Frigidaire FDB421RF Factory Parts Catalog
24" built-in dishwasher
Hide thumbs
Also See for FDB421RF:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
PRODUCT NO.
FDB421RFS6
MARKET
North America
SERVICE DATA SHEET # - 154370901
OWNER'S GUIDE # - 154392901
INSTALLATION INSTRUCTIONS # - 154329601
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
BASE MODEL NO.
SERIES
FDB421RF
Built-in 24"
Publication No.
5995352621
-EN/SERVICE /ECL
FACTORY PARTS CATALOG
COLOR
white
010418
©2001 White Consolidated Industries, Inc.
821
All rights reserved
DISHWASHER
24" Built-In
DISHWASHER
Model No.
FDB421RF
