Alfa Romeo STELVIO Quick Start Manual

AUTOMATIC TRANSMISSION - CONTROLS
CENTRAL CONSOLE
1) SHIFT LEVER
2) PARK BUTTON
3) REVERSE UNLOCK
SELECTING GEARS
• R: move the lever forward while pressing (3) to select REVERSE
• D: move the lever back while pressing (3) to select DRIVE
• P: press (2) to select PARK
• N: from R or D, move the lever to select NEUTRAL
• - M +: from D, move the lever to the left to select MANUAL
• + shifts to a higher gear
• - shifts to a lower gear
STEERING WHEEL
STEERING WHEEL PADDLES
• Left paddle (-): pull the left paddle to shift to a lower gear
• Right paddle (+): pull the right paddle to shift to a higher gear
• Both paddles: pull both simultaneously to engage NEUTRAL
• Right paddle (+) and Brake pedal: engages DRIVE.
Note : you can see the mode/gear engaged on the instrument panel.
CRUISE CONTROL
1) ENABLE/DISABLE: press the button to enable/disable the system.
2) SPEED RESET: press the RES button to reset the speed to the previous setting.
3) SET SPEED: move the SET switch up/down to set the cruising speed. When the car has
reached the desired speed, move the SET switch up/down to enable the device. The car
will automatically maintain the selected speed when the accelerator is released. You can
increase/decrease the set speed by operating the SET switch again.
If needed (when overtaking for instance), you can accelerate simply by pressing the
accelerator; when you release the pedal, the car goes back to the speed stored previously.
Pressing the brake pedal lightly will disable the Cruise Control.
4) SETTING THE DISTANCE BETWEEN VEHICLES (Active Cruise Control): press the button
to set the distance between your car and the vehicle ahead at which the system will react.
Each time you press the button, the setting decreases by one bar (shorter). The system
can be set to 4 different reaction levels.
ELECTRICALLY ADJUSTABLE FRONT SEATS
The electrical adjustment is only allowed when the ignition device is turned to ON and for
about 60 seconds after it is turned to STOP.
1) Longitudinal, height and angle adjustment of the seat.
2) Backrest angle adjustment.
3) Lumbar adjustment.
4) Backrest width adjustment.
ALFA DNA SYSTEM
The car is equipped with the Alfa DNA system. By operating the selector (on the central
tunnel), this system allows you to select different car response modes according to your
driving style and the road conditions:
d = Dynamic (sports driving mode)
n = Normal (mode for driving in normal conditions)
a = Advanced Efficiency (ECO driving mode for maximum fuel savings).
On the instrument panel display, the different modes are characterised by different colours:
• Dynamic – Red,
• Normal - Blue,
• Advanced Efficiency – Green.
For further information, refer to the Owner Handbook.
INSTRUMENT PANEL DISPLAY
You can see the screens for the various driving modes (Dynamic, Normal and Advanced
Efficiency) on the instrument panel display.
You can select the screens in rotation by pressing the button on the right stalk.
The display shows:
• The current speed
• The longitudinal/lateral acceleration
• Trip A
• Trip B
"Trip A" and "Trip B" allow you to see the following values:
• Distance travelled
• Average fuel consumption
• Average speed
• Active trip
• Fuel level gauge
To reset the values, press and hold down the button on the right stalk.
