Frigidaire FDB634CF Factory Parts Catalog
24" built in dishwasher
Hide thumbs
Also See for FDB634CF:
- Factory parts catalog (14 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
PRODUCT NO.
FDB634CFS1
MARKET
North America
SERVICE DATA SHEET # - 154296902
OWNER'S GUIDE # - 154255602
WIRING DIAGRAM # - 154296902
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
FDB634CF
24" buikt-in
Publication No.
5995347027
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
white
001205
821
©2000 White Consolidated Industries, Inc.
All rights reserved
DISHWASHER
24" BUILT IN
DISHWASHER
Model No.
FDB634CF
Advertisement
Related Manuals for Frigidaire FDB634CF
Summary of Contents for Frigidaire FDB634CF
- Page 1 PRODUCT NO. BASE MODEL NO. FDB634CFS1 FDB634CF MARKET North America SERVICE DATA SHEET # - 154296902 OWNER’S GUIDE # - 154255602 WIRING DIAGRAM # - 154296902 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 FACTORY PARTS CATALOG...
-
Page 2: Control Panel
Publication No. FDB634CFS1 5995347027 CONTROL PANEL 12/00... - Page 3 POS. NO # = Fast Moving Part * = Non-Illustrated Part FDB634CFS1 CONTROL PANEL PART NO DESCRIPTION 154222701 Panel-control,white 154311101 Insert-control pnl 154295701 Timer 154095701 Screw-timer,thread rolling ,(2) 154131203 Shield-timer 154214701 Switch-selector,6 button 154248601 Shield-switch 5303318719 Screw,mtg. 154239501 Knob-timer,white 154283701 Vapor Weldment Assy 154229201 Seal-chamber...
- Page 4 Publication No. FDB634CFS1 5995347027 DOOR 12/00...
- Page 5 POS. NO 12 # # = Fast Moving Part * = Non-Illustrated Part FDB634CFS1 DOOR PART NO DESCRIPTION 154226002 Spring-door,(2) 154325201 Spring linkage,(2) 154093301 Screw-arm assy,(4) 154325304 Arm Assy,LH 154325303 Arm Assy,RH 154211501 Pin-arm 154079601 Nut-arm assy,(4) 154299002 Door-inner assy 154226601 Liner grate 154230101...
- Page 6 Publication No. FDB634CFS1 5995347027 12/00...
- Page 7 POS. NO 24 # 25 # 28 # 28A* 29 # # = Fast Moving Part * = Non-Illustrated Part FDB634CFS1 PART NO DESCRIPTION 154209301 Tub assy,w/frame parts 154211601 Strike-door 154211801 Gasket-tub 154041001 Screw,plask #1 ,10-10 x 9/16 154213401 Roller-tub 5303943103 Screw w/washer,(8) 154239801...
-
Page 8: Motor & Pump
Publication No. FDB634CFS1 5995347027 MOTOR & PUMP 12/00... - Page 9 POS. NO 24A* 70 # # = Fast Moving Part * = Non-Illustrated Part FDB634CFS1 MOTOR & PUMP PART NO DESCRIPTION 154247601 Heater 154289801 Shield-heater terminal 154106201 Nut-heater,(2) 154322501 Bracket-heater,(2) 154245901 Macerator 154245501 Cover-volute 154245801 Impeller 154282701 Screw,ss impeller 154246801 Gasket-sump 154335403 Housing-sump...
- Page 10 Publication No. FDB634CFS1 5995347027 FRAME 12/00...
- Page 11 POS. NO # = Fast Moving Part * = Non-Illustrated Part FDB634CFS1 FRAME PART NO DESCRIPTION 154219601 Valve-water 154208701 Brace-front 154322903 Toeplate-adjustable 154323003 Kickplate/Baffle Assy,black 5300808658 Screw,#8A x .375" 154294701 Screw,#7 plas .375 ,(6) ,disp. assy. 154210901 Screw-leveling 154209601 Cover-junction box 154227401 Guard-motor 5300808749...
- Page 12 Publication No. FDB634CFS1 5995347027 RACKS 12/00...
- Page 13 POS. NO # = Fast Moving Part * = Non-Illustrated Part FDB634CFS1 RACKS PART NO DESCRIPTION 154320904 Rack assy-lower 154295201 Basket-Silverware 154321104 Rack assy-upper 5300809974 Wheel & bracket assy,upper rack 5300809927 Cap-slide,(4) 154232701 Slide-rack,(2) 154174501 Wheel & bracket assy,lower rack 154304001 Base-funnel 154251801...
