To avoid risk of personal injury, property damage, or product damage due to the weight of this device and sharp
edges that may be exposed:
Air conditioners covered in this manual pose an excessive weight hazard. Two or more people are needed to
move and install the unit. To prevent injury or strain, use proper lifting and carrying techniques when moving unit.
Carefully inspect location where air conditioner will be installed. Be sure it will support the weight of the unit over
an extended period of time.
Handle air conditioner with care. Wear protective gloves whenever lifting or carrying the unit. AVOID the sharp
metal fins of front and rear coils.
Make sure air conditioner does not fall during installation.
NOTE:
These instructions describe installation in a typical wood framed window with a wood SLIDE-BY sash, or
installation in a metal CASEMENT window. Modification may be necessary when installing in windows made
differently than those shown in these instructions.
Meeting Electrical Requirements
WARNING:
Electrical ground is required on this appliance.
DO NOT ground to a gas line.
If cold water pipe is interrupted by plastic, non-metallic gaskets, or other insulating materials, DO NOT use for
grounding.
Check with a qualified electrician if you are in doubt as to whether the appliance is properly grounded.
DO NOT modify power supply cord plug. If it does not fit outlet, have a proper outlet installed by a qualified
electrician.
DO NOT have a fuse in the neutral or grounding circuit. A fuse in the neutral, or grounding circuit could result in
an electrical shock.
DO NOT use an extension cord with this appliance.
Failure to follow these instructions could result in electrical shock, serious injury, or death.
OBSERVE ALL LOCAL GOVERNING CODES AND ORDINANCES. DO NOT, UNDER ANY CIRCUMSTANCES,
NOTE:
If codes permit, and a separate grounding wire is used, it is recommended that a qualified electrician determine
that the grounding path is adequate and not interrupted by plastic, non-metallic gaskets, or other insulating
materials.
Installation Instructions
READ BEFORE INSTALLING UNIT
For Slider Casement Air Conditioners
1
Advertisement
Related Manuals for Frigidaire FRA103KT1
Summary of Contents for Frigidaire FRA103KT1
-
Page 1: Installation Instructions
To prevent injury or strain, use proper lifting and carrying techniques when moving unit. Carefully inspect location where air conditioner will be installed. Be sure it will support the weight of the unit over an extended period of time. -
Page 2: Preparing For Installation
Be sure it will support the weight of the unit. This appliance must be installed according to all applicable codes and ordinances. Handle air conditioner with care. AVOID sharp metal fins on front and rear coils. Make sure your air conditioner does not fall during installation. - Page 3 Installation Instructions Make sure you have all the necessary parts. Installation kit contents (FIG.3): Hardware Platform Support brace Adjustment bolt Hex flange nut - 1/4 Track seal Side channel seal Window sash seal Safety bracket NOTE: Use scale below to measure length of your screws. The scale will come in handy when separating screws for installation.
-
Page 4: Flange Nut
Installation Instructions Choose the proper window location. Choose a window that allows the cooled air to flow freely and directly into room(s) you wish to cool. Remember, it is difficult to move air around corners. Also, choose a window that is within 6 feet of an electrical outlet as shown (FIG.5). - Page 5 NOTE: DO NOT push or pull air direction louvers. Place air conditioner in window opening. As shown (FIG.17), it should sit on platform assembly so that window panel frame and cabinet side channels are against top and side window jambs.
-
Page 6: Alternate Window Jamb Applications
Installation Instructions Slide inner window sash firmly against side of the cabinet. Make sure not to peel the seal strips from the window track and cabinet side channels. If the panel frame does not fit snugly to the inner window sash, secure the panel frame holes for the screws. - Page 7 NOTE: A projection below the base of the air conditioner will require the rear of the platform to be 7/16” lower than the front to create the 3/16” slant from front to rear (FIG.25) .
- Page 8 NOTE: DO NOT push or pull air direction louvers. Place the air conditioner in the window opening as shown (FIG.31). It should sit on the platform assembly so that the window panel frame and the cabinet side channels are against the top and side window jambs. Side channels should overlap side window jambs equally.
