- Page 1 USER MANUAL QN65Q90R QN75Q90R QN82Q90R Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com Model Serial No. If you have any questions, please call us at 1-800-SAMSUNG (1-800-726-7864) for assistance.
-
Page 2: Before Reading This User Manual
Settings > Support > Open e-Manual Scan this QR code with your smart device to visit Samsung's online Customer Service Center. You can also use your PC to visit "www.samsung.com" and click Support. On the website, you can download the user manual and see its contents on your PC or mobile device. -
Page 3: Warning! Important Safety Instructions
Warning! Important Safety Instructions Please read the Safety Instructions before using your TV. Refer to the table below for an explanation of symbols which may be on your Samsung product. Class II product: This symbol indicates that a CAUTION safety connection to electrical earth (ground) is not required. - Page 4 • Be sure to contact an authorized Samsung service center for information if you intend to install your TV in a location with heavy dust, high or low temperatures, high humidity, chemical substances, or where it will operate 24 hours a day such as in an airport, a train station, etc.
- Page 5 Internet connection, and minimize the risk of unauthorized access. These steps are listed below: • When Samsung releases software updates to improve the security of your TV, you should promptly install these updates. To automatically receive these updates, turn on Auto Update in the TV's menu ( >...
-
Page 6: Table Of Contents
Safety Precaution: Securing the TV to the wall to prevent falling ---------------------------------------------------------------------------- Installing a sound bar (sold separately) ---------------------------------------------------------------------------- The Samsung Smart Remote About the Buttons on the Samsung Smart Remote ---------------------------------------------------------------------------- Pairing the TV to the Samsung Smart Remote ---------------------------------------------------------------------------- Installing batteries into the Samsung Smart Remote ----------------------------------------------------------------------------... -
Page 7: Tv Installation
01 TV Installation One Invisible Connection Guide ONE CONNECT ONE CONNECT ONE CONNECT ONE CONNECT (M4 x L12) 4 inches Bending Cover To connect the One Invisible Connection to the One Connect and your TV, follow these steps: 1. After the TV is completely set up and placed in its final position, connect the One Invisible Connection to the One Connect and the TV as shown in Steps 1 to 4 above. - Page 8 • Do not use the One Connect in the upside-down or upright position. • When connecting the One Invisible Connection, use a Bending Cover, which prevents the cable of the One Invisible Connection from being bent at a 90 degree angle, to bend the cable. Failure to do so may cause damage to the cable.
-
Page 9: Mounting The Tv On A Wall
• When installing a wall mount kit, we recommend you fasten all four VESA screws. • If you want to install a wall mount kit that attaches to the wall using two top screws only, be sure to use a Samsung wall mount kit that supports this type of installation. -
Page 10: Providing Proper Ventilation For Your Tv
• When you install your TV with a stand or a wall mount, we strongly recommend you use parts provided by Samsung Electronics only. -
Page 11: Installing A Sound Bar (Sold Separately)
Preventing the TV from falling 1. Using the appropriate screws, firmly fasten a set of brackets to the wall. Confirm that the screws are firmly attached to the wall. – You may need additional material such as wall anchors depending on the type of wall. -
Page 12: The Samsung Smart Remote
About the Buttons on the Samsung Smart Remote • The images, buttons, and functions of the Samsung Smart Remote may differ depending on the model. • The Universal Remote function operates normally only when the Samsung Smart Remote that comes with the TV is used. -
Page 13: Pairing The Tv To The Samsung Smart Remote
Pairing the TV to the Samsung Smart Remote When you turn on the TV for the first time, the Samsung Smart Remote pairs to the TV automatically. If the Samsung Smart Remote does not pair to the TV automatically, point it at the remote control sensor of the TV, and then press and hold the buttons... -
Page 14: Initial Setup
To run an item on the menu, press the directional buttons on the TV Controller to move the focus to the item, and then press the button on the TV Controller. • The screen may dim if the protective film on the SAMSUNG logo or the bottom of the TV is not detached. Please remove the protective film. Control menu... -
Page 15: Troubleshooting And Maintenance
• Try pointing the remote directly at the TV from 5 ft. to 6 ft. (1.5-1.8 m) away. • If your TV came with a Samsung Smart Remote (Bluetooth Remote), make sure to pair the remote to the TV. The cable box or satellite box remote control doesn’t turn the TV on or off or adjust the volume. -
Page 16: What Is Remote Support
Settings > Support > Self Diagnosis > Reset Smart Hub. What is Remote Support? Samsung Remote Support service offers you one-on-one support with a Samsung Technician who can remotely: • Diagnose your TV • Adjust the TV settings for you •... -
Page 17: Eco Sensor And Screen Brightness
Eco Sensor and screen brightness Eco Sensor adjusts the brightness of the TV automatically. This feature measures the light in your room and optimizes the brightness of the TV automatically to reduce power consumption. If you want to turn this off, go to >... -
Page 18: Specifications And Other Information
05 Specifications and Other Information Specifications Model Name QN65Q90R QN75Q90R Display Resolution 3840 x 2160 3840 x 2160 Screen Size Diagonal 65˝ Class 75˝ Class Measured Diagonally 64.5 inches 74.5 inches Sound (Output) 60 W 60 W Dimensions (W x H x D) Body 57.1 x 32.7 x 1.6 inches 66.0 x 37.9 x 1.6 inches... -
Page 19: Decreasing Power Consumption
Dispose unwanted electronics through an approved recycler. To find the nearest recycling location, go to our website: www.samsung.com/recyclingdirect or call, (877) 278 - 0799 Decreasing power consumption When you shut the TV off, it enters Standby mode. In Standby mode, it continues to draw a small amount of power. To decrease power consumption, unplug the power cord when you don't intend to use the TV for a long time. -
Page 20: Dimensions
Dimensions Back panel detail / Rear view • The displayed image may differ from your TV, depending on the model. (Unit: inches) Model name QN65Q90R 20.6 12.8 QN75Q90R 25.1 12.5 QN82Q90R 24.3 18.2 Licenses The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. -
Page 21: Limited Warranty To Original Purchaser
SAMSUNG or SAMSUNG's authorized service center. SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG. - Page 22 CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE.
- Page 23 This page is intentionally left blank.
- Page 24 If you experience issues, please do not take the TV back to the store. In the United States of America, call us at 1-800-SAMSUNG (1-800-726-7864) or visit us at www.samsung. com or www.samsung.com/spsn for support and warranty service.
