Page 1: Air Conditioner
USE & CARE MANUAL THIS AIR CONDITIONER IS EQUIPPED WITH A NEW INDUSTRY STANDARD POWER SUPPLY CORD WITH A TEST-RESET FUNCTION READ AND SAVE THESE INSTRUCTIONS AIR CONDITIONER MULTI-STEP SPEED ELECTRONIC CONTROL P/N 220201d038 SZ000302(En)-YaoKong(1018) 10/25/2004, 2:33 PM... -
Page 2: Warranty
Your product is protected by this warranty Your appliance is warranted by Electrolux. Electrolux has authorized Frigidaire Consumer Services and their authorized servicers to perform service under this warranty. Electrolux authorizes no one else to change or add to any of these obligations under this warranty. Any obligations for service and parts under this warranty must be performed by Frigidaire Consumer Services or an authorized Frigidaire servicer. -
Page 3: Table Of Contents
Model No. Serial No. Register Your Product The self-addressed PRODUCT REGISTRATION CARD should be filled in completely, signed and returned to the Frigidaire Company. Warranty Product Registration Normal Sounds Important Safety Instructions... -
Page 4: Important Safety Instructions
• If the air conditioner is to be installed in a window, you will probably want to clean both sides of the glass first. If the window is a triple-track type with a screen panel included, remove the screen completely before installation. -
Page 5: Operation Of Current Device
The power supply cord contains a current device that senses damage to the power cord. To test your power supply cord do the following: 1. Plug in the Air Conditioner. 2. The power supply cord will have TWO buttons on the plug head. Press the TEST button. You will notice a click as the RESET button pops out. - Page 6 Air Conditioner Features (continued) TO TURN UNIT ON: DO THIS: PRESS ON/ OFF PAD TO CHANGE TEMPERATURE SETTING: DO THIS: PRESS TO RAISE PRESS TO LOWER TO ADJUST FAN SPEEDS: DO THIS: PRESS TO SELECT: FASTER SLOWER SZ000302(En)-YaoKong(1018) NOTE: The following instructions represent the Touch Pad, the same instructions can be used for the Remote Control.
- Page 7 Air Conditioner Features (continued) TO USE AUTO COOL FEATURE: DO THIS: PRESS AUTO COOL TO OPERATE ON FAN ONLY: DO THIS: PRESS MODE BUTTON CHOOSE FAN ONLY TO USE THE ENERGY SAVER FEATURE: DO THIS: PRESS MODE BUTTON CHOOSE ENERGY SAVER...
- Page 8 Air Conditioner Features (continued) TIMER: DELAY STOP / START FEATURE DO THIS: PRESS TIMER BUTTON TO TURN UNIT OFF: DO THIS: PRESS ON/ OFF BUTTON Now that you have mastered the operating procedure, here are more features in your control that you should become familiar with.
-
Page 9: Care And Cleaning
• Or, instead of washing you may vacuum the filter clean. Cabinet Cleaning • Be sure to unplug the air conditioner to prevent shock or fire hazard. The cabinet and front may be dusted with an oil-free cloth or washed with a cloth dampened in a solution of warm water and mild liquid dishwashing detergent. -
Page 10: Avoid Service Checklist
Air movement sound. This is normal. If too loud, set to a slower FAN setting. Window vibration - poor installation. Refer to installation instructions or check with installer. Improper installation. Tilt air conditioner slightly to the outside to allow water drainage. Refer to installation instructions - check with installer.
