Fetco CBS-2031e Technical Bulletin

TECHNICAL
BULLETIN
Control Board Washers – 2000e Series
Subject:
Applies to: All CBS-2000e Series Coffee Brewers
This bulletin applies to the following models:
CBS-2031e
CBS-2032e
It does not apply to CBS-2000 Series brewers, model numbers without "e" at the end.
Due to variations in the front panels and control boards on 2000e Series coffee brewers,
the control board may occasionally be positioned too close to the plastic overlay.
This may cause excessive pressure on the buttons, causing them to stick and generating
error code 255.
As a temporary solution to prevent this problem, Manufacturing has begun using small
nylon washers as spacers on the posts to which the control boards are mounted.
Beginning this week, on a temporary basis, control boards that are sent out as
replacement parts will include a supply of these washers with instructions. Six washers are
required for single brewers, seven for dual brewers.
The permanent solution is to lengthen the
standoffs on the control boards. This will occur on
the next production run of circuit boards in
approximately one month. The nylon washers will
then be discontinued on new equipment and
replacement boards.
When installing a replacement control board with
washers, place one washer on each mounting post
as shown in the drawing. If the brewer already
has washers on the posts, it is not necessary to
install additional washers.
Please contact Technical Support if you need a supply of the washers for control boards
you already have in stock.
FETCO ♦ 640 Heathrow Drive ♦ Lincolnshire, IL 60069 USA ♦ Tel. (800) 338-2699 or (847) 719-3000 ♦ Fax: (847) 821-1178
CBS-2041e
CBS-2042e
NUMBER
16
www.fetco.com
email : techsupport@fetco.com
Date:
CBS-2051e
CBS-2052e
May 19, 2004
PART # 24065
WASHER, NYLON
