Fortinet FortiAnalyzer-800B Quick Start Manual

FortiAnalyzer LED Indicators
Light Icon State
Green
Flashing Green
Off
Green
Off
Green
Flashing Green
Off
FortiAnalyzer Front Buttons
Power button.
Reset button.

Checking the Package Contents

Connector Type
Ports 1 to 4 RJ-45
CONSOLE DB-9
USB USB
Power
Connection
Connecting
Connect the FortiAnalyzer unit to a power outlet and to the network hub or switch.
• Place the FortiAnalyzer unit on a stable surface.
• Use included mounting slide rails to mount on a standard 19" rack.
• Connect one end of Ethernet cable to port 1, the other to the network hub or switch.
• Make sure the power is not plugged into the wall before connecting the power cable.

Planning the Configuration

You can add the FortiAnalyzer unit to your local FortiGate network to receive log messages
from your local FortiGate units.
Connect the FortiAnalyzer unit to the same hub or switch as the FortiGate unit. You can also
connect the FortiAnalyzer unit to multiple FortiGate units or remote FortiGate units over the
Internet . To connect the FortiAnalyzer unit to the FortiGate units remotely, you must config-
ure the DNS server and the default gateway.
You can manage the FortiAnalyzer unit within the local network or over the Internet.

Factory Defaults

User name:
Administrator Account
Password:
IP:
Port 1 Netmask:
Management Access:
IP:
Port 2 Netmask:
Management Access:
IP:
Port 3 Netmask:
Management Access:
IP:
Port 4 Netmask:
Management Access:
Description
The correct cable is in use and the equipment has
power.
Network activity at this interface.
No link established or the FortiAnalyzer unit is off.
Hard disk activity.
No hard disk activity
The FortiAnalyzer unit is running normally.
The FortiAnalyzer unit is running abnormally.
The FortiAnalyzer unit is powered off.
Speed Protocol
10/100/1000 Ethernet
9600 bps RS-232 serial
8/N/1
USB
LED indicators:
Power, Error, Network,
and Disk Access
Ethernet Ports
DB-9
1 and 2
Serial
Connection
2 Mounting Slide Rails
admin
(none)
192.168.1.99
255.255.255.0
ping, https, http, ssh
192.168.2.99
255.255.255.0
ping, https, http, ssh
192.168.3.99
255.255.255.0
ping, https, http, ssh
192.168.4.99
255.255.255.0
ping, https, http, ssh
© Copyright 2007 Fortinet Incorporated. All rights reserved.
Products mentioned in this document are trademarks or registered trade-
marks of their respective holders.
Regulatory Compliance
FCC Class A Part 15 CSA/CUS
28 September 2007
Description
Connection to the network
Connection to the management computer. Provides
access to the command line interface (CLI).
For future use.
Power Switch
Ethernet Ports
3 and 4
Power cable connects
to power outlet
Power Cable
Ethernet Cables:
Orange - Crossover
Grey - Straight-through
Null-Modem Cable
(RS-232)
Copyright 2007 Fortinet Incorporated. All rights reserved.
Trademarks
Products mentioned in this document are trademarks.
Null modem cable connects
to serial port on management computer
FortiAnalyzer-800B
05-30005-0417-20070928
Documentation
Q u i c k S t a r t G u i d e
FortiAnalyzer-800B
Straight-through Ethernet cables connects
to hub or switch on the network
