Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
PLD2885RFC0
Series
Built-in 24"
Color
stainless
Owner's Guide English 154575801
Owner's Guide Spanish 154575803
Owner's Guide French
154575802
Service Data Sheet
154495501
Energy Guide
154540025
Installation Instructions 154427301
Market
North America
Publication No.
5995470753
06/07/25
(EN/SERVICE/ECL)
821
24-INCH BUILT-IN
DISHWASHER
Model No.
PLD2885RF
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.
