Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FGF366EBA FGF366EQA FGF366ESA
Series
30" f/s gas
Color
black
Market
North America North America North America
Wiring Diagram
316417800
Owner's Guide
316417100
Installation Instructions 316259336
Service Data Sheet
316417605
Publication No.
5995446449
05/08/30
(EN/SERVICE/BJH)
369
30" f/s gas
30" f/s gas
bisque
white
316417800
316417800
316417100
316417100
316259336
316259336
316417605
316417605
30-INCH FREE-
STANDING GAS
RANGE
Model No.
FGF366E
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FGF366E
Summary of Contents for Frigidaire FGF366E
- Page 1 North America North America North America 316417800 316417800 316417800 316417100 316417100 316417100 316259336 316259336 316417605 316417605 316417605 30-INCH FREE- STANDING GAS RANGE Model No. FGF366E Publication No. 5995446449 05/08/30 (EN/SERVICE/BJH) © Copyright 2005 Electrolux Home Products, Inc. All rights reserved.
- Page 2 Publication No: 5995446449 FGF366E BACKGUARD 08/05...
- Page 3 316230701 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts FGF366E BACKGUARD A FGF366E (FGF366EBA) B FGF366E (FGF366EQA) C FGF366E (FGF366ESA) DESCRIPTION A B C Shield, backguard, rear wall A B C Shield, backguard, inner A B C Shield, top, inner...
- Page 4 Publication No: 5995446449 FGF366E BURNER 08/05...
- Page 5 316248105 316253700 316001003 316215600 5303271648 # Functional Parts * Non-Illustrated Parts FGF366E BURNER A FGF366E (FGF366EBA) B FGF366E (FGF366EQA) C FGF366E (FGF366ESA) DESCRIPTION A B C Pipe, manifold A B C Valve, 14K burner, w/mtg screw A B C Valve, 9.5K burner, w/mtg screw...
- Page 6 Publication No: 5995446449 NOTE: Oven Liner N/A Ass. du four N/A 08/05 FGF366E BODY T24V0025...
- Page 7 89 # 316415400 316401100 316401000 316404600 # Functional Parts * Non-Illustrated Parts FGF366E BODY A FGF366E (FGF366EBA) B FGF366E (FGF366EQA) C FGF366E (FGF366ESA) DESCRIPTION A B C Back, main A B C Shield, oven top A B C Brace, oven top...
- Page 8 Publication No: 5995446449 NOTE: Oven Liner N/A Ass. du four N/A 08/05 FGF366E BODY T24V0025...
- Page 9 316021105 316021108 316021110 316089500 5303285179 # Functional Parts * Non-Illustrated Parts FGF366E BODY A FGF366E (FGF366EBA) B FGF366E (FGF366EQA) C FGF366E (FGF366ESA) DESCRIPTION A B C Anti-tip Kit, w/bracket, screw A B C Bracket, anti-tip A B C Template, anti-tip A B C Screw, concrete, 1.75", anti-tip brkt...
- Page 10 Publication No: 5995446449 FGF366E TOP/DRAWER 08/05...
- Page 11 316099500 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts FGF366E TOP/DRAWER A FGF366E (FGF366EBA) B FGF366E (FGF366EQA) C FGF366E (FGF366ESA) DESCRIPTION A B C Drawer, utility A B C Liner, drawer A - - Panel, drawer, black, front...
- Page 12 Publication No: 5995446449 FGF366E DOOR T24D0017 08/05...
- Page 13 316021110 316433603 316021109 5303271648 5303285179 # Functional Parts * Non-Illustrated Parts FGF366E DOOR A FGF366E (FGF366EBA) B FGF366E (FGF366EQA) C FGF366E (FGF366ESA) DESCRIPTION A - - Trim, oven door, black - B - Trim, oven door, bisque - - C...
-
Page 14: Wiring Schematic
Publication No: 5995446449 FGF366E WIRING SCHEMATIC 08/05... -
Page 15: Wiring Diagram
FGF366E Publication No: 5995446449 WIRING DIAGRAM 08/05 # Functional Parts * Non-Illustrated Parts...
