Frigidaire FEB556CE Factory Parts Catalog

Electric wall oven
Hide thumbs Also See for FEB556CE:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRO DUCT NO.
FEB556CESF
FEB556CEBF
FEB556CETF
WIRING DI A GRAM #- 318046207
OWNER'S GUIDE
#- 318008802
IN STAL LA TION INSTR. # - 318064300
FRIGIDAIRE HOME PROD UCTS
7075 ORDAN DRIVE
MISSISSAUGA, ON TARIO
CANADA, L5T 1K6
TEL: (905) 565-9200
FAC TORY PARTS CAT A LOG
ELEC TRIC WALL OVEN
FAC TORY NO.
COLOR
38254431G6016
WHITE
38254431G6066
BLACK
38254431G6036
AL MOND
Pub li ca tion No.
5995317095
990118
-EN/SER VICE
377
MARKET
U.S.A.
U.S.A.
U.S.A.
ELEC TRIC WALL OVEN
Model No.
FEB556CE
©1999 White Con sol i dated In dus tries, Inc.
All rights re served

Advertisement

loading

Related Manuals for Frigidaire FEB556CE

Summary of Contents for Frigidaire FEB556CE

  • Page 1 FEB556CETF WIRING DI A GRAM #- 318046207 OWNER’S GUIDE #- 318008802 IN STAL LA TION INSTR. # - 318064300 FRIGIDAIRE HOME PROD UCTS 7075 ORDAN DRIVE MISSISSAUGA, ON TARIO CANADA, L5T 1K6 TEL: (905) 565-9200 FAC TORY PARTS CAT A LOG ELEC TRIC WALL OVEN FAC TORY NO.
  • Page 2 Pub li ca tion No. FEB556CE 5995317095 CON TROL PANEL LAP23G0039A 01/99...

  • Page 3: Control Panel

    A = FEB556CE (FEB556CESF) B = FEB556CE (FEB556CEBF) C = FEB556CE (FEB556CETF) POS. NO 20 # # = Func tional Part * = Non-Illustrated Part FEB556CE CON TROL PANEL PART NO DE SCRIP TION 5303302286 A B C Sup port backguard RH...
  • Page 4 01/99 FEB556CE CAVITY / EL E MENTS Pub li ca tion No. 5995317095 LA9923V04...
  • Page 5 A = FEB556CE (FEB556CESF) B = FEB556CE (FEB556CEBF) C = FEB556CE (FEB556CETF) POS. NO 141# # = Func tional Part * = Non-Illustrated Part FEB556CE CAVITY / ELEMENTS PART NO DE SCRIP TION 5303301263 A B C Shield oven-top 5303299366...
  • Page 6 FEB556CE Pub li ca tion No. 5995317095 DOOR LA9923D03 01/99...
  • Page 7 A = FEB556CE (FEB556CESF) B = FEB556CE (FEB556CEBF) C = FEB556CE (FEB556CETF) POS. NO # = Func tional Part * = Non-Illustrated Part FEB556CE DOOR PART NO DE SCRIP TION 318026100 Trim-oven door white 318026510 Trim-oven door black 318026101 Trim-oven door almond...

  • Page 8: Wiring Diagram

    Pub li ca tion No. FEB556CE 5995317095 WIRING DIAGRAM 01/99...
