The FortiUSB key

Restoring the previous configuration

The FortiUSB key
58
11 Enter the firmware image filename and press Enter.
The TFTP server uploads the firmware image file to the FortiGate unit and
messages similar to the following are displayed:
• FortiGate unit running v2.x BIOS
Do You Want To Save The Image? [Y/n]
Type Y.
• FortiGate unit running v3.x BIOS
Save as Default firmware/Run image without saving:[D/R]
or
Save as Default firmware/Backup firmware/Run image without
saving: [D/B/R]
12 Type D.
The FortiGate unit installs the new firmware image and restarts. The installation
might take a few minutes to complete.
Change the internal interface address, if required. You can do this from the CLI
using the following command:
config system interface
edit internal
set ip <address_ip4mask>
set allowaccess {ping https ssh telnet http}
end
After changing the interface address, you can access the FortiGate unit from the
web-based manager and restore the configuration. For details, see the
Administration Guide.
If you are reverting to a previous FortiOS version (for example, reverting from
FortiOS v3.0 to FortiOS v2.80), you might not be able to restore the previous
configuration from the backup configuration file.
The FortiUSB key provides flexibility and control when backing up and restoring
configuration files. The FortiUSB key also enables you to have a single, secure
location for storing configuration files.
Use the FortiUSB key with the USB Auto-Install feature, automatically installing a
configuration file and a firmware image file on a system reboot. The USB
Auto-Install feature uses a configuration file and a firmware image file that is on
the FortiUSB key, and on a system reboot, checks if these files need to be
installed. If so, the FortiGate unit installs the configuration file and firmware image
file directly from the key to the unit.
Note: The FortiUSB key is purchased separately. The FortiGate unit only supports the
FortiUSB key available from Fortinet.
FortiGate-200A, FortiGate-300A, FortiGate-400A, and FortiGate-500A FortiOS 3.0 MR4 Install Guide
