011B
WELLS MANUFACTURING
265 Hobson Street, Smithville, Tennessee 37166
telephone: 314-678-6314
fax: 314-781-2714
www.wells-mfg.com
OWNER'S MANUAL
BUILT-IN
BOTTOM-MOUNT
AUTOFILL
WARMER
MODELS
BMW206ULRTD/AF
BMW206ULSTD/AF
Includes
INSTALLATION
USE & CARE
EXPLODED VIEW
PARTS LIST
WIRING DIAGRAM
BMW206ULRTD/AF
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
2M-308015 Rev. A
03/18
Advertisement
Table of Contents
Related Manuals for Wells BMW206ULRTD/AF
Summary of Contents for Wells BMW206ULRTD/AF
- Page 1 Additional manuals are available from your WELLS DEALER. THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any questions concerning installation, operation or maintenance of this equipment.
- Page 2 Wells’ discretion have the parts replaced or codes, including incorrect gas or electrical connection. Wells is not liable repaired by Wells or a Wells-authorized service agency.
-
Page 3: Table Of Contents
PARTS & SERVICE CUSTOMER SERVICE DATA INTRODUCTION Thank You for purchasing this Wells Bloomfield appliance. Proper installation, professional operation and consistent maintenance of this appliance will ensure that it gives you the very best performance and a long, economical service life. -
Page 4: Features & Operating Controls
See the Installation Instructions, supplied with the particular SENSOR appliance, for details. C. DRAINS Suffix “D” units (e.g. BMW206ULRTD/AF) have drains for each pan, with each pan having an individual drain valve. D. AUTOFILL IL2468 On AUTOFILL BMW units, water level is automatically fed into the pan whenever the thermostat is ON . -
Page 5: Precautions & General Information
Do not operate this appliance if the control panel is damaged. Call read and followed. Damage your Authorized Wells Service Agent for service. to the appliance may result The technical content of this manual, including any wiring diagrams,... -
Page 6: Installation
Verify style of unit (e.g square-corner, radiused- specific instructions. corner) before making cutout. Wells Bloomfield does not NOTE: Cutout dimensions are different for square-corner and recommend bottom-mounted radiused-corner units. Verify the dimensions are correct for the installation before making the cutout. - Page 7 INSTALLATION ELECTRICAL INSTALLATION NOTE: Damage caused by leaks due to improper Refer to the product nameplate. Verify the electrical service installation is NOT covered by power. Voltage and phase must match the nameplate warranty. specifications. Wiring the warmer to the wrong voltage can severely damage the unit or cause noticeably decreased performance.
-
Page 8: Operation
OPERATION AUTOFILL WARMERS CAUTION: Autofill warmers sense water level by a sensor placed at the HOT SURFACE proper level. For manifolded autofill warmers, the water level Exposed surfaces can be hot sensor / fill tube is in one pan only, normally in the far left pan. to the touch and may cause Water fills the pan through an inlet tube. -
Page 9: Maintenance Instructions
Never use metal implements, wire brushes, abrasive scratch pads or steel wool to clean stainless steel. Warmer pans, insets and other vessels are subject to a harsher environment. Wells Manufacturing uses an very high quality stainless steel (#304DDQ) for our food warmer pans. -
Page 10: Cleaning Instructions
Contact your Authorized Wells Service Agency to inspect warmer if water or grease contamination is suspected. Close drain valve. Add proper amount of warm water. Turn control... - Page 11 CLEANING INSTRUCTIONS WEEkLY CLEANING INSTRUCTIONS CAUTION: CHEMICAL BURN PREPARATIONS: Remove any insets, pans and/or adapter tops. HAzARD Drain or remove water from well if used for Deilimng chemicals may be wet operation. caustic. Wear appropriate FREQUENCY: Weekly, or whenever lime or scale is seen personal protective equipment.
-
Page 12: Troubleshooting Suggestions
One or more pans of an auto-fill unit Blocked drain manifold Clean drain manifold do not fill There are no user-serviceable components in this appliance. In all instances of damage or malfunction, contact your Authorized Wells Service Agency for repairs. -
Page 13: Exploded View & Parts List
(incl. D8-303352) 2V-47650 2K-47662 2K-34136X 2K-31040 2C-46591 P2-306960 THERMOBULB P2-40843 (ref.) 2T-45917 P2-48181 D8-303352 WS-50131 2C-41974 2I-Z12311 2J-35687 2I-Z12311 2I-40034 2K-34136X 2E-46604 (120V) 2E-306865(208/240V) 2R-40498 WELLS (make from) 2C-46591 WS-83439(120V) WS-504939 (208/240V) P2-46587 P2-46143 IL2471-011B, Rev. A, 9/20/12 Model: BMW206RTDU/AFU, STD/AF... -
Page 14: Wiring Diagram
WIRING DIAGRAM... -
Page 15: Parts & Service
For factory authorized service, or to order factory authorized 4 QT. ROUND INSET w/ lid WS-20774 replacement parts, contact your Wells authorized service 7 QT. ROUND INSET w/ lid WS-20587 agency, or call: 11 QT. ROUND INSET w/ lid WS-20908... - Page 16 WELLS MANUFACTURING 265 Hobson Street, Smithville, Tennessee 37166 telephone: 314-678-6314 fax: 314-781-2714 www.wells-mfg.com...
