Summary of Contents for LG GWL227YUQA
- Page 2 Table of contents Introduction Installation Operation Suggestion on food storage Care and maintenance...
-
Page 3: Important Safety Instruction
Entry The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. -
Page 4: Child Entrapment
Child entrapment DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer: warning Take off the doors but leave the shelves in place so that children may not easily climb inside. The appliance is not intended for use by young children or infirm persons without supervision. - Page 5 *Dispenser model Freezer Compartment Automatic Icemaker Shelf or Drawer Lamp Shelf or Drawer Drawer Door rack Drawer (2 or 3) Door rack Lower cover NOTE Parts, features, and options vary by model. Your model may not include every option. • Refrigerator Compartment Milk product corner...
-
Page 6: Where To Install
Where to Install Select a good 1. Place your appliance where it is easy to use. location 2. Avoid placing the unit near heat sources, direct sunlight or moisture. 3. To ensure proper air circulation around the fridge -freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall. -
Page 7: Door Removal
Door removal Electric Shock Hazard Warning Disconnect electrical supply to refrigerator before installing. Failure to do so could result in death or serious injury. If your access door is too narrow for the refrigerator to pass through, remove the refrigerator door and pass the refrigerator laterally. Remove lower Remove the lower cover by lifting upward, and cover and... -
Page 8: Door Replacement
Pass the Pass the refrigerator laterally through the access refrigerator door as shown in the right figure. Door replacement Mount them in the reverse sequence of removal after they pass through the access door. Feed water pipe installation (*Dispenser model only) Before Automatic ice maker operation needs water pressure of 147~834 kPa (1.5~8.5 installation... -
Page 9: Height Adjustment
Installation Height adjustment If the freezer Level the door by inserting flat ( - type) driver into the groove of the left height adjusting screw and rotate it clockwise ( ). compartment door is lower than the refrigerator compartment door If the freezer Level the door by inserting flat ( - type) driver into the groove of the right height compartment door... -
Page 10: Adjusting The Temperatures And Functions
Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions *Non dispenser model Optional Function display board... - Page 11 *Dispenser model Refreshment Center Button Refreshment Center (hidden) NOTE Your model may not include every option. •...
- Page 12 Display power This function save the display power saving Press the FREEZER and EXPRESS FRZ. buttons simultaneously and hold them for 5 (on some model) seconds until the Ding sounds. All LED/LCDs will then turn ON, then OFF. When the power saving mode is activated, the display will remain off until the next time the door is opened.
-
Page 13: Dispenser Use (On Some Model)
Dispenser use Select among crushed ice, water, and cubed ice and press the push switch with a (on some model) glass or other container. Crushed Ice Light the crushed ice lamp by pressing the selection button. Reference : Hold your cup in place for a couple of seconds after dispensing ice or water so •... - Page 14 When ice maker Ice is lumped together does not operate When ice is lumped together, take the ice lumps out of the ice storage bin, break smoothly them into small pieces, and then place them into the ice storage bin again. When the ice maker produces too small or lumped together ice, the amount of water supplied to the ice maker need to adjusted.
- Page 15 The other Door open warning functions 3 times of warning sounds at the interval of 30 seconds if a minute passes with the door of refrigerator and the hombar door opened or completely closed. Please contact with the local service center if warning continue to sound even after closing the door.
-
Page 16: Refreshment Center (Applicable To Some Models Only)
Refreshment center (Applicable to some models only) How to use Open the refreshment center door. You can access the refreshment center without opening refrigerator door and thus saving electricity. Inner lamp is lit in refrigerator compartment when the refreshment center door opens. Thus it is easy to identify the contents. -
Page 17: Folding Shelf
Shelf (Applicable to some models only) Folding Shelf You can store taller items such as a gallon container or bottles by simply pushing in front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf. Wine holder (Applicable to some models only) Wine holder Bottles can be stored laterally with... -
Page 18: Humidity Control In The Vegetable Compartment
Humidity control in the vegetable compartment The humidity can be controlled by adjusting the humidity control switch to the left/right when storing vegetables or fruits. High humidity HUMIDITY CONTROL HIGH Low humidity HUMIDITY CONTROL HIGH Convert into a vegetable or meat compartment (Applicable to some models only) The bottom drawer in the refrigerator can be converted into a vegetable or meat compartment... -
Page 19: Miracle Zone Temperature Transition Corner (Applicable To Some Models Only)
Miracle Zone Temperature Transition Corner (Applicable to some models only) By pressing the button, store vegetables, fruits or other types of food such as meat to be defrosted, raw fish, etc. Temperature Change at Miracle Zone (Applicable to some models only) Method to Use You can select optimum temperature range depending on... -
Page 20: Location Of Foods
Location of foods (Refer to identification of parts) Wine holder Store wine. Snack drawer Store small foods such as bread, snacks, etc.. Freezer Store various frozen foods such as meat, fish, compartment ice cream, frozen snacks, etc.. shelf Store small packed frozen food. Freezer Temperature is likely to increase as door compartment... -
Page 21: Freezer Compartment
Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, and melons. -
Page 22: How To Dismantle Parts
How to dismantle parts NOTE Dismantling is done in the reverse sequence of assembly. • Be sure to unplug the power plug before dismantling and assembly. Never apply severe force to dismantle parts. Parts may be damaged. Separate the lamp by pulling it out ➂ while slightly Freezer pressing ➀... -
Page 23: Refreshment Center
Lamp in To remove the lamp cover, press the protrusion under the lamp cover to the front and then pull the lamp cover out. refrigerator Turn the bulb counterclockwise. Max. 40 W bulb for refrigerator is used and can be compartment purchased at a service center. -
Page 24: General Information
General information Vacation time During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation. -
Page 25: Troubleshooting
Trouble shooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Occurrence Possible cause Runing of refrigerator Refrigerator control is off. - Page 26 Occurrence Possible cause Refrigerator Thermostat is keeping the refrigerator compressor at a constant temperature. does not run. Temperatures are too cold Temperature in the Freezer control is set too cold freezer is too cold but the refrigerator temperature is satisfactory. Temperature in the Refrigerator control is set too cold.
- Page 27 Possible cause Occurrence Sound and noise Louder sound Today’s refrigerators have increased levels when storage capacity and maintain more refrigerator is on. even temperatures. Louder sound Refrigerator operates at higher pressures levels when during the start of the ON cycle. compressor comes on.
- Page 28 Occurrence Possible cause Odors in refrigerator Interior needs to be cleaned. Food with strong odor is in the refrigerator. Some containers and wrapping materials produce odors. Opening/Closing of doors/Drawers Door(s) will not Food package is keeping door open. close. Door(s) will not Door was closed too hard, causing other close.
- Page 29 Occurrence Possible cause Dispenser will Ice has melted and frozen around auger not dispense due to infrequent use, temperature ice. fluctuations and/or power outrages. Ice dispenser Ice cubes are jammed between the ice is jammed. maker arm and back of the bin. Ice cubes are frozen together.
-
Page 30: Warranty Certificate
Warranty Certificate For offer a 24-month warranty for this apparatus... - Page 31 Warranty conditions for refrigerator 1. The warranty period begins 2. During the warranty period, we will are not covered by this warranty. 4. We decide whether to make repairs, exchange or replace parts. 5. The warranty is nullified 6. Always keep the original packaging, 7.
