Cub Cadet LT1040 LE Operator's Manual

Cvt lawn tractor series 1000
Hide thumbs
Table of Contents

Advertisement

Quick Links

Operator's Manual
S
ERIES 1000
CVT Lawn Tractor
Model LT1040 LE
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
Warning:
This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered,
brush-covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or state laws
(if any). If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is
required by law (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands.
A spark arrester for the muffler is available through your Cub Cadet dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio
44136-0019.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
PRINTED IN U.S.A.
FORM NO. 769-02404.fm
(3/10/2006)

Advertisement

Table of Contents
loading

Related Manuals for Cub Cadet LT1040 LE

Summary of Contents for Cub Cadet LT1040 LE

  • Page 1 (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your Cub Cadet dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-0019.

  • Page 2: Table Of Contents

    A sample model plate is also illustrated below. You can locate the model plate by looking at the underside of the tractor‘s seat. This information will be necessary to use the manufacturer’s web site and/or help from your Cub Cadet dealer. Copy the model number here:...

  • Page 3: Important Safe Operation Practices

    SECTION 1: IMPORTANT SAFE OPERATION PRACTICES WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury.
  • Page 4 6. Do not shift to neutral and coast downhill. Over- manual, use care and good judgment. Contact your speeding may cause the operator to lose control of Cub Cadet dealer for assistance. the machine resulting in serious injury or death. 7. Do not tow heavy pull behind attachments (e.g.
  • Page 5 Gasoline is frame, your unit should be serviced professionally extremely flammable and the vapors are explosive. by your Cub Cadet dealer. Serious personal injury can occur when gasoline is 4. Check brake operation frequently as it is subjected spilled on yourself or your clothes which can ignite.
  • Page 6 8. Never tamper with the safety interlock system or other For safety protection, frequently check components and safety devices. Check their proper operation regularly. replace immediately with original equipment 9. After striking a foreign object, stop the engine, manufacturer’s (O.E.M.) parts only, listed in this disconnect the spark plug wire(s) and ground against manual.

  • Page 7: Slope Gauge

    SECTION 2: SLOPE GAUGE...

  • Page 8: Tractor Set-Up

    SECTION 3: TRACTOR SET-UP Gas and Oil Fill-up Shipping Brace Removal The gasoline tank is located under the fender and has a WARNING: Make sure the riding mower’s capacity of three gallons. Unthread the fuel cap by engine is off, set the parking brake and turning it counterclockwise.

  • Page 9: Know Your Lawn Tractor

    SECTION 4: KNOW YOUR LAWN TRACTOR NOTE: Steering Wheel not shown for clarity. Figure 2 A Systems Indicator Monitor/Hour Meter H Ignition Switch Module B Throttle Control Lever I PTO (Blade Engage) Knob C Choke Control J Brake Pedal D Parking Brake Lever K Drive Pedal E Shift Lever L Cruise Control Lever...
  • Page 10 Throttle Control Lever Ignition Switch Module The throttle control lever is Fast WARNING: Never leave a running machine located on the left side of the Position unattended. Always disengage PTO, move tractor’s dash panel. This lever shift lever into neutral position, set parking controls the speed of the engine.
  • Page 11 Refer to the MAINTENANCE section of this manual for the Always set the parking brake when IMPORTANT: proper battery charging procedure or have the charging leaving the tractor unattended. system checked by your Cub Cadet dealer.

  • Page 12: Operating Your Lawn Tractor

    See Figure 4. should ever malfunction, do not operate the tractor. 4. Once activated (indicator light ON), the tractor can Contact an authorized Cub Cadet service dealer. be driven in reverse with the cutting blades (PTO) • The safety interlock system prevents the engine engaged.
  • Page 13 Setting the Gauge Wheels • If the gauge wheels have excessive clearance with the surface below, lower the wheels to the index Select the height position of the cutting deck by placing hole that provides the approximate 1/2" clearance the deck lift lever in any of the six different cutting height as described above.
  • Page 14 Engaging the Parking Brake Driving On Slopes Refer to the SLOPE GAUGE on page 7 to help determine To engage the parking brake: slopes where you may operate the tractor safely. • Fully depress the brake pedal and hold it while gently pushing the parking brake lever downward.
  • Page 15 Stop machine if anyone enters the area. Operating the Headlights This tractor is equipped with one of Cub Cadet’s quality The lamps are ON whenever the ignition key is moved cutting decks. The following information will be helpful out of the STOP position.
  • Page 16 To operate the cutting deck without mulching, simply remove the Cub Cadet Series 1000 tractors are equipped with a mulch plug by unthreading the plastic wing nut which mulch kit which incorporates special blades, already fastens it to the cutting deck.

  • Page 17: Making Adjustments

    SECTION 6: MAKING ADJUSTMENTS WARNING: • Retighten the outer lock nut against the inner hex Never attempt to make any nut when proper adjustment is achieved. adjustments while the engine is running, except where specified in the operator’s Side to Side manual.
  • Page 18 Parking Brake Adjustment Steering Adjustment If the tractor turns tighter in one direction than the other, WARNING: Never attempt to adjust the or if the ball joints are being replaced due to damage or brakes while the engine is running. Always wear, the steering drag links may need to be adjusted.

  • Page 19: Maintaining Your Lawn Tractor

    Warranty repairs Air Cleaner must be performed by your Cub Cadet Dealer. Service the pre-cleaner and cartridge/air cleaner Changing Engine Oil element as instructed in the Kohler Owner’s Manual •...
  • Page 20 Lubrication 3. Thread the hose coupler (packaged with your tractor’s Operator’s Manual) onto the end of your garden hose. WARNING: Before lubricating, repairing, or 4. Attach the hose coupler to the water port on your inspecting, always disengage PTO, set deck’s surface.

  • Page 21: Service

    SECTION 8: SERVICE Tires • Remove the deck from beneath the tractor (refer to Cutting Deck Removal on page 22), then gently flip the deck over to expose its underside. WARNING: Never exceed the maximum • Place a block of wood between the center deck inflation pressure shown on the sidewall of the housing baffle and the cutting blade to act as a tire.
  • Page 22 Battery When charging your tractor’s battery, use IMPORTANT: only a charger designed for 12V lead–acid batteries. The battery is sealed and is maintenance-free. Acid Read your battery charger’s Owner’s Manual prior to levels cannot be checked and fluid can not be added. charging your tractor’s battery.
  • Page 23 See your • Remove the belt covers by removing the screws Cub Cadet dealer to have your drive belt replaced. that fasten them to the deck. Refer to the figure Changing the Deck Belt below.

  • Page 24: Off-Season Storage

    SECTION 9: OFF-SEASON STORAGE Clean and lubricate the tractor as instructed in Section 7: To empty the system, run the engine until the tank MAINTAINING YOUR LAWN TRACTOR on page 19 of this and system are empty. manual before storing for an extended period. Refer to WARNING: Drain fuel only into an Storage in the Kohler Owner’s Manual packed with...

  • Page 25: Maintenance Log

    SECTION 11: MAINTENANCE LOG Please keep a record of the maintenance performed on your tractor. Date Hour Meter Maintenance Performed by...

  • Page 26: Troubleshooting

    SECTION 12: TROUBLESHOOTING Trouble Possible Cause(s) Corrective Action Engine fails to start PTO/Blade Engage knob engaged. Place knob in disengaged (OFF) position. Parking brake not engaged. Engage parking brake. Spark plug wire(s) disconnected. Connect wire to spark plug. Throttle control lever not in correct Place throttle lever to FAST position.

  • Page 27: Attachments & Accessories

    SECTION 13: ATTACHMENTS & ACCESSORIES The following attachments and accessories are compatible for Series 1000 Lawn Tractors. See your Cub Cadet dealer or the retailer from which you purchased your tractor for information regarding price and availability. NOTE: Cub Cadet Series 1000 lawn tractors are NOT designed for use with any type of ground-engaging attachments (e.g.

  • Page 28: Replacement Parts

    SECTION 14: REPLACEMENT PARTS LT1040 LE Champion Spark Plug RC12YC Kohler Air Filter (Paper Element) 20-083-10-S Kohler Air Filter (Precleaner) 20-083-12-S Kohler Oil Filter 52-050-02-S Kohler Fuel Filter 25-050-07-S Drive Belt (Transmission, Upper) 754-0468 Drive Belt (Transmission, Lower) 754-0467 Drive Belt (Mowing Deck)

  • Page 29: Specifications

    498 lb. (225.9 kg) * Cub Cadet reserves the right to change product specifications, design, and standard equipment without notice and without incurring obligation ** Kohler’s horsepower ratings exceed Society of Automotive Engineers Small Engine Test Code J1940. Actual engine horsepower is lower and affected by, but not limited to, accessories (air cleaner, exhaust, charging, cooling, fuel pump, etc.), application, engine speed and ambient...

  • Page 30: Warranty Information

    CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS The California Air Resources Board and MTD Consumer Group Inc are pleased to explain the evaporative emission control system warranty on your 2006 lawn mower. In California, new lawn mower must be designed, built and equipped to meet the State’s stringent anti-smog standards. MTD Consumer Group Inc must warrant the EECS on your lawn mower for the period of time listed below provided there has been no abuse, neglect or improper maintenance of your lawn mower.
  • Page 31 KOHLER CO. FEDERAL AND CALIFORNIA EMISSION CONTROL SYSTEMS LIMITED WARRANTY UTILITY AND LAWN AND GARDEN ENGINES The U.S. Environmental Protection Agency (EPA), the California Air Resources Board (CARB), and Kohler Co. are pleased to explain the Federal and California Emission Control Systems Warranty on your small off-road equipment engine. For California, engines produced in 1995 and later must be designed, built and equipped to meet the state’s stringent anti-smog standards.
  • Page 32 The limited warranty set forth below is given by Cub Cadet LLC with respect to normal deterioration of the exterior finish due to use or exposure. new merchandise purchased or leased and used in the b.
