Publication Number 5995311163
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
almond
R134a
white
Publication No.
5995349098
010130
-EN/SERVICE /ECL
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model number
FRS24ZRG
©2001 White Consolidated Industries, Inc.
All rights reserved
