Frigidaire FGF337B Factory Parts Catalog

Gas range
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FGF337BCA
FGF337B
SERVICE DATA SHEET - # 316259145
WIRING DIAGRAM - #316255201
OWNER'S GUIDE - # 316257509
INSTALLATION INSTRUCTIONS -# 316259315
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
This Publication Supercedes
Publication # 5995370359
COLOR
MARKET
stainless
North America
Publication No.
5995377230
020821
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
GAS
RANGE
Model No.
FGF337B
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading

Related Manuals for Frigidaire FGF337B

Summary of Contents for Frigidaire FGF337B

  • Page 1 PRODUCT NO. BASE MODEL NO. FGF337BCA FGF337B SERVICE DATA SHEET - # 316259145 WIRING DIAGRAM - #316255201 OWNER’S GUIDE - # 316257509 INSTALLATION INSTRUCTIONS -# 316259315 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 This Publication Supercedes Publication # 5995370359...
  • Page 2 Publication No. FGF337BCA 5995377230 BACKGUARD 08/02...
  • Page 3 POS. NO 20 # 24 # # = Fast-moving Parts * = Non-Illustrated Parts FGF337BCA BACKGUARD PART NO DESCRIPTION 316239900 Shield,backguard ,rear wall 316220216 Support,backguard ,black ,RH 316220217 Support,backguard ,black ,LH 316232662 Panel,backguard ,black 316222800 Clock/Timer,electronic 316207200 Filter,noise ,electronic 316220701 Overlay,clock ,black 316246001 Switch,rocker ,black ,oven light...
  • Page 4 Publication No. FGF337BCA 5995377230 BURNER 08/02...
  • Page 5 POS. NO 2C # 10 # 10C# 11 # 11B# 11C# 13 # 14 # 16 # 17 # 18 # 19 # # = Fast-moving Parts * = Non-Illustrated Parts FGF337BCA BURNER PART NO DESCRIPTION 316204000 Pipe,manifold 5303935210 Valve,12K top burner ,w/mtg screw 5303935213 Valve,9.5K top burner ,w/mtg screw 316134300...
  • Page 6 Publication No. FGF337BCA 5995377230 BODY 08/02...
  • Page 7 POS. NO 37 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FGF337BCA BODY PART NO DESCRIPTION 316029416 Panel,main back 316230104 Panel,bodyside ,black ,RH 316230105 Panel,bodyside ,black ,LH 316201402 Burner Box 316129200 Screw,leveling ,plastic ,with stop 316067902 Rack,oven 316212906 Hinge,oven door ,RH...
  • Page 8 Publication No. FGF337BCA 5995377230 TOP/DRAWER 08/02...
  • Page 9 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF337BCA TOP/DRAWER PART NO DESCRIPTION 316110201 Carriage,low broil 316236401 Liner,low broil 316110800 Shield,broiler 316237600 Shield,low broil ,top 316238900 Panel,drawer ,stainless 316129100 Fastener,push-in nut ,nylon ,spacer 316081900 Pan,broiler 316082000 Insert,broiler pan 316111502 Glide,low broil ,chassis 316111600...
  • Page 10 Publication No. FGF337BCA 5995377230 DOOR 08/02...
  • Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF337BCA DOOR PART NO DESCRIPTION 316240000 Glass,oven door ,black ,outer 316222711 Shield,wool ,black ,oven door 316237100 Glass,oven door ,clear ,inner 316230605 Liner,oven door 316001015 Screw,waf hd sq ,10-24 x 1.25 ,(2) ,handle mtg 316001016 Screw,handle mtg ,10-12 X .750 316008401...

  • Page 12: Wiring Schematic

    Publication No. FGF337BCA 5995377230 WIRING SCHEMATIC 08/02...

  • Page 13: Wiring Diagram

    FGF337BCA Publication No. 5995377230 WIRING DIAGRAM # = Fast-moving Parts 08/02 * = Non-Illustrated Parts...
