Operation
Setpoint
PLM_Channel
TargMaxImprtP -30,000 to +30,000
TargMinImprtP -30,000 to +30,000
EnaIslanding
EnaExtTransfer
ExtTransVolt 50.0 - 200.0
ExtTransTime 1-360 Seconds
Export Override
PLM_Disable
CalOverride
CTTurnsRatio 1,500 - 3,000 Turns
16
Table 3-4. Inverter Device Settings
Range Default
0 - 12 1
0
0
on or off on
on or off off
95
15
on / off off
on / off off
on / off off
1,500
Channel for REbus communications. All devices in a system must use the
same channel (except REbus Beacon). Do not set equipment to channel 0
unless performing Multiple Inverter System Commissioning Procedure.See
installation manual for more details.
Maximum Threshold for importing power before the battery will discharge
in Self-Supply Mode to offset.
Minimum power import maintained by charging the battery from the grid in
Allows system to island, providing backup power during a grid outage.
Turn on if an external automatic transfer switch (ATS) has been installed to
operate with the Inverter.
Minimum voltage from the utility that must be present for the inverter to
reconnect an ATS back to the grid.
Length of time the inverter will wait to trigger an ATS to reconnect to the
utility upon sensing grid voltage return.
Formerly called Zero Export, this setting will inhibit the PWRcell system
from exporting power to the grid.
This setting will disable the power line communications coming from the
Overrides inverter logic for automatic detection of included Generac cur-
rent transformers (CTs).
Allows a different turns ratio to be set for specific CTs.
Description
Supply Mode.
inverter.
