Related Manuals for LG MS-1944WS
Summary of Contents for LG MS-1944WS
- Page 1 MICROWAVE OVEN OWNER’S MANUAL PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING. MS-1944W MS-1944WS P/No. : MFL06441703...
-
Page 2: Precautions
Precautions Precautions to avoid possible exposure to excessive microwave energy. You cannot operate your oven with the door open due to the safety interlocks When heating liquids, e.g. soups, sauces and beverages in your microwave built into the door mechanism. These safety interlocks automatically switch off oven, overheating the liquid beyond boiling point can occur without evidence of bubbling. -
Page 3: Table Of Contents
Conte ten n ts ts How the Microwave Oven Works Precautions Contents Microwaves are a form of energy similar to radio and television waves and Unpacking & Installing 4 ~ 5 ordinary daylight. Normally, microwaves spread outwards as they travel Setting the Clock through the atmosphere and disappear without effect. -
Page 4: Unpacking & Installing 4
Unpacking & By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your Installing oven make sure you remove all accessories and packing. - Page 5 Plug your oven into a standard household socket. Open your oven door by pulling the DOOR HANDLE. Make sure your oven is the only appliance Place the ROLLER REST inside the oven and place the connected to the socket. If your oven does not operate GLASS TRAY on top.
-
Page 6: Setting The Clock
Setting the Clock You can set either 12 hour clock or 24 hour clock. In the following example I will show you how to set the time for 14:35 when using the 24 clock. Make sure that you have removed all packaging from your oven. Make sure that you have correctly installed your oven as described earlier in this book. -
Page 7: Child Lock
Child Lock Press STOP/CLEAR. Your oven has a safety feature that Press and hold STOP /CLEAR until “ L” appears on the display and BEEP prevents accidental running of the oven. sounds. The CHILD LOCK is now set. Once the child lock is set, you will be unable to use any functions and no The time will disappear on the display if you have set the clock. - Page 8 min. min. sec. sec. START/Q-START. START/Q-START.
-
Page 9: Micro Power Cooking
Micro Power Your microwave oven is equipped with 5 power levels to give you maximum flexibility and control over cooking. Level The table below shows the examples of food and their recommended cooking power levels for use with this microwave oven. POWER LEVEL POWER LEVEL POWER OUTPUT... -
Page 10: Two Stage Cooking
min. min. min. min. min. min. min. min. START/Q-START. START/Q-START. -
Page 11: Quick Start
Quick In the following example I will show you how to set 2 minutes of cooking on high power. Start Press STOP/CLEAR. T/Q-START four times to select 2 minutes on HIGH power. Press START/Q-START The QUICK START feature allows you to Your oven will start before you have finished the fourth press. -
Page 12: Auto Cook 12
Auto In the following example I will show you how to cook 0.5 kg of jacket potato. Cook P P r r ess ess STOP/CLEAR. Press AUTO o one time. AUTO COOK allows you to cook most of your favorite food easily by selecting the “AC-1”... - Page 13 CATEGORY WEIGHT LIMIT UTENSIL FOOD TEMP. INSTRUCTIONS Choose medium sized potatoes 170 -200g. 1. JACKET POTATO 0.1 kg ~ 1.0 kg On glass tray Room Temp. Wash and dry potatoes. Pierce the potatoes several times with fork. Place the potatoes on the glass turntable. Adjust weight and press start.
-
Page 14: Auto Defrost 14
Auto The temperature and density of food varies, I would recommend that the food is checked before cooking commences. Pay particular attention to large joints of meat and chicken, some foods should not be completely thawed before cooking. For example fish cooks so quickly that it is sometimes better to begin cooking while still Defrost slightly frozen. - Page 15 AUTO WEIGHT DEFROST GUIDE * Food to be defrosted should be in a suitable microwave proof container and place uncovered on the glass turntable. * If necessary, shield small areas of meat or poultry with flat pieces of aluminum foil. This will prevent thin areas becoming warm during defrosting. Ensure the foil does not touch the oven walls.
-
Page 16: Quick Defrost 16
Quick Use this function to thaw only 0.5kg of Minced meat very quickly. This will require a standing time to allow the center to thaw. In the following example will show you how to defrost 0.5kg of forzen minced meat. Defrost Press STOP/CLEAR. - Page 17 QUICK DEFROST GUIDE Use this function to defrost quickly for minced meat. Remove the meat completely from it’s wrapping. Place the mince onto a microwave-safe plate. When BEEP, at this point remove the mince from the microwave oven, turn the mince over and return to the microwave oven. Press start to continue. At the end of the program remove the mince from the microwave oven, cover with foil and allow to stand 5-15 minutes or until completely thawed.
-
Page 18: More Or Less Cooking
More or Less In the following example I will show you how to change the preset of Auto Cook programme for a longer or Cooking shorter cooking time. Press STOP/CLEAR. Set the required Auto Cook programme. If you find that your food is over or (Select weight of food) undercooked when using the Auto Cook programme. -
Page 19: Heating Or Reheating Guide
Heating or Reheating To heat or reheat successfully in the microwave, it is important to follow several guidelines. Measure the amount of food in order to determine the time needed to reheat. Arrange the food in a circular pattern for best results. Room Guide temperature food will heat faster than refrigerated food. -
Page 20: Fresh Vegetable Guide
Fresh Vegetable Guide Cook time Standing Cook time Standing Vegetable Amount Instructions Vegetable Amount Instructions (at HIGH) Time (at HIGH) Time Artichokes 2 medium 1 /2 Trim. Add 2 tsp water and 2 tsp juice. 2~3 minutes Corn, Fresh 2 ears 4 ~ 8 Husk. -
Page 21: Important Safety Instructions
WARNING Important safety instructions Please ensure cooking times are correctly Read carefully and keep for future reference set as over cooking may result in FIRE and subsequent DAMAGE to the OVEN. 1 Do not attempt to tamper with, or make any adjustments or repairs to the 10 Small amounts of food require shorter cooking or heating time. -
Page 22: Microwave-Safe Utensils
Microwave-safe Utensils Never use metal or metal trimmed utensils in your Paper microwave oven Paper plates and containers are convenient and safe to use in your microwave oven, Microwaves cannot penetrate metal. They will bounce off any metal object in the provided that the cooking time is short and foods to be cooked are low in fat and oven and cause arcing, an alarming phenomenon that resembles lightning. -
Page 23: Food Characteristics & Microwave Cooking 23
Food characteristics& Microwave cooking Moisture content of food Keeping an eye on things Since the heat generated from microwaves tends to evaporate moisture, relatively dry food The recipes in the book have been formulated with great care, but your success in such as roasts and some vegetables should either be sprinkled with water prior to cooking preparing them depends on how much attention you pay to the food as it cooks. - Page 24 Food characteristics & Microwave cooking. Stirring To Clean Your Oven Stirring is one of the most important of all microwaving techniques. In conventional cooking, food is stirred for the purpose of blending. Microwaved food, however, is stirred in order to 1 Keep the inside of the oven clean spread and redistribute heat.
-
Page 25: Questions & Answers
Questions & Answers Q What’s wrong when the oven light will not glow? Q Is it possible to pop corn in a microwave oven? A There may be several reasons why the oven light will not glow. A Yes, if using one of the two methods described Light bulb has blown below Door is not closed... -
Page 26: Plug Wiring Information/Technical Specifications
Plug wiring information/ Technical Specifications Warning Technical Specification This appliance must be earthed MS-1944W /MS-1944WS The wires in this mains lead are colored in accordance with the following codes Power Input 230 V AC / 50 Hz BLUE ~ Neutral...
