Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
PLGFZ390ECA
Series
30" f/s gas
Color
stainless
Market
North America
Wiring Diagram
316417806
Owner's Guide
316417111
Installation Instructions 316259336
Service Data Sheet
316417610
Publication No.
5995439337
05/06/14
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING GAS
RANGE
Model No.
PLGFZ390E
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire PLGFZ390E
Summary of Contents for Frigidaire PLGFZ390E
- Page 1 Market North America Wiring Diagram 316417806 Owner's Guide 316417111 Installation Instructions 316259336 Service Data Sheet 316417610 30-INCH FREE- STANDING GAS PLGFZ390E Publication No. 5995439337 05/06/14 (EN/SERVICE/ECL) © Copyright 2005 Electrolux Home Products, Inc. RANGE Model No. All rights reserved.
- Page 2 Publication No: 5995439337 PLGFZ390ECA BACKGUARD 06/05...
- Page 3 POS. NO PART NO. 316416100 316051600 316235100 316095500 316022500 316411405 316411404 316424129 20 # 316418701 316419700 316223002 316220002 316447600 316416200 316040201 316230701 5303288565 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts PLGFZ390ECA BACKGUARD DESCRIPTION Shield, backguard, rear wall Shield, backguard, inner Shield, top, inner Switch, infinite, warmer...
- Page 4 Publication No: 5995439337 PLGFZ390ECA BURNER 06/05...
- Page 5 POS. NO PART NO. 316219501 5303935233 2A # 5303935235 2B # 5303935232 2C # 5303935234 316215600 316219006 318079001 10 # 316223300 10A# 316206400 10B# 316212300 10C# 316212400 11 # 316430500 11A# 316430800 11B# 316430401 11C# 316237800 11D# 316430700 13 # 316405300 14 # 316091706...
- Page 6 Publication No: 5995439337 NOTE: Oven Liner N/A Ass. du four N/A 06/05 PLGFZ390ECA BODY T24V0030...
- Page 7 POS. NO PART NO. 316401600 316402201 316437100 316400104 316400105 316201403 316272900 316407200 316404501 318219500 316400603 316081900 316082000 12 # 316407100 316116400 5303013071 08011086 316087500 18 # 316405800 316408000 316217700 316217701 316402500 316116600 316208901 37 # 316217001 39 # 3131425 316409600 316409200 316409201 316400703...
- Page 8 Publication No: 5995439337 NOTE: Oven Liner N/A Ass. du four N/A 06/05 PLGFZ390ECA BODY T24V0030...
- Page 9 POS. NO PART NO. 108# 316415700 316136400 316136500 316136600 316404600 161# 316211603 5303935180 170* 316107200 170* 316112500 170* 316116000 316404700 316416605 5303305345 316021105 316021108 316021110 316021132 316089500 5303271648 5303285179 # Functional Parts * Non-Illustrated Parts PLGFZ390ECA BODY DESCRIPTION Motor, convection Blade, fan Washer, fan motor Nut, fan retainer...
- Page 10 Publication No: 5995439337 06/05 PLGFZ390ECA TOP/DRAWER 24T00...
- Page 11 POS. NO PART NO. 316408901 316403203 316409304 316415000 316415001 316411216 20 # 316424203 316424403 316271900 316206600 316213600 316213500 316246100 81 # 316239201 316093200 316093300 316093501 316425900 316095800 316091900 316099500 316001917 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts PLGFZ390ECA TOP/DRAWER DESCRIPTION...
- Page 12 Publication No: 5995439337 PLGFZ390ECA DOOR 06/05...
- Page 13 POS. NO PART NO. 316408501 316402307 316403900 316117500 316423801 316001002 316008401 316403101 316407804 316102208 316102205 316402403 316408600 316437702 316418900 316246100 316408101 316408300 316021110 316433603 316021109 5303271648 5303285179 # Functional Parts * Non-Illustrated Parts PLGFZ390ECA DOOR DESCRIPTION Glass, door front, black Shield, wool Insulation, oven door Glass, oven door, heat barrier...
-
Page 14: Wiring Schematic
Publication No: 5995439337 PLGFZ390ECA WIRING SCHEMATIC 06/05... -
Page 15: Wiring Diagram
PLGFZ390ECA Publication No: 5995439337 WIRING DIAGRAM 06/05 # Functional Parts * Non-Illustrated Parts...
