Page 1: Table Of Contents
Contents Warnings,2 Introduction, 3 English, 2 Installation, 4 Safety Information, 5 Features, 6 The Controls, 7-8 HUE62X S The Cooking Modes in your Cooker, 9 HUE62G S Electronic Clock & Automatic Cooking HUE62K S Feature, 10-12 HUE62P S HUE62X S.0 HUE62X S.0...
Page 2: Warnings,2
Warnings WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards...
Page 3: Introduction
Introduction * The guarantee is subject to the provisions that the To the Installer: Before installation, fill in the product details on the back appliance: cover of this book. (a) Has been used solely in accordance with The information can be found on the rating plate. the Users Instruction Book.
Page 4: Installation
Installation Adjacent side walls which project above hob level, WARNING - THIS APPLIANCE MUST BE must not be nearer to the cooker than 150mm and EARTHED. should be protected by heat resistant material. Any overhanging surface or cooker hood should not be Mains Connection nearer than 650mm.
Page 5: Safety Information
Safety Information causing the container to burst. When used properly your appliance is completely safe but as with · Never store chemicals/food stuffs or pressurised containers in or any electrical product there are certain precautions that must be on the appliance, or in cabinets immediately above or next to the observed.
Page 6: Features
Features 1800/750W Dual Hilite 1200W Hilite Solarglo Solarglo 1500/800W Dual Oval Solarglo 1200W Hilite Solarglo Hob Hot Timer indicators Control panel Model number & Serial number label Grill Oven Light Grill pan and food support Grill pan handle Top Oven/Grill 'Stay Clean' liners rod shelf Top Oven door...
Page 7: The Controls
The controls Switch on the electricity supply to the cooker at the Cooker Control Unit. GRILL MAIN RIGHT TOP OVEN ELECTRONIC LEFT LEFT RIGHT OVEN FRONT TIMER FRONT REAR REAR PLATE PLATE PLATE PLATE Front Left and Rear Right Hob Controls Grill Control - Top Oven As each control knob is turned clockwise, numbers The grill control will not operate unless the top oven...
Page 8 The controls continued... Top Oven Control The Main Oven Cooking Functions This control switches on the top and bottom heating The main oven has eight cooking functions. Use the elements in the top oven. The temperature in the oven main oven control to select the cooking mode you can be set anywhere between 100°C and 220°C.
Page 9: The Cooking Modes In Your Cooker
The Cooking Modes in your Cooker Your new cooker is equipped with a number of different and other poultry to perfection. Each heating element cooking modes: is used in the cycle to guarantee a homogeneous temperature within the oven. A temperature is suggested on this mode but this can be altered using the ‚+/-’...
Page 10: Electronic Clock & Automatic Cooking Feature
Electronic Clock & Automatic Cooking Feature When you first switch on the appliance you will be prompted to set the ‚Time of Day’ on the display. You must ensure you have done this before attempting to use the automatic cooking feature. Main Oven Light Time/Mode...
Page 11 Electronic Clock & Automatic Cooking Feature knob. (The oven will start). STEP 4. Press the Time/Mode button, until the ‚cooking duration’ symbol is flashing. STEP 5. Turn the +/- control knob to set the cooking duration you require. After a few seconds Main Oven Light Time/Mode...
Page 12 Electronic Clock & Automatic Cooking Feature STEP 6. Press the Time/Mode button, until the ‚end This product complies with the requirements of the time’ symbol is flashing. The display will latest European Directive on the limitation of power show a default cooking end time (this consumption will be the current time plus the cooking by the use of ...
Page 13: Use And Care Of The Ceramic Hob
Using the Ceramic Hob WARNING: IF THE SURFACE IS CRACKED, SWITCH OFF THE APPLIANCE TO AVOID THE POSSIBILITY OF ELECTRIC SHOCK, FOR HOB SURFACES OF GLASS-CERAMIC OR SIMILAR MATERIAL WHICH PROTECT LIVE PARTS. Ratings of Cooking Zones Front Left Front Right Back Left Back Right Hilite Solarglo...
Page 14 Safety requirements for deep fat frying In the unfortunate event of a chip pan fire: 1. Switch Off the electricity supply. Always ensure that the bottom of the pan is both NEVER attempt to move the pan - burns and clean and dry.
Page 15: Solarplus Grilling
Solarplus Grill distorted - DO NOT store the grill pan handle on the Warning: Accessible parts may become hot during grill pan grid when the grill pan runners are on the top use. Young children should be kept away. runner position. Your cooker is not fitted with a conventional type of There are two halves to the grill, one on the left and grill.
Page 16: Top Oven - Conventional Cooking
Top Oven - Conventional Cooking The heat for conventional cooking in the top oven is provided by the grill element and the element under Using the grill pan kit the floor of the oven. It is ideal for the slow cooking of cheaper cuts of meat in casseroles etc.
Page 17 Top Oven Temperature Charts - Meat Temperature Position Meat Pre-heat Time (approx.) °C in Oven Beef/ Lamb (slow roasting) 170/180 35 mins per 450g (1lb) + 35 mins over. Beef/ Lamb (foil covered) 190/200 35-40 mins per 450g (1lb) Pork (slow roasting) 170/180 40 mins per 450g (1lb) + 40 mins over Pork (foil covered)
Page 18 Top Oven Temperature Charts - Baking Temperature Food Pre-heat Time in mins. Position in Oven °C Scones 210/220 10-15 Runner 2 from bottom of oven. Small Cakes 180/190 20-25 Runner 2 from bottom of oven. Victoria Sandwich 170/180 20-30 Runner 2 from bottom of oven. Sponge Sandwich (fatless) 180/190 20-25...
Page 19: Main Oven - The Intelligent Cooking System
Main Oven - The Intelligent Cooking System The main oven of your new cooker is equipped with User adjustable temperature ranges by cooking an intelligent electronic cooking system that gives you mode: additional cooking performance, flexibility and features over traditional cooking products. Mode Minimum Back Left...
Page 20 Main Oven - The Intelligent Cooking System COOK CHART - Roast Chicken mode: Meat Pre-heat Temperature Shelf Position Cooking Time Chicken 170°C 2 or 3 20 minutes per 450g (1lb) Turkey 170°C 2 or 3 15-20 minutes per 450g (1lb) Internal Temperatures: Notes: Poultry...
Page 21 Main Oven - The Intelligent Cooking System COOK CHART - Traditional mode: Shelf Meat Pre-heat Temperature Cooking Time Position Beef 190/200°C 2 or 3 20-25 minutes per 450g (1lb) + 20 minutes extra Beef (foil covered) 190/200°C 2 or 3 35-45 minutes per 450g (1lb) Lamb 190/200°C...
Page 22: Care And Cleaning
To clean the oven interiors remove all the oven fittings hob and contains a mild detergent which and where applicable the ‚Stay Clean’ liners. makes cleaning easier. Hotpoint has a All types of oven cleaners can be used, but do not Cleaner-Conditioner which can be obtained,...
Page 23 Care and Cleaning Cleaning the glass doors Ensure anti-rattle bungs are fitted before fitting inner door glass. DROP DOWN DOORS BE CAREFUL NOT TO DAMAGE THE GLASS PANELS BY PUSHING THEM TOO HARD. Open the door fully and carefully slide the first When fitting the glass make sure it is fitted correctly ie inner glass towards you, reflective face is fitted the right way round.
Page 24: Disposal Of Your Appliance
Disposal Respecting and conserving the Disposal of your product environment To minimise the risk of injury to children please dispose of your product carefully and safely. Remove all doors • Whenever possible, avoid pre-heating the oven and lids. Remove the mains cable (where fitted) by and always try to fill it.
Page 25: Something Wrong With Your Cooker
Something Wrong with your Cooker? Before contacting your nearest Service Centre/Installer, check the problem guide below; there may be nothing wrong with your cooker. Problem Check Slight odour or small amount of smoke when grill / This is normal and should cease after a short period. oven used for first time If you find that the timer display is blank, then it is likely that there is no electricity supply to...
Page 26: Cooking Results Not Satisfactory
Cooking Results Not Satisfactory? Problem Check Ensure that the grill pan is positioned centrally below Grilling Uneven cooking front to back the grill element. Fat splattering Ensure that the grill is not set to too high a setting. Ensure that the oven shelves are level by using a spirit level on the rod shelf and adjusting the wheels/feet.
Page 27: Guarantee Information
90 days of ownership. Simply call our Hotpoint Service Hotline on 08448 224 224 (ROI 0818 313 413) for telephone PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24...
Page 28: Service Information
04/2014 - 195122065.01 XEROX FABRIANO After Sales Service No one is better placed to care for your Hotpoint appliance during the course of its working life than us - the manufacturer. Essential Contact Information Hotpoint Service We are the largest service team in the country offering you access to 400 skilled telephone advisors and 1100 fully qualified engineers on call to ensure you receive fast, reliable, local service.
