PRODUCT NO.
FAS153K1A1
WIRING DIAGRAM - # 309341601
OWNER'S GUIDE - # 309000825
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
BASE MODEL NO.
OWNER'S GUIDE
FAS153K1A
309000825
Publication No.
5995353603
-EN/SERVICE /DJH
ROOM AIR CONDITIONER
BTU-COOLING
15000BTU
ROOM AIR CONDITIONER
010511
345
©2001 White Consolidated Industries, Inc.
All rights reserved
Model No.
FAS153K1A
Advertisement
Related Manuals for Frigidaire FAS153K1A1
Summary of Contents for Frigidaire FAS153K1A1
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAS153K1A1 FAS153K1A WIRING DIAGRAM - # 309341601 OWNER’S GUIDE - # 309000825 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER OWNER’S GUIDE BTU-COOLING 309000825 15000BTU ROOM AIR CONDITIONER FAS153K1A Publication No. - Page 2 Publication No. FAS153K1A 5995353603 CABINET FRONT AND WRAPPER 08/01...
- Page 3 Grille,rear ,with rail 309631104 Link,vertical louver 309630804 Louver,horizontal 309633305 Louver Assy,horizontal 309631004 Louver 309631404 Filter-air,molded plastic 309633205 Front-cabinet,complete assy 309341003 Overlay,Frigidaire 309321401 Door-vent,actuator 309330404 Handle-vent,gray 309330202 Detent-vent 309630904 Panel,cabinet front 309342401 Enclosure,elec control mt 309350502 Remote Control,transmitter ,with batteries Publication No.
- Page 4 Publication No. FAS153K1A 5995353603 CONTROLS 08/01...
- Page 5 POS. NO 13 # 16 # 71 # 72 # # = Fast-moving Parts * = Non-Illustrated Parts FAS153K1A CONTROLS PART NO DESCRIPTION 309630403 Control Box 309623601 Bulkhead,control systeml 5303318963 Capacitor,370 V 5303015427 Screw,truss head ,8-18AB x 0.47 5303303077 Strap-capacitor 5304408752 Wiring Harness 309343111...
- Page 6 Publication No. FAS153K1A 5995353603 AIR HANDLING PARTS 08/01...
- Page 7 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAS153K1A AIR HANDLING PARTS PART NO DESCRIPTION 5303311048 Fan Blade,with clamp 3202975 Screw,10-16 x 0.72 ,square drive 309623201 Shroud-condenser,one piece 5303015311 Seal,fan housing ,lower 3015312 Screw,8-18AB x 0.500 309630605 Motor-fan,Heshan 309623401 Bulkhead,air system 309633001...
- Page 8 Publication No. FAS153K1A 5995353603 COMPRESSOR PARTS 08/01...
- Page 9 POS. NO 11 # 12 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAS153K1A COMPRESSOR PARTS PART NO DESCRIPTION 5303925103 Compressor,w/overload 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 5303272298 Gasket-cover,terminal 3206230 Cover-terminal 5303016697 Overload Protector 5303211017 Nut-terminal cover 309634103 Evaporator...
- Page 10 5995353603 POS. NO 08/01 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal-window frame,stuffer 5304414928 Frame,LH 309313303 Kit-window mounting,heavy duty 5304409250 Seal-top rail 5304414933 Retainer,accordian 5304414105 Bracket-support,RH 309313204 Kit-mounting support 5304409248 Hardware-mounting 5304414106 Bracket-support,LH 5304414929 Frame,RH 5304414930 Closure,accordian type ,window mount 5304414116 Rail,top 5303212504...
- Page 11 FAS153K1A Publication No. 5995353603 WIRING DIAGRAM # = Fast-moving Parts 08/01 * = Non-Illustrated Parts...
