Frigidaire GLEB30M9FSA Installation Instructions Manual

MICROWAVE/ WALL OVEN COMBINATION
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
Your new wall oven has been designed to fit a limited variety of cutout sizes to make the job of installing
easier. The first step of your installation should be to measure your current cutout dimensions and
compare them to the cutout dimensions chart below for your model. You may find little or no cabinet
work is necessary.
Do not remove spacers (if equipped) on the side walls and/or on the back of the built-in
oven. These spacers center the oven in the space provided. The oven must be centered to prevent
excess heat buildup that may result in heat damage or fire.
NOTES:
1. Base must be capable of supporting 225 pounds (102 kg).
2. Allow at least 21" (53.3 cm) clearance in front of oven for door
depth when it is open.
3. Dimension G (cutout depth) is
critical to the proper installation of
the built-in oven. If the oven
decorative trim does not butt
against the cabinet verify
dimension G to assure it is the
required depth.
* Suggested distance from floor
is 11½" (29.2 cm).
Minimum required distance is 4
½" (11.4 cm)
MODEL
27" (68.6 cm) Wall Oven
30" (76.2 cm) Wall Oven
MODEL
24
27" (68.6 cm) Wall Oven
28½ (72.4)
30" (76.2 cm) Wall Oven
All dimensions are stated in inches and (cm).
Printed in United States

INSTALLATION INSTRUCTIONS

B
Door Open
(see note 2)
A
PRODUCT DIMENSIONS
A
27 (68.6)
30 (76.2)
CUTOUT DIMENSIONS AND CABINET WIDTH
Min. F Max.
7 / (63.2) 25¼ (64.1)
8
29 (73.7)
1" (2.5 cm) 1" (2.5 cm)
Min. Min.
C
40-15/16" 40-15/16"
(104 cm) (104 cm)
11½" 11½"
(29.2 cm) (29.2 cm)
Spacer
D
2" (5 cm) Wide Wood
Spacer if Needed
Figure 1
B
42¾ (108.6) 24
42¾ (108.6) 28¼ (71.8)
Min.
G (Min.)
1
41 / (104.5)
23½ (59.7)
8
1
41 / (104.5)
23½ (59.7)
8
1
I
G
F
H
1¼" 1¼"
(3.2 cm) (3.2 cm)
Junction Box
Min. Min.
(right or left side)
C
5
/ (62.5) 24½ (62.2)
8
24½ (62.2)
.
H Max
41¼ (104.8)
27 1 / (68.9) Min
8
41¼ (104.8)
1
30 / (76.5) Min
8
P/N 318201521 (0503) Rev. A
English – pages 1-6
Español – páginas 7-12
Hole for
Cable
(right or
left side
depending
on model)
3" (7.6 cm) 3" (7.6 cm)
Max. Max.
Electrical
D
I
