  • Page 1 All manuals and user guides at all-guides.com Turbo Sound Sound Equalizer New Structure Design CL-21M40MQ...
  • Page 2 All manuals and user guides at all-guides.com © Samsung Electronics Co., Ltd. Sep. 2006 This Service Manual is a property of Samsung Electronics Co.,Ltd. Printed in Korea Any unauthorized use of Manual can be punished under applicable AA82-03964A International and/or domestic law.

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Table of Contents Chapter 1 Precaution 1-1 Safety Precautions ............1-1 1-2 Servicing Precautions .
  • Page 4 All manuals and user guides at all-guides.com Chapter 9 PCB Diagram 9-1 Main Board ..............9-1 9-2 CRT Board .

  • Page 5: Chapter 1 Precaution

    When Check the AC power cord for possible damages. Keep voltage exceeds the specified limits, check each special the part or the lead away from any heat-emitting part. materials. Samsung Electronics...
  • Page 6 Critical safety parts should be bracketed with ( Use only regular parts for replacements (in particular, flame resistance and dielectric strength specifications). Irregular parts or materials may cause electric shock or fire. Samsung Electronics...

  • Page 7: Servicing Precautions

    5. Check for insulation between the blade of the AC plug 10. The sharp edges of the metal material may cause and that of any conductive materials (i.e. the metal physical damage, so ensure wearing protective gloves panel, input terminal, earphone jack, etc). during the repair. Samsung Electronics...

  • Page 8: Static Electricity Precautions

    These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Samsung Electronics...

  • Page 9: Installation Precautions

    5. Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause fire or electric shock. Samsung Electronics...
  • Page 10 All manuals and user guides at all-guides.com MEMO Samsung Electronics...

  • Page 11: Chapter 2 Product Specification

    - TDA9377PS/N3/A: CVBS, Video and Sound Signal Processing , Controls the operation of the overall main board. - TDA7297SA : Sound Signal Amplify - KA5Q0765RTH-YDTU : Power Supply TR - TUNER-F/S;TDQ-6F/13F2S(tuner) : RF signal processing , Output IF signal Samsung Electronics...

  • Page 12: Key Features

    All manuals and user guides at all-guides.com Product Specification 2-2 Key Features Model CL-21M40MQ Voltage AC110V Frequency of Operation 60HZ 622 x489.5x472 Dimensions (mm/inches) 24.48x19.25x18.58 Weight (Kg/ lbs) 25.8/56.6 H/W Configuration - 21 AK CRT adopted Picture - System : SECAM/NTSC4.43/NTSC3.58...

  • Page 13: Specifications Analysis

    All manuals and user guides at all-guides.com Product Specification 2-3 Specifications Analysis Model 21M16 CL-21M40MQ Chassis KS9A KS9C Design Screen Size 21" 21" Pure Flat CRT DNIe Jr. Comb Filter Velocity Modulation Picture Video Noise Reduction Auto Kinetic Bias Color Tone Control...

  • Page 14: Accessories

    Product Specification 2-4 Accessories Accessories Item Item code Remark Remote Control AA59-00385A Batteries 4301-000121 Owner's Instructions AA68-03810A Samsung Service Safety Guide Manual AA68-03242F center Warranty Card AA68-03727A Video Cable / Audio Cable Antenna Cable Internal shopping mall Component Cable Optical Cable...

  • Page 15: Chapter 3 Alignment & Adjustment

    Some of the contents may be changed subject to the sales location and the product specifications. 2. When replacing the Main Board : Focus adjustment, screen voltage setting and W/B adjustment are all required. 3. When replacing the CRT Ass'y : No adjustments required. Samsung Electronics...

  • Page 16: How To Access Service Mode

    When failing to enter Service Mode, repeat the procedure above. 2. The initial screen of Service Mode. ADJUST OPTION G2-ADJUST CHCKSUM RESET T-FMTNUS 3. Functions of the Keys within Service Mode MENU Show all menus Move the cursor to select an item. Adjust the selected configuration value Samsung Electronics...

  • Page 17: Factory Data

    The underlined are items applied during the service adjustment. None of the others should be adjusted. 1.T-FMTNUS Item Adjust/Fix Initial Remark Adjust Adjust Adjust Adjust Adjust Adjust Adjust Adjust Adjust Adjust MVOL RPO0 RPO1 FMWS AGCS SCBT DNSR DSBT DCDL DBLR DBLB Samsung Electronics...
  • Page 18 Start Language English English at time of purchase Hotel Mode Blue Screen Blue Screen when there is no source signal V-Chip AV Option AV1/2/DVD/SV AV1/2/DVD Back Jack Option 3.White Balance Item 21"FLAT Remark Hight Light 275/265/45FL Low Light 275/265/1.5FL Samsung Electronics...
  • Page 19 All manuals and user guides at all-guides.com Alignment & Adjustment Samsung Electronics...

  • Page 20: Service Adjustment

    MUTE 1 8 Power On " Display the Lion pattern. using the remote control and enter Factory Mode. Adjust the VA, VS,VSL and HS items so Enter Deflection Mode. that the width becomes 5 and the height becomes 4. Samsung Electronics...
  • Page 21 Adjust the V-Linearity and V-SC settings so that the intervals of the horizontal lines become uniform. When the adjustments are complete, display the Lion pattern and check that the picture size has not been changed. If there is no change, finish the adjustments. Samsung Electronics...

  • Page 22: Replacements & Calibration

    3-5 Replacements & Calibration 3-5-1 Adjusting the Focus 1. Display the CROSS Hatch pattern. 2. Turn the Focus clockwise to the optimal position. 3. Slowly turn the Focus clockwise so that the cross line is the most clearly displayed. Samsung Electronics...
  • Page 23 MUTE 1 8 2 Power On " to enter Service Mode. 2. Turn to toshiba pattern 3. Use remocon come into " G2 Adjust" mode by hand or automatically. 4. Turn Screen VR of FBT and confirm the characters below changed to GREEN. Samsung Electronics...
  • Page 24 4. When the adjustment is finished, check the following checklist. - If there is a spot on the screen when turning the TV set off/on, adjust the Screen Voltage again. - If there is a ghost line on the screen, adjust the Screen Voltage again. 3-10 Samsung Electronics...
  • Page 25 All manuals and user guides at all-guides.com...

  • Page 26: Cl21M40Mqgxxao

    C-FILM,LEAD-PEF 2.2nF,5%,100V,TP,5.5X10X C235 2305-000289 C-FILM,LEAD-PEF 220nF,5%,63V,TP,-,5mm C236 2305-000289 C-FILM,LEAD-PEF 220nF,5%,63V,TP,-,5mm C237 2401-002619 C-AL 47uF,20%,25V,GP,TP,5x11,5 C238 2305-000412 C-FILM,LEAD-PEF 470nF,5%,63V,TP,-,5mm C239 2202-000796 C-CERAMIC,MLC-AXIAL 1NF,10%,50V,Y5P,TP,3 C240 2305-000412 C-FILM,LEAD-PEF 470nF,5%,63V,TP,-,5mm C241 2401-000302 C-AL 100uF,20%,25V,GP,TP,6.3x11,5 C242 2305-000665 C-FILM,LEAD-PEF 100nF,5%,63V,TP,7.5x4.0x C243 2202-000127 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,25V,Y5V Samsung Electronics...
  • Page 27 C-AL 33uF,20%,50V,WT,-,6.3x11mm,2.5 C803 2305-000665 C-FILM,LEAD-PEF 100nF,5%,63V,TP,7.5x4.0x C804 2301-000016 C-FILM,LEAD-PEF 22nF,5%,100V,TP,7.2x4.5x C805 2301-000408 C-FILM,LEAD-PEF 2.7nF,5%,50V,TP,5.5x7x3m C806 2301-001435 C-FILM,LEAD-PPF 1.5nF,5%,1.2kV,TP,15x8x1 C810 2301-000016 C-FILM,LEAD-PEF 22nF,5%,100V,TP,7.2x4.5x C811 2201-000991 C-CERAMIC,DISC 0.56NF,10%,2KV,Y5P,TP,7.5 C812 2401-000262 C-AL 100uF,20%,160V,HR,TP,16x25,7.5 C813 2401-002290 C-AL 47uF,20%,160V,GP,TP,13x20,5 C814 2201-000599 C-CERAMIC,DISC 0.56NF,10%,500V,Y5P,TP,5. Samsung Electronics...
  • Page 28 DIODE-ZENER MTZJ5.6B,5.4-5.7V,500mW,DO-3 DZ212 0403-001373 DIODE-ZENER MTZJ5.1A,4.85-5.03V,500mW,DO DZ213 0403-000509 DIODE-ZENER MTZJ5.6B,5.4-5.7V,500mW,DO-3 DZ214 0403-001373 DIODE-ZENER MTZJ5.1A,4.85-5.03V,500mW,DO DZ215 0403-000509 DIODE-ZENER MTZJ5.6B,5.4-5.7V,500mW,DO-3 DZ216 0403-000509 DIODE-ZENER MTZJ5.6B,5.4-5.7V,500mW,DO-3 DZ217 0403-000720 DIODE-ZENER MTZJ9.1B,8.57-9.01V,500mW,DO DZ301 0403-001328 DIODE-ZENER MTZJ22A,20.15-21.2V,500mW,DO DZ302 0403-001328 DIODE-ZENER MTZJ22A,20.15-21.2V,500mW,DO DZ303 0403-000700 DIODE-ZENER TZP33A,5%,1000mW,DO-41,TP Samsung Electronics...
  • Page 29 EY818 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H EY819 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H EY820 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H EY821 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H EY822 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H EY827 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H EY830 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H EY833 6042-000002 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H F101 2901-000297 FILTER-EMI ON BOARD -,3A,-,3.5x5mm,TP,- Samsung Electronics...
  • Page 30 Q201 0501-000283 TR-SMALL SIGNAL KSA539,PNP,400mW,TO-92,T Q202 0501-000389 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,T Q203 0501-000283 TR-SMALL SIGNAL KSA539,PNP,400mW,TO-92,T Q204 0501-000389 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,T Q208 0501-000389 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,T Q211 0501-000283 TR-SMALL SIGNAL KSA539,PNP,400mW,TO-92,T Q401 AA96-02906A ASSY HEAT SINK P AA62-00145A,SCREW,ST200 S.N.A Samsung Electronics...
  • Page 31 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM R291 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM R293 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM R301 2001-000016 R-CARBON(S) 1OHM,5%,1/2W,AA,TP,2.4X6.4MM R302 2008-001076 R-FUSIBLE(S) 1.8ohm,5%,2W,AF,TP,3.9x10mm R303 2008-000290 R-FUSIBLE(S) 2.4ohm,5%,2W,AF,TP,3.9x10mm R304 2008-000252 R-FUSIBLE(S) 0.47ohm,10%,1/2W,AF,TP,2.5x R305 2008-000252 R-FUSIBLE(S) 0.47ohm,10%,1/2W,AF,TP,2.5x R306 2001-001050 R-CARBON(S) 1.5KOHM,5%,1/2W,AA,TP,2.4X6. R307 2004-001371 R-METAL(S) 1.5Kohm,1%,1/2W,AA,TP,2.4x6.4 Samsung Electronics...
  • Page 32 1KOHM,5%,1/2W,AA,TP,2.4X6.4M R821 2001-001131 R-CARBON(S) 33KOHM,5%,1/2W,AA,TP,2.4X6.4 R822 2004-001983 R-METAL(S) 2.49Kohm,1%,1/2W,AA,TP,2.4x6. R823 2001-000037 R-CARBON(S) 330OHM,5%,1/2W,AA,TP,2.4X6.4 R824 2008-001033 R-FUSIBLE(S) 10ohm,5%,2W,AF,TP,3.9x10mm R825 2008-000264 R-FUSIBLE(S) 1ohm,5%,1W,AF,TP,3.9x10mm R827 2003-002009 R-METAL OXIDE(S) 390ohm,5%,2W,AF,TP,3.9x R828 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM R829 2001-000563 R-CARBON 27KOHM,5%,1/8W,AA,TP,1.8X3.2MM R830 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...

  • Page 33: Cl21M40Mqgxxao

    PIN-STAPLE AUTO,33X17.8X2.4,H18,33X17.8X S.N.A ASSY ACCESSORY M0045 AA92-11838D ASSY ACCESSORY CL21M40MQGXXAO,MI,KS9C S.N.A M0045 AA96-04373D ASSY ACCESSORY CL21M40MQGXXAO,MI,KS9C S.N.A T0251 3721-000136 PLUG-CONVERSION 2P,4.0mm,N,NI T0524 6902-000009 BAG PE HDPE,T0.03,L400,W240,TRP,8,2,PE M S.N.A T0903 AA26-90001F TRANS MATCHING -,300ohm/75ohm,NTSC,40-89 T0116 AA39-40001B CABLE RCA ,3P,1500MM,RED/WHT/YEL,RCA,RCA Samsung Electronics...
  • Page 34 -,ABS,V0,-,BLK,- S.N.A T0527 AA65-30018A CLAMPER CORE-WIRE DONG-A,NYLON-66,-,-,-, S.N.A T0527 AA65-30111A CLAMPER CORE-WIRE ALL MODEL,NYLON,V0,WHT S.N.A T0066 AA96-20109C ASSY POWER CORD -,CP2/NO(4.0),H/C300,KKP T0061 3811-001609 WIRE-PVC CU BCWA,300V,ROLL,-,#22,BLK 0.15 S.N.A T0268 AA39-10006X CBF-POWER CORD -,-,KKP419C,3P,-,-,BLK,-, T0010 AA61-20284A HOLDER P-CORD,PP,-,-,-,BLK,VO,KE-002 S.N.A Samsung Electronics...
  • Page 35 All manuals and user guides at all-guides.com MEMO 5-10 Samsung Electronics...

  • Page 36: Chapter 6 Troubleshooting

    1) Check that the power cord is correctly connected to electrical source equipment. 2) Check that the Tact Switch has been pressed. 3) Check that the signal cable is properly connected. 4) Check that channel setting has been set. Samsung Electronics...

  • Page 37: Troubleshooting Procedures By Error Modes

    - The System Blcok has the last output terminal, TDA9377PS/N3, which shows the internal Test pattern. - The Power Block supplies power to the Deflection Block - The System Block receives all signal inputs, the signal-processed signal is sent to CRT Ass'y. Deflection and focus are controlled by the Deflection Block Samsung Electronics...

  • Page 38: Troubleshooting Procedures By Ass'y

    All manuals and user guides at all-guides.com Troubleshooting 6-3 Troubleshooting Procedures by ASS'Y 1. NO Power 2. NO Video Samsung Electronics...
  • Page 39 All manuals and user guides at all-guides.com Troubleshooting 3. NO Sound 4. Fly Back Lion Badness CN603 CN602 CN701A CN401 GT804,GT805 PD801S Samsung Electronics...

  • Page 40: Troubleshooting By Blocks

    The RF / CTV signal is transmitted to the Tuner of the Main Board If the signal is not received, check the following items - Power supply: 5V, 33V - Check for RF defects: Check the IF & CVBS output - Check for AUDIO defect: Check the SIF Signal output Samsung Electronics...
  • Page 41 All manuals and user guides at all-guides.com Troubleshooting 2. Micom Diagnosis - Power supply : 3.3V, 5V,8V - Check for input defects : Y/C(CVBS), 480i Y/Pb/Pr signal Samsung Electronics...
  • Page 42 The signals are sent to UOC and the selected signals are output. If the signal input or output does not work, check the following items. - Check for input defects: Check the Micom input pin. - Check for output defects: Check JA701A (for RF/AV) or JA702(for comp) Samsung Electronics...
  • Page 43 4. TDA7297SA (Audio Processor) Diagnosis This receives the signal from the MICOM(TDA9377PS/N3) and outputs the signal in 10W + 10W sound. - Power supply : 12.5V - Check for input defects : AMP-R,AMP-L - Check for output defects : L+, L-, R+,R- Samsung Electronics...
  • Page 44 5. MSP3425G-B8(Audio Processor) Diagnosis This receives the signal from the Audio Processor (TDA9377PS/N3) and outputs the signal in TDA9377PS/N3 - Power supply : 12.5V - Check for input defects : B+8V, A+5V - Check for output defects : DACM_R,DACM_L Samsung Electronics...
  • Page 45 If the voltage is measured, the problem is a defect in the FBT unit. (When you don't have an oscilloscope, and you can hear the high-voltage sound, you can determine that the horizontal TR is normal.) Is the vertical input waveform output from the TDA9377PS/N3/A VDP Pin. 6-10 Samsung Electronics...

  • Page 46: Chapter 7 Block Diagram

    All manuals and user guides at all-guides.com Block Diagram 7. Block Diagram 7-1 Overall Block Diagram Samsung Electronics...

  • Page 47: Partial Block Diagram

    7-2-1 System Board Block Diagram < > r e t - e r < > - V / & e v i o c i A - t e v i < > & & o i t × Samsung Electronics...

  • Page 48: Chapter 8 Wiring Diagram

    8. Wiring Diagram 8-1 Overall Wiring signal AUDIO S IG NAL power E AR S IG NAL C R T P O W E R S UP P L Y R G B S IG NAL AV S IG NAL Samsung Electronics...

  • Page 49: Pin Connection

    All manuals and user guides at all-guides.com Wiring Diagram 8-2 Pin Connection MAIN TO SPEAKER TO EARPHONE TO CRT RGB HEATER B+180V TO SIDE AV V-Out V-In L-Out R-Out TU01S L-In R-In RCA 9P Samsung Electronics...

  • Page 50: Chapter 9 Pcb Diagram

    * CN401 : This is a 4 pin port connected to the DY, and supplies voltage for Deflection. * GT804,GT805 : This is a port connected to the D-Coil surrounding the CRT. * PD801S : This is a 3 pin port connected to the AC power cable. It is connected to the power cable socket. Samsung Electronics...
  • Page 51 Connected to the Side Sound Port PIN No. Pin Name PIN No. Pin Name CN501A CN701A Connected to the CRT Ass'y Connected to the AV Ass'y PIN No. Pin Name PIN No. Pin Name V-Out V-In L-Out R-Out HEATER L-In R-In B+180V Samsung Electronics...

  • Page 52: Crt Board

    * CN501A : This is a 9 pin port to receive the R/G/B output signals and power from the Main Board. 9-2-3 CRT Board Connector Pin CN501A Connects the R/G/B signal ar for the CRT PIN No. Pin NAME HEATER B+180V Samsung Electronics...
  • Page 53 All manuals and user guides at all-guides.com MEMO Samsung Electronics...
  • Page 54 All manuals and user guides at all-guides.com...
  • Page 55 All manuals and user guides at all-guides.com...
  • Page 56 All manuals and user guides at all-guides.com...
  • Page 57 All manuals and user guides at all-guides.com...
  • Page 58 All manuals and user guides at all-guides.com Operation Instruction & Installation 11. Operation Instruction & Installation 11-1 Product Features and Functions 11-1-1 Front Panel Buttons Samsung Electronics 11-1...
  • Page 59 All manuals and user guides at all-guides.com Operation Instruction & Installation 11-1-2 Connection Jacks (Side) 11-2 Samsung Electronics...
  • Page 60 All manuals and user guides at all-guides.com Operation Instruction & Installation 11-1-3 Connection Jacks (Rear) Samsung Electronics 11-3...
  • Page 61 All manuals and user guides at all-guides.com Operation Instruction & Installation 11-1-4 Remote Control 11-4 Samsung Electronics...
  • Page 62 Tap the upper part of the Back Cover 2 or 3 times and pull the Back Cover to separate it from the unit. : Disassemble the product after disconnecting the power cord and discharge the unit to prevent an electric shock and damage to the product due to static electricity. Samsung Electronics 12-1...
  • Page 63 Press the clip down completely and pull the connec- tor. Separate the D-Coil and power cable from the Front Cabinet and Main Board. To separate the power cord, slide the fixing clip and lift the cable up. 12-2 Samsung Electronics...
  • Page 64 Separate the cables connecting the FBT and the CRT. : Since there may be a remaining high-voltage current within the CRT, take care not to touch the CRT hole with metal or a part of yourself when separating the cables. Samsung Electronics 12-3...
  • Page 65 : Take care when separating the wires because pulling the wires by force may damage the socket. In addition, separate the wires on a flat and clean surface so as to prevent scratching of the material and the PCB. 12-4 Samsung Electronics...
  • Page 66 * The signals were processed by MICOM, then output. * This chassis's MICOM is same as KS9A, it use UOC CHIP. * The external port be consists of AV input and output,each of them has three channels,Audio are White and Red, Video is Yellow Video(Yellow). Samsung Electronics 13-1...
  • Page 67 * TDQ-6F/13F2S(TUNER):Receives the RF signal and output a fixed IF to Micom. * Micom Block consists of five aspects as: Video & Sound IF Processor, Video Processor, Display and Deflection Processor and Controller, OSD,Text Processing. * TUNER-F/S;TDQ-6F/13F2S(tuner) : RF signal processing , Output IF signal 13-2 Samsung Electronics...

  • Page 68: Power

    All manuals and user guides at all-guides.com Circuit Description 13-2-2 Power Block AM P 13V Audio AM P EEPROM M ICOM A+5V B+3.3V IC802(7632) B+8V B+5V Q804(KSC2073-H2) 125V A+5V ± 16.5V Vertical AM P B+33V TUNER B+180V Video AM P SCREEN FOCUS HEATER Samsung Electronics 13-3...

  • Page 69: Micom

    Main Board Items Descriptions Remarks MICOM TDA9377PS/N3/A,T-FMTNUS Tuner TDA9377PS/N3/A Trans Switching TRANS SWITCHING;,CS21S5T,80~280V,PM2,PL3 SMPS KA5Q0765RTH-YDTU Vertical DEF. LA78040N Horizontal DEF. ST2001HI(028Y) SOUND AMP TDA7297SA, SGS-TOMSON 10W+10W EEPROM 24C161,SAMSUNG VIDEO AMP TDA6109JF, Philips Regulator IC-MULTI REG.;7632,SIP,10P,-,PLASTIC,3.3 A+5V,B+3.3V,B+8V Regulator 13-4 Samsung Electronics...
  • Page 70 The mirror returns to a blank state so that no stains or after-images are left. The SAMSUNG SKY500N model has both an ANYNET port and a SERVICE jack port. Because the shape of the ANYNET port on the DLP TV is the same as that of the SERVICE Confusion between the jack port of the SKY500N, it fails to turn the TV off after a connection has been reported.
  • Page 71 Ex: For LCD 15:9 devices, "Wide" is displayed on the OSD instead of "16:9". 4. The picture size can be changed even in the blue screen. However, the picture size should be controlled by the product specifications if the change is impossible due to hardware restrictions. 14-2 Samsung Electronics...

  • Page 72: Audio

    VHF refers to TV channels 2 to 13, and UHF refers to TV chan- tinguished by the white (left) and red colors (right). nels 14 to 69. External Input External Input is connecting video devices such as a VCR, camcorder, DTV receiver, DVD, etc. as a video source. Samsung Electronics 14-3...
  • Page 73 All manuals and user guides at all-guides.com MEMO 14-4 Samsung Electronics...
