Premier designs Wind Garden 25684 Assembly Instructions

A
Hub 1
Sleeve 1
Rod 1
Velcro Seam
B
Main
Strut A
Upper Support Pole
C
Rod 3
Empty Red Golf Cart Spinner
sku #25684
Main
Star Lock Hub
Strut B
Push Star Lock Hub firmly onto
Plastic Tip of Support Pole
Plastic Tip
NOTE: To make insertion
process easier, place bottom
of Upper
of Support Pole on a hard,
Support Pole
flat surface and push down
on Star Lock Hub
Main Strut A
Hub
Strut Assembly
Velcro Seam
Step 1
Remove Your Empty Red Golf Cart Spinner from
the package. Open the Velcro Seam along the
bottom of the Golf Cart.
Sleeve 2
Step 2
Slide Rod 1 and 2 through the opened Velcro
Rod 2
Seam into the corresponding Sleeve 1 and 2
as shown in Diagram A. Push Rod 1 so that
securely fits into the Hub 1 at the top left of the
frame structure as shown in Diagram A.
Step 3
Identify and align Main Strut A, Star Lock Hub,
and Main Strut B according to Diagram B. Insert
the Main Strut A rod into the Star Lock Hub
horizontal fitting securely. Insert the Main Strut
B rod into the Star Lock Hub horizontal fitting
securely.
Step 4
Slide the narrow plastic tipped end of the Upper
Support Pole into the Star Lock Hub. Push down
on the hub until The Support Pole locks into
place and cannot be removed.
Step 5
Position the Strut Assembly in between the
pieces of fabric and insert Rod 1 into the Hub of
Main Strut A as shown in Diagram C.
Step 6
Insert Rod 3 in between the pieces of fabric
so that it is positioned at an angle from the
bottom corner below the black bumper to just
above the Main Strut A Hub. Close Velcro Seam.
Completed internal Strut Assembly should
match Diagram C.
assembly
instructions
