Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
WR250RY
32D-28199-22

Advertisement

Table of Contents
loading

Related Manuals for Yamaha 2009 WR250R

Summary of Contents for Yamaha 2009 WR250R

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL WR250RY 32D-28199-22...
  • Page 2 EAU46090 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 EAU10102 Welcome to the Yamaha world of motorcycling! As the owner of the WR250RY, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 WR250RY OWNER’S MANUAL ©2008 by Yamaha Motor Co., Ltd. 1st edition, October 2008 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS LOCATION OF IMPORTANT Ignition circuit cut-off system ..4-19 Valve clearance ......7-19 LABELS ..........1-1 Tires ..........7-19 FOR YOUR SAFETY – Spoke wheels ....... 7-21 SAFETY INFORMATION ....2-1 PRE-OPERATION CHECKS ....5-1 Adjusting the clutch lever free play ..........
  • Page 7 TABLE OF CONTENTS Replacing the fuses .......7-32 Replacing the headlight bulb ..7-33 Tail/brake light .......7-34 Replacing a turn signal light bulb ..........7-35 Replacing the license plate light bulb ..........7-35 Replacing an auxiliary light bulb ..7-36 Supporting the motorcycle .....7-36 Front wheel ........7-37 Rear wheel ........7-38 Troubleshooting ......7-39 Troubleshooting charts ....7-41...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 LOCATION OF IMPORTANT LABELS Before you operate this vehicle, read the owner’s manual. Prima di usare il veicolo, leggete il manuale di istruzioni. Lire le manuel du propri étaire avant d ’utiliser ce v éhicule. Lesen Sie die Bedienungsanleitung bevor Sie dieses Fahrzeug fahren. Antes de conducir este vehículo, lea el Manual del Propietario.
  • Page 10 LOCATION OF IMPORTANT LABELS...
  • Page 11 LOCATION OF IMPORTANT LABELS...

  • Page 12: Safety Information

    SAFETY INFORMATION EAU10313 time you use the vehicle to make sure it Many accidents involve inexperi- is in safe operating condition. Failure to enced operators. In fact, many op- Be a Responsible Owner inspect or maintain the vehicle properly erators who have been involved in As the vehicle’s owner, you are respon- increases the possibility of an accident accidents do not even have a cur-...
  • Page 13 SAFETY INFORMATION changing lanes. Make sure that Wear a face shield or goggles. less, tasteless gas which may be other motorists can see you. Wind in your unprotected eyes present even if you do not see or smell The posture of the operator and could contribute to an impairment any engine exhaust.
  • Page 14 Yamaha accessories, which are avail- of the motorcycle is changed. To avoid to minimize imbalance or instabili- able only from a Yamaha dealer, have the possibility of an accident, use ex- been designed, tested, and approved treme caution when adding cargo or Shifting weights can create a sud- by Yamaha for use on your vehicle.
  • Page 15 SAFETY INFORMATION or others. Installing aftermarket prod- lightweight as possible and Aftermarket Tires and Rims ucts or having other modifications per- should be kept to a minimum. The tires and rims that came with your formed to your vehicle that change any Bulky or large accessories may motorcycle were designed to match the of the vehicle’s design or operation...

  • Page 16: Description

    DESCRIPTION EAU10410 Left view 1. Front fork rebound damping force adjusting screw (page 4-14) 8. Helmet holder (page 4-14) 2. Fuse box (page 7-32) 9. Front fork compression damping force adjusting screw (page 4-14) 3. Coolant reservoir (page 7-13) 4. Shock absorber assembly compression damping force adjusting screw (page 4-17) 5.

  • Page 17: Right View

    DESCRIPTION EAU10420 Right view 1. Rear brake fluid reservoir (page 7-24) 2. Air filter element (page 7-16) 3. Rear brake light switch (page 7-23) 4. Engine oil filler cap (page 7-10) 5. Engine oil level check window (page 7-10) 6. Shock absorber assembly rebound damping force adjusting dial (page 4-17)

  • Page 18: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 4-9) 2. Left handlebar switches (page 4-8) 3. Main switch/steering lock (page 4-1) 4. Multi-function display (page 4-3) 5. Right handlebar switches (page 4-8) 6. Brake lever (page 4-10) 7. Throttle grip (page 7-18) 8.

  • Page 19: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS EAU10460 EAU10661 EAU10681 Main switch/steering lock LOCK All electrical systems are off. The key The steering is locked, and all electrical can be removed. systems are off. The key can be re- moved. EWA10061 WARNING Never turn the key to “OFF” or To lock the steering “LOCK”...

  • Page 20: Indicator And Warning Lights

    4. Turn signal indicator light “ ” for a few seconds, then go off, have a 5. High beam indicator light “ ” Yamaha dealer check the electrical cir- 6. Engine trouble warning light “ ” cuit. EAU11020 Turn signal indicator light “...

  • Page 21: Multi-Function Display

    If the warning light does not come on on for a few seconds, then go off, have EWA12312 for a few seconds, then go off, have a a Yamaha dealer check the electrical WARNING Yamaha dealer check the electrical cir- circuit.
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS distance traveled since they were of the display segments of the last set to zero) multi-function display will appear a fuel reserve tripmeter (which and then disappear, in order to test shows the distance traveled since the electrical circuit.
  • Page 23 INSTRUMENT AND CONTROL FUNCTIONS To reset a tripmeter, select it by push- ing the “SELECT 2” button, and then The fuel level warning light may not push the “RESET” button for at least function accurately while riding off road one second. If you do not reset the fuel as the fuel level reading changes due to reserve tripmeter manually, it will reset the movement and inclination of the ve-...
  • Page 24 INSTRUMENT AND CONTROL FUNCTIONS lease it to start the clock. operation. If the stopwatch is in op- eration, stop it by pushing the “SELECT 1” button and “SELECT When setting the clock, push the 2” button together. “SELECT 1” button to increase the 2.
  • Page 25 1. Check that the stopwatch mea- consult your nearby Yamaha dealer. 3. Push the “SELECT 1” button and surement is in operation. Calibrate the distance-compensation “SELECT 2” button together to 2.

  • Page 26: Handlebar Switches

    3. Horn switch “ ” cate an error code. engine damage. If the display indicates any error codes, note the code number, and then have a Yamaha dealer check the vehicle.

  • Page 27: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS Right EAU12500 EAU12820 Horn switch “ ” Clutch lever Press this switch to sound the horn. EAU12660 Engine stop switch “ ” Set this switch to “ ” before starting the engine. Set this switch to “ ”...

  • Page 28: Shift Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12870 EAU12890 EAU12941 Shift pedal Brake lever Brake pedal 1. Shift pedal 1. Brake lever 1. Brake pedal The shift pedal is located on the left The brake lever is located at the right The brake pedal is on the right side of side of the engine and is used in com- handlebar grip.

  • Page 29: Fuel Tank Cap

    INSTRUMENT AND CONTROL FUNCTIONS EAU44363 EAU13212 Fuel tank cap Fuel Make sure there is sufficient gasoline in To remove the fuel tank cap the tank. 1. Insert the key into the lock and turn EWA10881 WARNING it counterclockwise as shown. Gasoline and gasoline vapors are extremely flammable.
  • Page 30 Gasoline is poisonous and can as well as to the exhaust system. cause injury or death. Handle gaso- Your Yamaha engine has been de- line with care. Never siphon gaso- signed to use premium unleaded gaso- line by mouth. If you should swallow...

  • Page 31: Catalytic Converter

    INSTRUMENT AND CONTROL FUNCTIONS EAU13433 pairable damage to the catalytic EAU13970 Catalytic converter Seat converter. This model is equipped with a catalytic converter in the exhaust system. To remove the seat EWA10862 Remove the bolts, and then pull the WARNING seat off.

  • Page 32: Helmet Holder

    INSTRUMENT AND CONTROL FUNCTIONS EAU14282 EAU45201 Helmet holder Adjusting the front fork EWA10180 WARNING Always adjust both fork legs equal- ly, otherwise poor handling and loss of stability may result. This front fork is equipped with rebound damping force adjusting screws and compression damping force adjusting 1.
  • Page 33 INSTRUMENT AND CONTROL FUNCTIONS Rebound damping force Compression damping force 1. Remove the rubber cap by pulling it out of the front fork leg. 1. Compression damping force adjusting screw 1. Rebound damping force adjusting screw To increase the rebound damping force Compression damping setting: 1.

  • Page 34: Front Fork Bleeding

    INSTRUMENT AND CONTROL FUNCTIONS always represents the entire adjusting EAU14791 should be no weight on the front end of Front fork bleeding range. To obtain a precise adjustment, the vehicle. it would be advisable to check the num- 2. Remove the bleed screws and al- ber of clicks of each damping force ad- low all of the air to escape from justing mechanism and to modify the...

  • Page 35: Adjusting The Shock Absorber Assembly

    12 click(s) in direction (b)* Spring preload adjustment should be Maximum (hard): Maximum (hard): made by a Yamaha dealer, since this Distance A = 206 mm (8.11 in) 3 click(s) in direction (b)* service requires special tools and tech- * With the adjusting dial fully turned in direction (a) nical skills.

  • Page 36: Exup System

    INSTRUMENT AND CONTROL FUNCTIONS in production. EAU41940 EXUP system EWA10221 This model is equipped with Yamaha’s WARNING EXUP (EXhaust Ultimate Power valve) This shock absorber assembly con- system. This system boosts engine tains highly pressurized nitrogen power by means of a valve that regu- gas.

  • Page 37: Sidestand

    Yamaha’s ignition circuit cut-off system has been designed to assist the operator in fulfilling the respon- sibility of raising the sidestand be- fore starting off. Therefore, check this system regularly as described below and have a Yamaha dealer re- 4-19...
  • Page 38 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.

  • Page 39: For Your Safety - Pre-Operation Checks

    Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equipment damage. Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 40 Adjust if necessary. Make sure that operation is smooth. Check cable free play. Throttle grip 7-18, 7-27 If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. Make sure that operation is smooth. Control cables 7-27 Lubricate if necessary.
  • Page 41 Make sure that all nuts, bolts and screws are properly tightened. Chassis fasteners — Tighten if necessary. Instruments, lights, signals Check operation. — and switches Correct if necessary. Check operation of ignition circuit cut-off system. Sidestand switch 4-19 If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 42: Operation And Important Riding Points

    Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this position.

  • Page 43: Shifting

    EAU16671 the neutral position, do not Shifting on. If not, ask a Yamaha dealer to coast for long periods of time check the electrical circuit. with the engine off, and do not 3. Start the engine by pushing the tow the motorcycle for long dis- start switch.

  • Page 44: Tips For Reducing Fuel Consumption

    Shift up swiftly, and avoid high en- Since the engine is brand new, do not immediately have a Yamaha dealer gine speeds during acceleration. put an excessive load on it for the first check the vehicle.

  • Page 45: Parking

    OPERATION AND IMPORTANT RIDING POINTS EAU17213 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10311 WARNING Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them and be burned.

  • Page 46: Periodic Maintenance And Adjustment

    If If you do not have the tools or experi- you are not familiar with vehicle ser- ence required for a particular job, have vice, have a Yamaha dealer perform a Yamaha dealer perform it for you. service.

  • Page 47: Periodic Maintenance Chart For The Emission Control System

    From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi). Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.

  • Page 48: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU1770B General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ √...
  • Page 49 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Check chain slack, alignment and condition. Drive chain Adjust and lubricate chain with a Every 500 km (300 mi) and after washing the motorcycle or riding in the rain special O-ring chain lubricant...
  • Page 50 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Change. √ √ Engine oil Check oil level and vehicle for oil Every 5000 km (3000 mi) leakage.
  • Page 51 PERIODIC MAINTENANCE AND ADJUSTMENT EAU18670 The air filter needs more frequent service if you are riding in unusually wet or dusty areas. Hydraulic brake service Regularly check and, if necessary, correct the brake fluid level. Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid.

  • Page 52: Removing And Installing Panels

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU18771 2. Remove the bolts and collars. Removing and installing panels The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed.
  • Page 53 PERIODIC MAINTENANCE AND ADJUSTMENT To install the panel Panel C 1. Place the panel in the original po- sition, and then install the collars To remove the panel and bolts. 1. Remove the bolts. 1. Bolt 2. Panel B To install the panel 2.

  • Page 54: Checking The Spark Plug

    Do not attempt to diagnose such problems yourself. Instead, have a Yamaha dealer check the vehicle. If the spark plug shows signs of elec- trode erosion and excessive carbon or other deposits, it should be replaced.

  • Page 55: Engine Oil And Oil Filter Element

    PERIODIC MAINTENANCE AND ADJUSTMENT Before installing a spark plug, the spark installing a spark plug, a good estimate EAU45141 Engine oil and oil filter plug gap should be measured with a of the correct torque is 1/4–1/2 turn element wire thickness gauge and, if necessary, past finger tight.
  • Page 56 PERIODIC MAINTENANCE AND ADJUSTMENT to collect the used oil. 4. Remove the engine oil filler cap and drain bolt to drain the oil from the crankcase. 1. Engine oil filler cap 1. Engine oil drain bolt 2. Maximum level mark 2.
  • Page 57 PERIODIC MAINTENANCE AND ADJUSTMENT 5. Remove the oil filter element cover then install and tighten the oil filler by removing the bolts. cap. Recommended oil: See page 9-1. Oil quantity: Without oil filter element replace- ment: 1.30 L (1.37 US qt, 1.14 Imp.qt) With oil filter element replacement: 1.40 L (1.48 US qt, 1.23 Imp.qt) 1.

  • Page 58: Coolant

    In addition, the cool- so it will not seize. If this occurs, ant must be changed at the intervals have a Yamaha dealer repair the specified in the periodic maintenance vehicle. and lubrication chart.
  • Page 59 If water has been 2. Remove panels A and C. (See added to the coolant, have a page 7-7.) Yamaha dealer check the anti- 3. Place a container under the engine freeze content of the coolant as to collect the used coolant.
  • Page 60 PERIODIC MAINTENANCE AND ADJUSTMENT 9. Remove the coolant drain bolt to recommended coolant into the ra- drain the cooling system. diator and reservoir. Antifreeze/water mixture ratio: Recommended antifreeze: High-quality ethylene glycol anti- freeze containing corrosion inhibitors for aluminum engines Coolant quantity: Radiator capacity (including all routes): 1.

  • Page 61: Cleaning The Air Filter Element And Check Hose

    If coolant is leaking, have a Yamaha The air filter element should be cleaned dealer check the cooling system. at the intervals specified in the periodic 19.
  • Page 62 PERIODIC MAINTENANCE AND ADJUSTMENT The sponge material should be wet but not dripping. Recommended oil: Yamaha foam air filter oil or other quality foam air filter oil 6. Pull the sponge material over the air filter element frame. 1. Sponge material 1.

  • Page 63: Adjusting The Engine Idling Speed

    Yamaha dealer make the adjustment. rection (a). To decrease the en- sary, have a Yamaha dealer adjust it. gine idling speed, turn the screw in direction (b). 7-18...

  • Page 64: Valve Clearance

    Rear: from occurring, the valve clearance the specified tires. 175 kPa (1.75 kgf/cm , 25 psi) must be adjusted by a Yamaha dealer 90–185 kg (198–408 lb): at the intervals specified in the periodic Tire air pressure Front: maintenance and lubrication chart.
  • Page 65 2. Tire sidewall soon possible with model by Yamaha Motor Co., Ltd. 3. Tire wear indicator high-quality product. Front tire: The tires must be checked before each Size: ride.

  • Page 66: Spoke Wheels

    4. Fully turn the adjusting bolt in di- age before each ride. If any dam- rection (a) to loosen the clutch ca- age is found, have a Yamaha ble. dealer replace the wheel. Do not 5. Loosen the locknut further down attempt even the smallest repair to the clutch cable.

  • Page 67: Adjusting The Brake Lever Free Play

    If there is air in the hy- draulic system, have a Yamaha dealer bleed the system before 1. Locknut operating the motorcycle. Air in 2.

  • Page 68: Adjusting The Rear Brake Light Switch

    EAU22272 EAU22390 indicator grooves have almost disap- Adjusting the rear brake light Checking the front and rear peared, have a Yamaha dealer replace switch brake pads the brake pads as a set. The front and rear brake pads must be...

  • Page 69: Checking The Brake Fluid Level

    However, if the Observe these precautions: brake fluid level goes down sud- When checking the fluid level, denly, have a Yamaha dealer make sure that the top of the brake check the cause. 1. Minimum level mark fluid reservoir is level.

  • Page 70: Changing The Brake Fluid

    EAU22731 EAU22760 Changing the brake fluid Drive chain slack Have a Yamaha dealer change the The drive chain slack should be brake fluid at the intervals specified in checked before each ride and adjusted the TIP after the periodic maintenance if necessary.

  • Page 71: Cleaning And Lubricating The Drive Chain

    PERIODIC MAINTENANCE AND ADJUSTMENT gine as well as other vital parts EAU23023 Tightening torque: Cleaning and lubricating the of the motorcycle and can lead Axle nut: drive chain to chain slippage or breakage. 125 Nm (12.5 m·kgf, 90.4 ft·lbf) To prevent this from occurring, The drive chain must be cleaned and keep the drive chain slack with- lubricated at the intervals specified in...

  • Page 72: Checking And Lubricating The Cables

    If a cable is damaged maintenance chart. or does not move smoothly, have a Yamaha dealer check or replace it. WARNING! Damage to the outer sheath may interfere with proper ca- ble operation and will cause the in- cable rust.

  • Page 73: Checking And Lubricating The Brake And Clutch Levers

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU23142 ride, and the lever pivots should be lu- EAU23182 Checking and lubricating the Checking and lubricating the bricated if necessary. brake and clutch levers brake pedal Recommended lubricants: Brake lever: Brake lever Silicone grease Clutch lever: Lithium-soap-based grease The operation of the brake pedal should be checked before each ride,...

  • Page 74: Checking And Lubricating The Sidestand

    WARNING push down hard on the handlebars If the sidestand does not move up several times to check if the front and down smoothly, have a Yamaha fork compresses and rebounds dealer check or repair it. Otherwise, smoothly. the sidestand could contact the ground and distract the operator, re- sulting in a possible loss of control.

  • Page 75: Checking The Steering

    If any damage is found or the front avoid injury, securely support fork does not operate smoothly, the vehicle so there is no danger have a Yamaha dealer check or re- of it falling over. [EWA10751] pair it. 2. Hold the lower ends of the front fork legs and try to move them for- ward and backward.

  • Page 76: Checking The Wheel Bearings

    IES OUT OF THE REACH OF fastened. CHILDREN. EWA10760 WARNING To charge the battery Electrolyte is poisonous and Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to furic acid, which causes severe 7-31...

  • Page 77: Replacing The Fuses

    Using a conventional battery charger will damage the battery. If you do not have access to a con- stant-voltage battery charger, have a Yamaha dealer charge your battery. 1. Main fuse 2. Spare main fuse To store the battery The fuse box, which contains the fuses 1.

  • Page 78: Replacing The Headlight Bulb

    If a fuse is blown, replace it as follows. 4. If a fuse immediately blows again, 1. Turn the key to “OFF” and turn off have a Yamaha dealer check the the electrical circuit in question. electrical system. 2. Remove the blown fuse, and then install a new fuse of the specified amperage.

  • Page 79: Tail/Brake Light

    6. Install the headlight cowling (to- gether with the headlight unit) by placing it in the original position, and then installing the bolts. 7. Have a Yamaha dealer adjust the headlight beam if necessary. 1. Headlight coupler 2. Bulb cover...

  • Page 80: Replacing A Turn Signal Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU24204 EAU24312 Replacing a turn signal light Replacing the license plate bulb light bulb 1. Remove the turn signal light lens 1. Remove the license plate light unit by removing the screw. by removing the screws. 1.

  • Page 81: Replacing An Auxiliary Light Bulb

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU45222 EAU24350 Replacing an auxiliary light Supporting the motorcycle bulb Since this model is not equipped with a centerstand, follow these precautions If the auxiliary light bulb burns out, re- when removing the front and rear place it as follows.

  • Page 82: Front Wheel

    PERIODIC MAINTENANCE AND ADJUSTMENT frame in front of the rear wheel or under EAU24360 Front wheel each side of the swingarm. EAU45161 To remove the front wheel EWA10821 WARNING To avoid injury, securely support the vehicle so there is no danger of it falling over.

  • Page 83: Rear Wheel

    PERIODIC MAINTENANCE AND ADJUSTMENT EAU25080 Rear wheel Make sure that there is enough space between the brake pads before install- EAU45181 To remove the rear wheel ing the brake caliper onto the brake disc. EWA10821 WARNING 2. Insert the wheel axle. To avoid injury, securely support the 3.

  • Page 84: Troubleshooting

    3. Slot self. However, should your motorcycle erwise the brake pads will be require any repair, take it to a Yamaha forced shut. [ECA11071] 2. Install the drive chain onto the rear dealer, whose skilled technicians have sprocket.
  • Page 85 PERIODIC MAINTENANCE AND ADJUSTMENT heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or property damage. 7-40...

  • Page 86: Troubleshooting Charts

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 87 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 88: Motorcycle Care And Storage

    Be ble. Rust and corrosion can develop Cleaning sure to consult a Yamaha dealer for even if high-quality components are ECA10772 advice on what products to use be- NOTICE used.
  • Page 89 MOTORCYCLE CARE AND STORAGE off any detergent residue using scratches on the windshield. plenty of water, as it is harmful Test the product on a small hid- Salt sprayed on roads in the winter may to plastic parts. den part of the windshield to remain well into spring.

  • Page 90: Storage

    WARNING ity to seep in and cause rust. To prevent corrosion, avoid Contaminants on the brakes or tires Consult a Yamaha dealer for ad- damp cellars, stables (because can cause loss of control. vice on what products to use. of the presence of ammonia)
  • Page 91 MOTORCYCLE CARE AND STORAGE 3. Perform the following steps to pro- centerstand. tect the cylinder, piston rings, etc. 5. Check and, if necessary, correct from corrosion. the tire air pressure, and then lift a. Remove the spark plug cap the motorcycle so that both of its and spark plug.

  • Page 92: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Fuel: Overall length: Type: Recommended fuel: 2180 mm (85.8 in) SAE 10W-30, SAE 10W-40, SAE 10W-50, Premium unleaded gasoline only Overall width: SAE 15W-40, SAE 20W-40 or SAE Fuel tank capacity: 810 mm (31.9 in) 20W-50 7.6 L (2.01 US gal, 1.67 Imp.gal) Overall height: Fuel reserve amount:...
  • Page 93 SPECIFICATIONS Gear ratio: Loading: Operation: Right hand operation 1st: Maximum load: Recommended fluid: 37/14 (2.642) 185 kg (408 lb) DOT 4 2nd: (Total weight of rider, passenger, cargo and Rear brake: 29/16 (1.813) accessories) 3rd: Tire air pressure (measured on cold Type: 29/22 (1.318) Single disc brake...
  • Page 94 SPECIFICATIONS Voltage, capacity: Fuses: 12 V, 6.0 Ah Main fuse: Headlight: 30.0 A Bulb type: Headlight fuse: Halogen bulb 15.0 A Bulb voltage, wattage × quantity: Signaling system fuse: 10.0 A Headlight: Ignition fuse: 12 V, 60 W/55 W 7.5 A Tail/brake light: Radiator fan fuse: 7.5 A...

  • Page 95: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.

  • Page 96: Motorcycle Noise Regulation (For Australia)

    The use of the vehicle after such spare parts from a Yamaha dealer. device or element of design has been removed or rendered inoper- ative by any person.
  • Page 97 INDEX Air filter element and check hose, Front and rear brake pads, checking..7-23 Neutral indicator light ........ 4-2 cleaning ..........7-16 Front fork, adjusting......... 4-14 Noise regulation (for Australia) ....10-2 Auxiliary light bulb, replacing ....7-36 Front fork, bleeding ......... 4-16 Front fork, checking.........
  • Page 98 INDEX Turn signal indicator light ......4-2 Turn signal light bulb, replacing ....7-35 Turn signal switch ........4-9 Valve clearance ........7-19 Vehicle identification number ....10-1 Wheel bearings, checking....... 7-31 Wheel (front) ........... 7-37 Wheel (rear) ..........7-38 Wheels ............
  • Page 100 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2008.10–0.2×1 !
