Fortinet FortiLog FortiLog-2000 Quick Start Manual

FortiLog unit LED Indicators
LED State Description
Power On The FortiLog unit is powered on.
Off The FortiLog unit is powered off.
Status On The FortiLog unit is running normally.
Ethernet Flashing Network activities at this interface.
ports
Off No link at the interface.
(back)
10/100 On The interface is connected at 100 Mbps.
Off The interface is connected at 10 Mbps.
Link Act Flashing Network activities on the FortiLog unit
On Interface connected.
1

Checking the package contents

Front
Connector
Ports 1, 2, 3, 4
CONSOLE
2
Planning the installation
You can add the FortiLog unit to your local FortiGate network to receive log messages from your local FortiGate units, or
connect the FortiLog unit to the FortiGate units remotely using FortiManager. To connect the FortiLog unit to the
FortiGate units remotely, you must configure the DNS server and the default gateway.
To manage the FortiLog unit, you can use a computer within the local network or over the Internet.

Factory Defaults

User name:
Administrator
account
Password:
IP:
Port 1 Netmask:
Management Access:
IP:
Port 2 Netmask:
Management Access:
IP:
Port 3 Netmask:
Management Access:
IP:
Port 4 Netmask:
Management Access:
3
Connecting the FortiLog unit
• Place the FortiLog unit on a stable surface. It requires 1.5 inches (3.75 cm) clearance on each side to allow for cooling.
• Make sure the power is not plugged into the wall before connecting the power cable.
• The Status light flashes while the unit is starting up and remains lit when the system is up and running.
Straight-through Ethernet cable connects
to hub or switch on the network
LED indicators:
LCD
Power, Error, Network Access
Panel
RJ-45
Ethernet USB ports
Serial
Connections for future use
Connection
Type Speed Protocol Description
RJ-45 10/100Base-T Ethernet
DB-9 9600 bps RS-232
serial
admin
(none)
192.168.1.99
255.255.255.0
ping, https, ssh, http
192.168.2.99
255.255.255.0
ping, https, ssh, http
192.168.3.99
255.255.255.0
ping, https, ssh, http
192.168.4.99
255.255.255.0
ping, https, ssh, http
FortiLog-2000
© Copyright 2005 Fortinet Incorporated. All rights reserved.
Trademarks
Products mentioned in this document are trademarks or registered trademarks of their respective holders.
Regulatory Compliance
FCC Class A Part 15, CE, and UL
30 September 2005
For technical support please visit http://www.fortinet.com.
Check that the package contents are complete.
Connection to the network.
Connection to the management computer.
Provides access to the command line interface (CLI).
Things you need to know before installing the FortiLog unit.
Connect the FortiLog unit to a power outlet and to the network hub or switch.
RJ-45 to DB-9 serial cable connects
to management computer
QuickStart Guide
Power
Connections
Back
Power cable connects
to power outlet
05-30000-0237-20050930
Ethernet Cables:
Orange - Crossover
Grey - Straight-through
RJ-45 to
DB-9 Serial Cable
Power Cable
FortiLog-2000
QuickStart Guide
Copyright 2005 Fortinet Incorporated. All rights reserved.
Trademarks
Products mentioned in this document are trademarks.
Documentation
Internet
Backup
power outlet
