6. Turn off dome light or remove dome light fuse to prevent battery drain. This device complies with Part 15 of the FCC rules. Any changes or modifications made to the system without the express approval of Avital Technologies, Inc. could void the user’s authority to operate this equipment.
4. Sleeve these wires with vinyl tubing or electrical tape and route them through an existing rubber grommet into the engine compartment. 5. If an existing grommet is not available, drill a hole and install a snap grommet. AviStart 3000 Installation Manual...
NOTE: Do not connect the RED/WHITE wire to the control unit RED wire. 2. If the parking lights are negative (-) trigger, connect the RED/WHITE wire to control unit BLACK wire. 3. Connect the RED/BLACK wire to the vehicle parking light wire. AviStart 3000 Installation Manual...
NOTE: Because these wires can draw high current, we recommend that they be soldered and shrink tubed or taped. If only one 14 ga PINK wire is needed, tape the end of the second 14 ga PINK wire to prevent a short circuit. AviStart 3000 Installation Manual...
Page 10
1. Use a voltmeter to find the wire that shows +12 volts while the ignition key is in the "CRANK" position only and 0 volts while the key is in the "OFF," "ON" and "RUN" positions. 2. Connect the VIOLET wire to the starter wire. AviStart 3000 Installation Manual...
Currently, the only vehicles with the combined neutral safety switch that Avital is aware of are General Motors trucks, GM sport utility vehicles, GM column shift passenger cars and Dodge Dakota pickup trucks. There may be additional vehicles with the combined neutral safety switch that require the additional relay.
Page 12
The wire color codes are subject to change. Check all wires with a volt/ohmmeter. If you have any questions, please contact the Avital Technical Support Department. AviStart 3000 Installation Manual...
Page 13
Gen eral Mo tors Sport Util ity Ve hi cles, Trucks and Col umn Shift Pas sen ger Ve hi cles Dodge Da kota Pickup Trucks AviStart 3000 Installation Manual...
Some types of door lock sys tems re quire op tional re lays, for ex am ple, re verse po lar ity type door locks. Refer to the diagrams on pages 12 - 14. Posi tive Trig ger Door Locks AviStart 3000 Installation Manual...
On most vehicles, the tach wire is easily accessible. If the tach wire is not accessible, there are several alternative choices. Contact Avital Technical Support Department for alternate choices. The following procedure for testing the vehicle tach wire is not exact and may vary with different vehicle make, model and year.
NOTE: Stop on the 8th beep. See the "Programming Table for System Features" on page 18. 5. Press and hold the remote START button. 6. The parking lights will flash two times to confirm the RPMs have been memorized. 7. Release the START button. AviStart 3000 Installation Manual...
6. Follow the "Secondary Action." You will hear a number of beeps to confirm that you have changed the setting of that feature. 7. Turn the ignition key "OFF." 8. Repeat steps 1-7 for any other feature you wish to program. AviStart 3000 Installation Manual...
