  • Page 1 Internet Camera ICA-100PE User’s Manual Version 1.1...
  • Page 2 PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims liability for any inaccuracies or omissions that may have occurred.
  • Page 3 PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User’s Manual. PLANET makes no commitment to update or keep current the information in this User’s Manual, and reserves the right to make improvements to this User’s Manual and/or to the products described in this User’s Manual, at any time without notice.

  • Page 4: Table Of Contents

    ABLE OF ONTENTS ABOUT THIS GUIDE ..........5 CHAPTER 1 INTRODUCTION........6 ..........7 EATURES AND ENEFITS ..........9 NPACKING THE ACKAGE ..........10 YSTEM EQUIREMENT ..........11 HYSICAL ESCRIPTION CHAPTER 2 HARDWARE INSTALLATION ..15 ......15 TTACHING THE AMERA TO THE TAND ......16 ONNECTING THE THERNET CABLE ........16 TTACHING THE OWER...
  • Page 5 ............50 SING ..........55 ONFIGURING THE YSTEM CHAPTER 7 APPENDIX ..........69 ......69 REQUENTLY SKED UESTIONS B PING Y IP A ...........72 DDRESS ..........73 ROUBLE HOOTING .............77 ABLE .......79 PLUG ONTROL NSTALLATION ......83 DJUST NTERNET AMERA OCUS ............84 PECIFICATION ..........86 LOSSARY OF ERMS...

  • Page 6: About This Guide

    BOUT UIDE This manual provides instructions and illustrations on how to use your ICA-100PE Internet Camera, includes: Chapter 1, Introduction, provides the general information on the camera. Chapter 2, Hardware Installation, describes the hardware installation procedure for the camera. Chapter 3, Security, explains the security feature of the camera.

  • Page 7: Chapter 1 Introduction

    Chapter 1 INTRODUCTION Thank you for purchasing the ICA-100PE Internet Camera, a camera device that can be connected directly to an Ethernet or Fast Ethernet network. Compared to the conventional PC Camera, the Internet Camera features a built-in CPU and web-based solutions that can provide a cost-effective solution to transmit real-time high-quality video images and sounds for monitoring.

  • Page 8: Features And Benefits

    Small Office/Home Office (SOHO) environments. Support Variety of Platforms The ICA-100PE supports TCP/IP networking, SMTP e-mail, HTTP and other Internet related protocols, and can be utilized in a mixed operating system environment such as Windows, Unix, and Mac.
  • Page 9 Web Configuration Applying a standard web browser, the administrator can configure and manage the Internet Camera directly from its own web page via the Intranet or Internet. Up to 64 users name and password are permitted with privilege setting controlled by the administrator.

  • Page 10: Unpacking The Package

    Unpacking the Package Unpack the package and check all the items carefully. In addition to this User’s Guide, be certain that you have: PLANET PoE Internet Camera x 1 Installation CD-ROM x 1 Quick Installation Guide x 1 Camera Stand x 1...

  • Page 11: System Requirement

    System Requirement Networking 10Base-T Ethernet or 100Base-TX Fast Ethernet. Accessing the Camera For Web Browser Users Operating System: Microsoft® Windows® 98SE/ME/ 2000/XP CPU: Intel Pentium II, 266 MHz or above Memory Size: 32MB (64MB recommended) Resolution: 800x600 or above Microsoft® Internet Explorer 5.0 or above (ActiveX & JAVA Mode –...

  • Page 12: Physical Description

    Physical Description This section describes the externally visible features of the Internet Camera. Front Panel 1. Power LED 2. Link LED 1. Power LED The Power LED is positioned on the right side of the Internet Camera’s lens while facing the Internet Camera. A steady BLUE light confirms that the Internet Camera is...
  • Page 13 A steady ORANGE light confirms that the camera has good connection to LAN connectivity. Dependent on the data traffic the LED will begin to flash to indicate that the Internet Camera is receiving/sending data from/to the network. Rear Panel 2. Reset Button 1.
  • Page 14 Please choose either PoE or power adapter as the power supply for the ICA-100PE. Do not connect both the PoE port, and the power adapter at the same time, the unit might be damaged permanently.
  • Page 15 Top Panel Top Panel Screw Hole Screw Hole Located on the top/bottom panel of the camera, the screw hole is used to connect the camera stand onto the camera by attaching the screw head on the camera stand into the screw hole of the camera.

  • Page 16: Chapter 2 Hardware Installation

    Chapter 2 HARDWARE INSTALLATION Attaching the Camera to the Stand The Internet Camera comes with a camera stand (optional) with a swivel ball screw head that can be attached to the Internet Camera's bottom screw hole. Attach the camera stand to the Internet Camera and station it for your application.

  • Page 17: Connecting The Ethernet Cable

    Connecting the Ethernet cable Connect an Ethernet cable to the network cable connector located Internet Camera’s rear panel, and then attach it to the network. Attaching the Power Supply Attach the external power supply to the DC power input connector located on Internet Camera’s rear panel, and then connect it to your local power supply.

  • Page 18: Chapter 3 Security

    Chapter 3 SECURITY To ensure the highest security and prevent unauthorized usage of the Internet Camera the Administrator has the exclusive privilege to access the System Administration for settings and control requirements to allow users the level of entry and authorize the privileges for all users.

  • Page 19: Chapter 4 Application Of The Camera

    Chapter 4 APPLICATION OF THE CAMERA The Internet Camera can be applied in wide variety of applications. With the built-in CPU, it can work as a standalone system that provides a web-based solution transmitting high quality video images and sounds for monitoring purposes. It can be managed remotely, accessed and controlled from any PC desktop over the Intranet or Internet via a web browser.

  • Page 20: Applications

    Applications Monitoring of local and remote places and objects such as construction sites, hospitals, amusement parks, schools and day-care centers through the use of a web browser. Capture multiple frame images from the IPView pro application. Configure the camera to upload image or send-mail messages with a single frame image.

  • Page 21: Application Diagrams Of The Camera

    Application Diagrams of the Camera Home Applications...
  • Page 22 Office Applications...

  • Page 23: Chapter 5 Using The Camera

    Chapter 5 USING THE CAMERA You can access and manage the Internet Camera through: 1) a web browser, and 2) the enclosed software IPView Pro. This chapter describes the Web Configuration Utility, and provides the instructions on using the camera with a web browser. Web Configuration The Internet Camera must be configured through its built-in Web- based Configuration.
  • Page 24 Default IP address Pre-view area Welcome Screen of the Configuration Utility After the default IP address is entered from the browser, the Internet Camera Welcome screen will appear with a still image. There will be three options to choose from to set-up and view your Internet Camera, including: View Video –...

  • Page 25: System Administration

    System Administration Under the Welcome screen of the Configuration Utility, click System Administration to enter the administration window that contains the settings required for the camera in the top menu bar, including Management, Configuration, Tools, Help, and Home. TIP: Once you have changed the settings in each option, click Save to store the settings, or Cancel to abandon, or Refresh to reload the status.
  • Page 26 System Click the System item in the left column to display the device status of your camera. - Device Status: The information about the camera, including the Camera Name, Location, Model, Firmware Version, MAC Address and IP Address, can be found in this field.
  • Page 27 Frame Rate, Frame Size and IP Address, can be found in this field. Network Click the Network item in the left column to display the information of the LAN. - Network Status: The items in this field display the information of the LAN, such as the IP Address, Subnet Mask, Default Gateway, Primary DNS Address, Secondary DNS Address, Dynamic DNS, Secondary HTTP Port, and UPnP.
  • Page 28 System Administration Configuration The Configuration window contains commands for settings that are required to input key details to setup the camera for operation. Click Configuration in the top menu bar and the Configuration window will appear as below: System Click the System item in the left column to setup the basic configuration of your camera.
  • Page 29 • Camera Name: This field is used to enter a descriptive name for the device. The default setting for the Camera Name is PL-xxxxxx, where xxxxxx the last six digit of the MAC Address. The maximum length is 32 (printable ASCII). •...
  • Page 30 The default setting for the LED control is at Normal. When you have configured the LED control, the correct illumination will be set after 1 minute. Video Click the Video item in the left column to setup the image configuration of your camera. - Video Setting: In this field, you can configure the basic information of your camera.
  • Page 31 • Saturation Control: Adjust the saturation with default setting at 64. • Light Frequency: Adjust the light frequency to suit your area of operation from the options either 50 Hz or 60 Hz (default). Network Click the Network item in the left column to setup the LAN configuration of your camera.
  • Page 32 • IP Address – 192.168.0.20 • Subnet Mask – 255.255.255.0 • Default Gateway – 0.0.0.0 Dynamic Address (DHCP) – If your network uses the DHCP server, select this option. According to this setting, the camera will be assigned an IP address from the DHCP server automatically.
  • Page 33 PCs of all form factors. Check the Enable option to enable the function of your camera. User Click the User item in the left column to add, edit and delete users for your camera. - User Access Control: • Access Control: The administrator has the authority to give permission for the privilege to control the device to users by selecting Enable or Disable.
  • Page 34 • Delete User: Select the user you want to delete from the pull-down menu, and then click the Delete button. • User List: This list displays the current users status of your camera. DateTime Click the DateTime item in the left column to setup time and date for your camera, providing correct information for the remote users who might be thousands of miles away from the camera’s location.
  • Page 35 TimeZone – Select the time zone for the region from the pull-down menu. • Set Manually: Select this option to set the time manually. The system administrator must enter the date and time in the respective field manually. Upload Click the Upload item in the left column to setup configuration for FTP server, time schedule and manual operation.
  • Page 36 • Port Number: The standard port number for the FTP server is Port 21, and it’s also the default setting. If the FTP server uses a specific port, please confirm the IT manager. • User Name: Enter the user name in this field. •...
  • Page 37 the image. The setting refers to Base File Name and File information above. E-mail Click the E-mail item in the left column to setup configuration for E-mail account, time schedule and manual operation settings. - E-mail Account: This field contains the following six basic settings for your FTP server.
  • Page 38 • Receiver e-mail Address: Enter the e-mail address of the user who will receive the e-mail. • User Name: Enter the user name in this field. • Password: Enter the user password in this field to login receiver’s mail server. - Time Schedule: Select the “Enable-mail video to e-mail account”...
  • Page 39 System Administration Tools The Tools window contains commands for restarting the camera. Click Tools in the top menu bar and the Tools window will appear as below: E-mail Test Click the E-mail Test item in the left column to test your e-mail account.
  • Page 40 Reset Do you really want to reset this device? Click the YES button from this option, and you can restart the camera just like turning the device off and on and saved settings are retained. If you do not want to reset the camera, exit this window without clicking YES.
  • Page 41 Backup Click the Backup item in the left column to backup the current configuration. - Backup Device Configuration to File: Do you really want to backup the configuration to file? Click the Backup button from this option, and you can save the current configuration to file.
  • Page 42 System Administration Help The Help window provides the basic information of the camera. Click Help in the top menu bar and the Help window will appear as below: About Displays the camera’s model name and version.
  • Page 43 Once the configuration is completed, click Home to return to the Welcome screen and select the desired View Video option either through ActiveX Mode or Java Mode as described in the next section. Then, position the camera to the desired location appropriately for your purpose.

  • Page 44: View Video - Activex Mode

    View Video – ActiveX Mode To view video images from the browser, click View Image – ActiveX Mode from the Welcome screen to access the video images from Internet Explorer as illustrated below: Camera Name Date and Time Camera Name: The Camera name will be displayed when the Camera Name field is entered in the Web Configuration setting under Configuration.

  • Page 45: View Image - Java Mode

    desired selection ON or OFF to utilize the options for each of the functions. View Image – Java Mode To view video images from the browser, click View Image – Java Mode from the Welcome screen to access the video images from Internet Explorer or Netscape browser as illustrated below: Camera Name Date and Time...
  • Page 46 Date and Time: The date/time of the camera will be displayed here. In the View Video – Java Mode, you are allowed to use the Upload Video and E-mail Video options. Simply click the desired selection ON or OFF to utilize the options for each of the functions.

  • Page 47: Chapter 6 Ipview Pro

    This chapter describes the IPView Pro, which is a powerful software application designed with a user-friendly interface for ease of control and navigation requirements. Getting Started To launch IPView Pro, click Start > Programs > PLANET > IPView Pro > IPView Pro. The main screen will appear as below:...
  • Page 48 NOTE: IPView Pro requires the system’s resolution setting up to 1024x768. Please configure the resolution to 1024x768 or higher; otherwise, it may shows incomplete screen when launching the program. Item Feature Item Description Date/Time Show current date/time.
  • Page 49 Status Mode Show the camera’s status in this window. Window Click the Change Status Mode button ( ) on the right lower corner of the window to change the display mode: Camera list mode Camera information mode View Show the camera’s view in this window. Window View Mode Select the view mode from these buttons.
  • Page 50 Key Lock Click to lock/unlock the camera. When locked, Button the user cannot operate any camera. Power Button Click to exit or minimize IPView Pro. Record Record video clip of the selected camera and save Button it in the computer. The storage position can be configured in System Configuration.

  • Page 51: Using Ipview Pro

    Using IPView Pro Adding a Camera To add a camera: 1. Click the System Configure button to enter the System Configuration. If you are not sure of the camera’s IP address, you can click Search to search the available camera(s) within the network.
  • Page 52 2. Select the camera you want by highlighting it, and then click Add Camera. The camera is added. Click the Add Camera button. The camera found within the network. 3. Click Save, and then click the System Configure button to return to View Window.
  • Page 53 Alternately, you can add a camera by entering the its IP address directly: 4. Select the Input IP tab. The camera is added. Click the Add Camera button. Enter the camera’s IP address and Port. 5. Enter the camera’s IP address (default: 192.168.1.2) and Port (default: 80), and then click Add Camera.
  • Page 54 Removing a Camera To remove the camera from the list: camera elect the you want to remove. 2. Click Delete Camera. Viewing a Camera From the View Modes of the panel, you can select one-camera mode or other modes to display your video. IPView Pro allows a maximum of 16 cameras for viewing.
  • Page 55 Video Recording IPView Pro allows you to record the video clip and save it in your computer through the following methods: Manual Record, Schedule Record, and Motion Record. When you click the Record button and select Manual Record, it will start recording. Click the button again to stop. If you select Schedule Record or Motion Record, the system will record the video clip according to the settings in System Configuration.

  • Page 56: Ystem

    Configuring the System Clicking the System Configure button on the panel allows you to configure the system settings, and the System Configuration Screen will appear in the View Window as shown below. Once configured, click Save to save the settings, and then click the System Configure button again to exit configuration.
  • Page 57 Camera Configuration In this field, you can add/delete the camera (as described in the previous section). Also, you can configure the following settings: Web Configuration In the left column, selecting the Web Configuration item will launch the Web Configuration Utility in View Window. You can configure these settings according to the description in Chapter 5, Using the Camera.
  • Page 58 Motion Configuration-1 The Motion Configuration-1 item provides the commands for motion detection control. Before configuring, you should select one camera from the pull-down menu. Select one camera. Detect Region: When you select the Full picture option, the camera will monitor the whole area. Sensitivity Level: Move the slide bar to adjust the sensitivity level for detecting motion to record video.
  • Page 59 Motion Configuration-2 The Motion Configuration-2 item allows you to configure to the alarm and e-mail setting. Invoke Alarm: Select this option to enable alarm when some motion detected by the system. Send e-mail: When this option is checked, click the Mailing Configuration in the left column to enter the required information (see the following section).
  • Page 60 Tools The Tools item allows you to reset the camera to factory default setting or upgrade the firmware. Reset: Restore the original setting of your camera. Do you really want to reset this device? Click Yes in the pop-up dialog box to confirm. Factory Reset: Restore the factory default settings of the camera.
  • Page 61 Mailing Configuration When Motion Detection function is enabled and the Send e-mail option is checked, you should enter the required information in the respective fields. Mail Server: Enter the mail server address that is used to send your e-mail. Mail From/To: Enter the sender’s/receiver’s e-mail address. Subject: Enter the title of the e-mail.
  • Page 62 Proxy Server Check the Proxy Server option and enter the required settings in the Address and Port boxes to enable and use the Proxy Server function.
  • Page 63 Recording Configuration In this field, you can configure the storage settings. Log Storage: • Reserved HDD Space For MS-Windows OS – You can reserve 500 MB to 1000 MB hard disk space for the program. • Each Recording File Size – If the recorded video files reach the file size limit, video images will be recorded into another file automatically.
  • Page 64 • Storage List – The destination folder to save the recorded video file can be specified here. Click Modify to change the current path setting; click Add to add a new destination folder; click Delete to remove a selected path setting.
  • Page 65 Schedule-Recording Configuration This recording function will work after you have enabled respective settings in the Schedule mode. The recording schedule can be defined by Date Mode or Week Mode. Date Mode: First, select the camera desired from the pull- down menu. Then, setup the time in the Start/Stop fields. Click Add to add the recording schedule to the list.
  • Page 66 Week Mode: First, select the camera desired from the pull- down menu. Then, setup the time in the Start/Stop fields, and select the weekday from the buttons. Click Add to add the recording schedule to the list. Click Save to save the settings.
  • Page 67 Others When multiple cameras connected, this option allows the system to display these views as the main view in circles according to your time settings. The range of Time interval of scan is from 1 to 20 seconds.
  • Page 68 Log List This filed displays the user(s) information, which includes the Date, MAC address, and the brief description of events.
  • Page 69 About This filed provides information of the software application.

  • Page 70: Configuring Thes

    Chapter 7 APPENDIX A Frequently Asked Questions Internet Camera Features Q: What is an Internet Camera? A: The Internet Camera is a standalone system connecting directly to an Ethernet or Fast Ethernet network. It is different from the conventional PC camera, the Internet Camera is an all- in-one system with built-in CPU and web-based solutions providing a low cost solution that can transmit high quality video images for monitoring.
  • Page 71 A: The Internet Camera utilizes the JPEG image compression technology providing high quality images for users. JPEG is adopted since it is a standard for image compression and can be applied to various web browser and application software without the need to install extra software. Internet Camera Installation Q: Can the Internet Camera be used out-doors? A: The Internet Camera is not weatherproof.
  • Page 72 transmits image data, the default port 8481 is also required. Therefore, it is necessary to open port 8481 of the network for remote users to access the Internet Camera.
  • Page 73 B PING Your IP Address The PING (Packet Internet Groper) command can determine whether a specific IP address is accessible by sending a packet to the specific address and waiting for a reply. It can also provide a very useful tool to confirm if the IP address conflicts with the Internet Camera over the network.

  • Page 74: A Frequently Askedb Ping Your Ip Addressc Trouble Shooting

    C Trouble Shooting Q: I cannot access the Internet Camera from a web browser. A1: The possible cause might be the IP Address for the Internet Camera is already being used by another device. To correct the possible problem, you need to first disconnect the Internet Camera from the network.
  • Page 75 the product by connecting a local computer to the unit, utilizing a standard Crossover (hub to hub) Cable. If the problem is not solved the Internet Camera might be faulty. Q: Why does the Power LED not light up constantly? A: The power supply used might be at fault.
  • Page 76 Q: Why does a series of broad vertical white line appears through out the image? A: A likely issue is that the CMOS sensor becomes overloaded when the light source is too bright such as direct exposure to sunlight or halogen light. You need to reposition the Internet Camera into a more shaded area immediately as this will damage the CMOS sensor.
  • Page 77 the Internet Options menu. Alternatively, you can use the Java Applet for viewing the required images.

  • Page 78: D Time Zone Table

    D Time Zone Table...

  • Page 80: E Xplug Controli

    E Xplug Control Installation Installation To Web Server Important Information It is highly recommended to install the Xplug Control application to the Web Server for IE 5.0. It must be installed to a Public Domain with Fixed IP address. 1. Installation: Copy the “xplug.ocx”...
  • Page 81 Software Installation Insert the CD-ROM into the CD-ROM drive to initiate the auto- run program. Once completed, a menu screen will appear as below: To install Xplug Control, click the “Xplug Control" button to activate the installation procedure for the plug-in program. Once executed, a prompt will appear requesting the input of the desired language selection.
  • Page 82 The Welcome screen will appear. Click the “Next” button to proceed with the installation. The License Agreement prompt will appear as below. Read the details carefully and click the “Yes” button to continue with the installation procedure.
  • Page 83 Click the “Finish” button to complete Setup of the Xplug Control Utility program for the Internet Camera.

  • Page 84: F Adjust Internetc

    F Adjust Internet Camera Focus To adjust the focus of the lens, you need to turn the lens slowly in either clockwise or anti-clockwise direction until the desired image appears. DO NOT over turn the lens in either of the directions, as it will be out of focus.
  • Page 85 G Specification Video specification Resolution: 640 x 480 pixel Sensor: Color CMOS sensor Lens: f: 6.0 mm, F: 1.8 Gain control: Automatic Exposure: Automatic White Balance: Automatic Image (Video Setting) Image compression: JPEG Frame rate: 30fps @ QCIF, 25fps @ CIF, 10fps @ VGA Compression Rate selection: 5 levels: Very low/Low/...
  • Page 86 RTOS Power Supply: DC 5V Power over Ethernet: IEEE 802.3af Power consumption: 4.25 Watt (850mA x 5V) LED Indicator: Power LED (Blue) Activity LED (Orange) Software Browser: Internet Explorer 5.0 or above; Netscape 6.0 or above Application Software: IPView Pro OS supported: Microsoft Windows 98SE/ME/ 2000/XP, Windows NT4.0...
  • Page 87 H Glossary of Terms NUMBERS 10BASE-T 10BASE-T is Ethernet over UTP Category III,IV, or V unshielded twisted-pair media. 100BASE-TX two-pair twisted-media implementation 100BASE-T is called 100BASE-TX. Applet Applets are small Java programs that can be embedded in an HTML page. The rule at the moment is that an applet can only make an Internet connection to the computer form that the applet was sent.
  • Page 88 BOOTP Bootstrap Protocol is an Internet protocol that can automatically configure a network device in a diskless workstation to give its own IP address. Communication Communication has four components: sender, receiver, message, and medium. In networks, devices and application tasks and processes communicate messages to each other over media.
  • Page 89 of manually assigning it a unique IP address. DHCP allows the specification for the service provided by a router, gateway, or other network device that automatically assigns an IP address to any device that requests one Domain Name System is an Internet service that translates domain names into IP addresses.
  • Page 90 Fast Ethernet Fast Ethernet, also called 100BASE-T, operates at 10 or 100Mbps per second over UTP, STP, or fiber-optic media. Firewall Firewall is considered the first line of defense in protecting private information. For better security, data can be encrypted. A system designed to prevent unauthorized access to or from a private network.
  • Page 91 for humans to read hexadecimal numbers than binary numbers. IEEE Institute of Electrical and Electronic Engineers. Intranet This is a private network, inside an organization or company, that uses the same software you will find on the public Internet. The only difference is that an Intranet is used for internal usage only.
  • Page 92 packets across the Internet. For example 80.80.80.69 is an IP address, it is the closet thing the Internet has to telephone numbers. When you “call” that number, using any connection methods, you get connected to the computer that “owns” that IP address. Internet Service Provider, is a company that maintains a network that is linked to the Internet by way of a dedicated communication line.
  • Page 93 Network Address Translator generally applied by a router, that makes many different IP addresses on an internal network appear to the Internet as a single address. For routing messages properly within your network, each device requires a unique IP address. But the addresses may not be valid outside your network.
  • Page 94 connections. Point-to-Point Protocol over Ethernet. PPPoE is a PPPoE specification for connecting the users on an Ethernet to the Internet through a common broadband medium, such as DSL or cable modem. All the users over the Ethernet share a common connection. Communication on the network is governed by sets of Protocol rules called protocols.
  • Page 95 RARP Reverse Address Resolution Protocol, a TCP/IP protocol that allows a physical address, such as an Ethernet address, to be translated into an IP address. RJ-45 RJ-45 connector is used for Ethernet cable connections. Router A router is the network software or hardware entity charged with routing packets between networks.
  • Page 96 (TCP/IP) Transmission Control Protocol/Internet Protocol is a widely used transport protocol that connects diverse computers of various transmission methods. It was developed y the Department of Defense to connect different computer types and led to the development of the Internet. A transceiver joins two network segments together.
  • Page 97 Wide-Area Network. A wide-area network consists of groups of interconnected computers that are separated by a wide distance and communicate with each other via common carrier telecommunication techniques. Windows is a graphical user interface for workstations Windows that use DOS. Workgroup A workgroup is a group of users who are physically located together and connected to the same LAN, or a...
