Model: HT554PH (HT554PH-D0, SH54PH-F/S/C/W)
HT554TH (HT554TH-D0, SH54TH-F/S/C/W)
HT554TM (HT554TM-D0, SH54TM-S/C/W)
Full HD up-scaling (1080p)
(Go to page 10)
Portable In
(Go to page 17)
FOR THE WARRANTY TERMS & CONDITIONS, PLEASE REFER TO BACK COVER OF THIS MANUAL.
As an E
S
NERGY
TAR
LG has determined that this
product or product models meet
the E
S
®
guidelines for
NERGY
TAR
energy efficiency.
E
NERGY
S
TAR
®
is a U.S. registered mark.
P/NO : MFL60020721
12:05 PM
Page 1
5.1ch ez Set-up
(Go to page 15)
®
Partner,
USB Direct Recording
(Go to page 17)
Advertisement
Table of Contents
Related Manuals for LG HT554PH
Summary of Contents for LG HT554PH
- Page 1 HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Model: HT554PH (HT554PH-D0, SH54PH-F/S/C/W) HT554TH (HT554TH-D0, SH54TH-F/S/C/W) HT554TM (HT554TM-D0, SH54TM-S/C/W) Full HD up-scaling (1080p) (Go to page 10) Portable In (Go to page 17) FOR THE WARRANTY TERMS & CONDITIONS, PLEASE REFER TO BACK COVER OF THIS MANUAL.
-
Page 2: Safety Precaution
This product is manufactured to comply with EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC. European representative : LG Electronics Service Europe B.V. Veluwezoom 15, 1327 AE Almere, The Netherlands (Tel : +31-036-547-8940) -
Page 3: Table Of Contents
Some functions of this unit are controlled by TV’s remote control when this unit and LG TV with SIMPLINK are connected through HDMI connection. • Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power Off, etc. -
Page 4: Setting Up
Setting up The speakers are detached from the speaker stands. Assembling the Speakers (HT554TH, HT554PH) 1 Attach the speakers to the speaker stands by rotating the screw. 2 If you want to arrange the speaker cable, draw the speaker cable through the hole on the speaker. -
Page 5: Hooking Up The Unit
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Hooking up the unit a Connect jacks on the unit and your TV (DVD player or Digital Device etc.) using the cables. Video Out connection Connect the VIDEO OUTPUT (MONITOR) jack on the unit to the corresponding input jack on your TV using a Video cable. -
Page 6: Hooking Up The Unit
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Hooking up the unit HDMI Out connection Connect the HDMI OUTPUT jack on the unit to the HDMI input jack on a HDMI compatible TV using a HDMI cable. Digital Audio in connection Page 6 Hooking up the unit - more you can do Resolution Setting You can change the resolution for component video... -
Page 7: Remote Control
Controlling the TV. You can control the sound level, input source, and power switching of LG TVs as well. Hold POWER (TV) and press PR (+/–) button repeatedly until the TV turns on or off. -
Page 8: Main Unit
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Main Unit Open/Close DVD/CD Disc Drawer PORT. IN port The PORT. In port means you can connect an audio device to play trough the surround sound speakers. USB port The USB port allows you can connect a memory device to your DVD player. -
Page 9: Osd Initial Language Settings - Optional
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM OSD Initial language settings - Optional During the first use of this unit, the initial language setup menu appears on your TV screen. You must complete initial language selection before using the unit. English will be selected as the initial language. - Page 10 HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Adjust the display settings TV Aspect – Select which screen aspect to use based on the shape of your TV screen. [4:3]: Select when a standard 4:3 TV is connected. [16:9]: Select when a 16:9 wide TV is connected. Display Mode –...
-
Page 11: Setting The Sound Mode
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Adjust the lock settings To access the lock options, you must enter the 4-digit password. If you have not yet entered a password you are prompted to do so. Enter a 4-digit password. Enter it again to verify. If you make a mistake while entering number, press CLEAR to delete numbers. -
Page 12: Displaying Disc Information
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Displaying Disc Information 1 Press DISPLAY: 2 Select a item: 3 Adjust the Display menu settings: 4 To return the exit: Displaying Disc Information - more you can do U U u u You can select an item by pressing and change or select the setting by I I i i pressing... - Page 13 HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Fast forward or fast reverse Press SCAN (m or M) to play fast forward or fast reverse during playback. You can change the playback speed by pressing SCAN (m or M) repeatedly. Press PLAY (B) to continue play at normal speed. Selecting a subtitle language DivX During playback, press SUBTITLE (...
-
Page 14: Viewing Photo Files
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Creating your own program You can play the contents of a disc in the order you want by arranging the order of the music files on the disc. The program is cleared when the disc is removed. Select a desired music file then press PROG./MEMO. -
Page 15: Listening To The Radio
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Listening to the radio Be sure that FM aerial is connected. 1 Turn the power on: 2 Select FM: 3 Select a radio station: 4 To ‘save’ a radio station: A preset number will show in the display. 5 To select a ‘saved’... -
Page 16: Listening To Music From Your Usb Device
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Listening to music from your USB device The advantage of connecting your portable USB player through the system’s USB port is that the USB device can be controlled from the system. 1 Connect the USB device to the unit using a USB cable (not supplied).: 2 Select the USB function: 3 Select a file from the menu:... -
Page 17: Recording Music From Cd To Your Usb Device
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Recording music from CD to your USB device 1 Connect the USB device to the unit: 2 Select a mode (DVD/CD) in which you want to record: 3 Start the recording: If you want to record desired music file in Disc to USB. -
Page 18: Language Codes
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Afar 6565 Croatian 7282 Afrikaans 6570 Czech 6783 Albanian 8381 Danish 6865 Ameharic 6577... -
Page 19: Troubleshooting
HT554TH-D0_BGBRLL_ENG_0721 3/18/09 12:05 PM Troubleshooting CAUSE PROBLEM No power The power cord is disconnected. No picture The TV is not set to receive the DVD signal. The video cables are not connected securely. There is little or no sound Equipment connected via the audio cable is not set to receive DVD signal output. -
Page 20: Types Of Playable Discs
You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live File System, you cannot use it on LG players. (Mastered/Live File System : Disc format system for Windows Vista) -
Page 21: Specifications
Net Dimensions (W x H x D) 275 x 1053 x 275 mm 350 x 105 x 93 mm Net Weight 3.4 kg 1.08 kg Designs and specifications are subject to change without prior notice. Page 21 Specifications Speakers (HT554PH) Front Speaker Type 2 Way 3 Speaker 4 Ω Impedance Rated Input Power 70 W Max. - Page 22 3/18/09 12:05 PM ● LG Electronics U.K. Ltd. will provide the following services in order to expedite this Guarantee. 1. All faulty components which fail due to defective manufacture will be replaced free of charge for a period of 12 months from the original date of purchase.
