Introduction Identification of Parts Freezer Compartment Door Rack Automatic Icemaker Lamp Shelf (steel) Door Rack Drawer Door Rack Lower Cover Where to install Unstable installation may cause vibration and Strong noise. If the oor to install the refrigerator on and even floor is not even, make the refrigerator level by rotating the height adjusting screw.
Page 7
Where water Select a place where a water supply can be supply can be easily connected between the automatic ice easily connected maker and dispenser. in a dry place Installing the refrigerator in a wet or damp area may cause rust and may be an electrical hazard.
Installation Door removal Warning Electric Shock Hazard Disconnect electrical supply to refrigerator before installing. Failure to do so could result in death or serious injury. If your entrance door is too narrow for the refrigerator to pass through, remove the refrigerator door and pass the refrigerator laterally.
Move the Push the refrigerator sideways through the Refrigerator entrance door as shown in the right picture. Door replacement Mount the doors in the reverse order of removal after the refrigerator is brought to the installation area. NOTE: Check the direction of the lever hinge. Correct Feed water tube installation Before...
Page 10
Installation Connect 1. Unplug refrigerator or disconnect power. the Tubing to 2. Turn OFF main water supply. Turn on the nearest faucet to relieve the pressure Water Line 3. Find a 1/2-inch to 1-1/4-inch vertical COLD water pipe near the refrigerator. •...
Operation Instruction Guide Connect the Tubing Before making the connection to the refrigerator, be sure the refrigerator to the Refrigerator power cord is not plugged into the wall outlet. If your refrigerator does not • have a water filter, we recommend installing one.
Installation Height adjustment (First identify your screw type, it could vary) If the freezer Make them level by inserting at (- type) driver into the groove of the left height adjusting compartment door screw and rotating it clockwise ( is lower than the refrigerator compartment door If the freezer...
Operation Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting The Temperatures and Functions...
Page 14
Operation 1. Buzzer sound mute Mode 2. Display Power saving Mode 3. To change temperature display from Fahrenheit (ºF) to Celsius (ºC) press and hold IMPORTANT: "ICE PLUS" button can be showed as "Express Frz" button. If your refrigerator has "Express Frz"...
Page 15
The automatic icemaker can automatically make 8 cubes at a time, Automatic Icemaker 120~150 pieces per day. This quantity may vary by circumstance, including ambient temperature, door opening, freezer load. etc. Icemaking stops when the ice storage bin is full. If you don't want to use automatic icemaker, turn the icemaker switch to OFF.
Page 16
Operation The Other Ambient Temperature Display Window. Functions Temperature is displayed only between 16 F ~ 120 F. Temperature less than 15 F is indicated with LO and temperature more than 121 F is indicated with HI. Door open warning A warning tone will sound 3 times at thirty-second intervals if the refrigerator or freezer door is left open for more than sixty seconds.
Page 17
6 Filter Condition (filter replacement There is a replacement indicator light for the water filter cartridge on the dispenser. cycle) Display Water filter needs replacement once every six Function months. Filter light comes on to let you know when to replace filter.
Operation Shelf Shelf Height The refrigerator compartment shelf is movable so that you can place it at a height Adjustment according to space requirement of foods. Slide Shelf Pull the shelf ahead and take off it while lifting both front and rear part. Fix Shelf, Folding Shelf Lightly lift up the front part of shelf to pull it ahead and then take off it while lifting the...
Operation Location of Foods (Refer to Identification of Parts) Wine Holder Store wine. Snack Drawer Store small foods such as bread, snacks, etc. Freezer Store various frozen foods such as meat, fish, Compartment ice cream, frozen snacks, etc. Shelf Store small packed frozen food. Freezer Temperature is likely to increase as door Compartment...
Storing Foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining it's freshness and flavor. Do not store food which spoils easily at low temperatures, such as bananas and melons. Allow hot food to cool prior to storing, placing hot food in the refrigerator could spoil other food, and lead to higher energy consumption.
How to Dismantle Parts NOTE Dismantling is done in the reverse sequence of assembly. • Be sure to unplug the power plug before dismantling and assembly. Never apply severe force to dismantle parts. Parts may be damaged. Freezer Separate the lamp by pulling it out Compartment slightly striking Lamp...
Page 22
Care and Maintenance To remove the lamp cover, press the protrusion under the lamp cover to the front and Lamp in then pull the lamp cover out. Refrigerator Turn the bulb counterclockwise. Max. 40 W bulb for refrigerator is used and can be Compartment purchased at a service center.
General Information Vacation Time During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan to store the refrigerator, remove all food, disconnect the power cord, clean the interior thoroughly, and Block the doors open to prevent mold and mildew.
Care and Maintenance Troubleshooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Occurrence Running of refrigerator Refrigerator control is off.
Page 25
Possible cause Occurrence Refrigerator Thermostat is keeping the refrigerator compressor at a constant temperature. does not run. Temperatures are too cold Temperature in the Freezer control is set too cold freezer is too cold but the refrigerator temperature is satisfactory. Temperature in the Refrigerator control is set too cold.
Page 26
Care and Maintenance Occurrence Sound and noise Louder sound Today’s refrigerators have increased levels when storage capacity and maintain more refrigerator is on. even temperatures. Louder sound Refrigerator operates at higher pressures levels when during the start of the ON cycle. compressor comes on.
Page 27
Occurrence Possible cause Odors in refrigerator Interior needs to be cleaned. Food with strong odor is in the refrigerator. Some containers and wrapping materials produce odors. Opening/Closing of doors/Drawers Door(s) will not Food package is keeping door open. close Door(s) will not Door was closed too hard, causing other close door to open slightly.
Page 28
Care and Maintenance Occurrence Ice has melted and frozen around auger Dispenser will due to infrequent use, temperature not dispense fluctuations and/or power outrages. Ice dispenser Ice cubes are jammed between the ice is jammed maker arm and back of the bin. Ice cubes are frozen together.
Page 29
LG REFRIGERATOR LIMITED WARRANTY - USA Your LG Refrigerator will be will repaired or replaced, at LG’s option, if it proves to be defective in material or workmanship under normal use, during the warranty period ("Warranty Period") set forth below, effective from the date ("Date of Purchase") of original consumer purchase of the product.
