PRODUCT NO.
FAH086J1T2
OWNERS GUIDE # - 309000823
P.O. Box 212378
Augusta, GA 30917
FACTORY PARTS CATALOG
BASE MODEL NO.
FAH086J1T
Publication No.
5995338539
000307
-EN/SERVICE /REP
VOLTS
BTU-COOLING
115
8000
Model No.
FAH086J1T2
©2000 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FAH086J1T2
Summary of Contents for Frigidaire FAH086J1T2
- Page 1 PRODUCT NO. BASE MODEL NO. FAH086J1T2 FAH086J1T OWNERS GUIDE # - 309000823 P.O. Box 212378 Augusta, GA 30917 Publication No. 5995338539 -EN/SERVICE /REP FACTORY PARTS CATALOG VOLTS Model No. FAH086J1T2 000307 ©2000 White Consolidated Industries, Inc. All rights reserved BTU-COOLING...
- Page 2 FAH086J1T2 CABINET FRONT AND WRAPPER 5/00...
- Page 3 POS. NO. 5/00 FAH086J1T2 CABINET FRONT AND WRAPPER PART NO. 309627504 309636101 309324004 309628004 309628104 309628204 309629405 309307011 5304410881 309631805 309629304 5304408740 DESCRIPTION WRAPPER-U BEND 18.5 BLD SCREEN-SAFETY 18.5 BLD LINK-VERT LOUVER LOUVERS-HORIZ LOUVER-VERT FILTER-MOLDED AIR FRONT ASSY 18.5 BLD...
- Page 4 FAH086J1T2 CONTROL PARTS 5/00...
- Page 5 POS. NO. 5/00 FAH086J1T2 CONTROL PARTS PART NO. DESCRIPTION 309628501 #BOX-CONTROL 5304408739 SWITCH-7POS GE 5304408746 CONTROL-AIR TEMP 309329801 #RETAINING CLIP 5303303576 Capacitor,370V, 30+7.5 5303285199 Screw,phillips, 8-18,sq. recess truss head 5303303077 Strap-capacitor 309343108 CORD-SRV 115V/16GA TYPE A 5303007754 Screw,.138-32 3200761 Spacer-control bulb...
- Page 6 FAH086J1T2 AIR HANDLING PARTS 5/00...
- Page 7 POS. NO. 5/00 FAH086J1T2 AIR HANDLING PARTS PART NO. 309629102 3202975 309628901 5304408764 309627401 309631701 5303012110 309628802 309622801 309622901 309335201 309629001 309335001 DESCRIPTION BLADE-FAN ASSY Screw,10-16 x 0.72 sq. drive SHROUD-CONDENSER MOTOR-FAN 3SP,W/LEADS BULKHEAD-18.5CHASSIS BLOWER WHEEL Clamp-blower TOP-CONDENSER SCROLL-18.5 SCROLL PLATE...
- Page 8 FAH086J1T2 COMPRESSOR PARTS 5/00...
- Page 9 POS. NO. 5/00 FAH086J1T2 COMPRESSOR PARTS PART NO. 5304406829 5303283877 5308006948 3200282 3200281 3202920 5303211017 309632303 309641901 309628703 309632004 5304415472 5300265301 5303002664 NOT REQUIRED NOT REQUIRED DESCRIPTION COMPR-SANYO Grommet,compressor,(3) Nut,compressor,(3) Gasket-cover Cover-terminal OVERLOAD-MRA 98869-443 Nut,cover EVAP ASSY-2RW/17FPI COND ASSY-2RW/15FPI TRAY-BASE...
- Page 10 POS. NO. 5/00 FAH086J1T2 WINDOW MOUNTING PARTS PART NO. 309628603 309628604 5304409303 5304409304 5303301038 5304409305 5304409306 5304409307 5304409308 5304409309 5304409310 309335101 5304409311 309636002 DESCRIPTION TRIM FRAME-SIDES TRIM FRAME-TOP & BOTTOM KIT-GROUNDING WIRE BLOCK-TAPERED SEAL-WRAPPER SEAL-COND END BRACKET SEAL-COND/REAR PANEL SEAL-COND/REAR PNL,SIDES SEAL-COND/RR PNL,TOP &BTTM...
- Page 11 FAH086J1T2 WIRING DIAGRAM 5/00...
