CUSTOMIZING OPERATION
Modify and Save the Light Levels of a Scene
1. Change lighting levels as desired by pressing
2. Press and hold the scene button until the LED flashes once (about
2 seconds) to save the new settings.
Removing or Adding Devices to a Scene
1. Press on the PSWCR until the LED begins flashing (about 2 seconds).
2. Press the scene button that you wish to program. LEDs on all wireless
LightSense™ devices begin to flash. You now have 5 minutes to complete
this process.
3. To include or exclude a device in the scene press
LED changes color. Yellow flashing LED = Included in the active scene
Green flashing LED = NOT included in the active scene
If you get to a device and it is NOT flashing, see TROUBLESHOOTING.
NOTE: You must include devices that are off in the room scene if you want
them to turn off when that scene is recalled.
4. Return to the PSWCR used in step 1. Press
LED stops flashing, then all the status LEDs in the house turn green.
Removing or Adding Devices to the
1. Press on the PSWCR until the LED begins flashing (about 2 seconds).
2. Tap the paddle on the PSWCR. The LEDs on all the LightSense wireless
devices begin to flash. You now have 5 minutes to complete this process.
3. To include or exclude a device press
changes color. Yellow flashing LED = Included in paddle operation
Green flashing LED = NOT included in paddle operation
If you get to a device and it is NOT flashing, see TROUBLESHOOTING.
4. Return to the PSWCR used in step 1. Press
status LED stops flashing, then all the status LEDs in the house turn green.
5. To test, tap on any room scene controller that is bound to the same room
to switch included devices to on (dimmers go to full bright).
Removing or Adding Devices to the
1. Press on the PSWCR until the LED begins flashing (about 2 seconds).
2. Tap the paddle on the PSWCR. The LEDs on all the LightSense wireless
devices begin to flash. You now have 5 minutes to complete this process.
3. See step 3 above.
4. See step 4 above.
5. To test, tap on any room scene controller that is bound to the same room
to switch or fade included devices to off (dimmers go to 0%).
10/23/08 10:49 AM
or on individual devices.
on the device until the
for 2 seconds – the status
Paddle "On" Function
on the device until the LED
for about 2 seconds – the
Paddle "Off" Function
