E-Lead EL-HA1 Manual

Hide thumbs Also See for EL-HA1:
Table of Contents

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
Introduction
E-Lead EL-HA1 is a small, high performance, and highly stable product.
Provides simple & convenient hands-free operation to eliminate the distraction mobile
phone communication.
I.
Attention
We strongly recommend using the following mobile handsets. The listed
handsets already passed our highly standard function and audio clearance test. Product
supplier is not responsible for fault communication if the service provider's signal is
too weak.
II. Accessory
1. EL-HA1 mainframe
2. Connect cable
III.
Product Feature
1. EL-HA1 support both Headset and Hands-Free Bluetooth Profile up to 3
devices for pairing at the same time.
1

Advertisement

Table of Contents
loading

Related Manuals for E-Lead EL-HA1

Summary of Contents for E-Lead EL-HA1

  • Page 1 II. Accessory 1. EL-HA1 mainframe 2. Connect cable III. Product Feature 1. EL-HA1 support both Headset and Hands-Free Bluetooth Profile up to 3 devices for pairing at the same time.

  • Page 2: Function Key

    All manuals and user guides at all-guides.com 2. Stereo auto switch mute/on: EL-HA1 will automatically mute the stereo during incoming calls and switch to audio phone; and auto switch back when the call ends. 3. Red/Blue status indicator, Yellow-Green backlight: Different light colors indicate incoming/talking/pairing/error status;...

  • Page 3: Advanced Functions

    All manuals and user guides at all-guides.com Advanced Functions: Function Key Combination Function Key Others Manually search Not linked with Press “Pick Up” paired device handsets After linked with handsets, Handsets must Voice dial activation Press “Pick Up” support voice dial function Only available...
  • Page 4 All manuals and user guides at all-guides.com V. Application 1. A Bluetooth handset is required. 2. Up to 10 meters talking range (No barrier space). The further the distance, the weaker the signal is. VI. Recommended pairing sequence and handset devices Please note that different handsets may require different Bluetooth pairing process.
  • Page 5 All manuals and user guides at all-guides.com 1. Select 2. Select device 3. Searching for 4. Select device 5. Enter pass key controlpanel\Bl device (0000) uetooth 6. Pairing succeed 4. NOKIA 3650 1.Enter Bluetooth 2. Set Bluetooth On 3. Press right Searching 5.
  • Page 6 All manuals and user guides at all-guides.com 5. Sony Ericsson Z600/T610 1. Select 2. Select Bluetooth 3. Select [My devicies] 4. Select [New device] [Connectivity] 5. Searching for 6. Select device 7. Enter Passkey: 0000 8. Pairing succeed device 6. Sony Ericsson P800 1.
  • Page 7 All manuals and user guides at all-guides.com 1. Select [Connect] 2. Select 3. Select [Discover 4. Searching for 5. Select Bluetooth [Bluetooth] & Pair] Bluetooth device device for pairing 6. Enter Passkey : 7. Pairing succeed 0000 8. SIMENS S55 1.
  • Page 8 Motorola A760, A768 A760 Attention: Above Bluetooth phones are tested by E-Lead. Please check phone owner’s manual for correct pairing if not on the list. VIII. Description of application environment 1. Wired signal has higher priority than Bluetooth function, which will shut off automatically when wired.

  • Page 9: Troubleshooting

    All manuals and user guides at all-guides.com IX. Trouble Shooting Frequent ask questions and trouble shooting Situation Possible cause Solution Key pad not responding; Power is off Turn the car key to ACC position or no back light ignition. illumination Loose connection or bad cable Please contact local HONDA maintenance.

  • Page 10: Specification

    All manuals and user guides at all-guides.com X. Specification Frequency：2402~2480MHz Transmission Power：Max 4dBm Operate temperature：-20°C~+60°C；Storage temperature： -30°C~+85°C Voltage：DC 4V~6V Power consumption：0.1A (MAX) Bluetooth module: 1. Comply with Bluetooth Headset Profile v1.1；Handfree Profile v1.0。 2. Support: NOKIA 6310、6310i、8910i、8910、3650, 6600, Sony Ericsson T68、T68i、P800、T610、Z600, SIEMENS S55、Motorola A760, A768, V500, V600, Sharp GX-31 and other Bluetooth Headset-AG Profile v1.1 or Handfree-AG Profile v1.0 handsets。...
  • Page 11 All manuals and user guides at all-guides.com 15.21 Federal Communications Commission (FCC) Statement The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment.
