PRO DUCT NO.
FGC36S9HBA
WIRING DI A GRAM # - 318047100
OWNER'S GUIDE # - 318200651
IN STAL LA TION INSTR. # - 318063914
FRIGIDAIRE HOME PROD UCTS
7075 ORDAN DRIVE
MISSISSAUGA, ON TARIO
CANADA, L5T 1K6
TEL: (905) 565-9200
FAC TORY PARTS CAT A LOG
OFF
OFF
OFF
SIMMER
SIMMER
OFF
OFF
Galler y
PROFESSIONAL SERIES
FAC TORY NO.
COLOR
3775742399061
BLACK
Pub li ca tion No.
5995324539
990609
-EN/SER VICE
377
GAS COOKTOP
MARKET
U.S.A.
GAS COOKTOP
Model No.
FGC36S9H
©1999 White Con sol i dated In dus tries,
Inc.
