- Page 1 IC-7001W Quick Installation Guide 10-2013 / v1.0...
-
Page 2: Table Of Contents
I. Product Information ................1 I-1. Package Contents ................1 I-2. Back Panel ..................1 I-3. LED Status ..................2 I-4. Product Label ................... 2 I-5. Reset ....................3 II. Hardware Installation ................4 III. Camera Setup ..................5 III-1. Installing & Using EdiView Finder ............. 5 III-2. -
Page 3: Product Information
Product Information I-1. Package Contents IC-7001W CD-ROM Power Adapter Ethernet Cable I-2. Back Panel Antenna WPS/Reset Button LAN Port Audio Output Power Port... -
Page 4: Led Status
I-3. LED Status LED Color LED Status Description Network camera is starting Quick Flashing up/restarting. Orange Slow Flashing WPS is active. (1 x per second) Connected to network and cloud. Green Slow Flashing Connected to network but not cloud. (1 x per second) No connection. -
Page 5: Reset
I-5. Reset If you experience problems with your network camera, you can reset the camera back to its factory default settings. This resets all settings back to default. Press and hold the WPS button found on the back panel for at least 10 seconds Release the button when the orange LED is flashing quickly. -
Page 6: Hardware Installation
II. Hardware Installation Follow the instructions below to ensure your camera is properly connected and ready for setup. Use an Ethernet cable to connect the network camera’s LAN port to a router/switch/access point’s LAN port, as shown below. Connect the power adapter to the network camera’s power port and to a power supply, as shown below. -
Page 7: Camera Setup
III. Camera Setup Your network camera can be up and running in just a few minutes. First, please follow the instructions below in III-1. Installing & Using EdiView Finder to install the included EdiView finder software and connect your camera to your wireless network. - Page 8 Click “Next” and follow the on-screen instructions to install the EdiView Finder software utility. When installation is complete, select “Launch EdiView Finder Utility” before clicking “Finish”. Or double click the ”EdiView Finder Utility” icon on your desktop to launch EdiView Finder. EdiView Finder will list all cameras on your local network, along with each camera’s name, model, IP address and MAC address.
- Page 9 Double click your camera and then choose “Yes” or “No” if you wish to set up a wireless connection. If you choose “No” please go to step 10. The IC-7001W is a wireless camera, please choose “Yes” to set up your wireless connection.
- Page 10 Select your wireless network from the list and enter the correct password in the “Password” field, before clicking “OK”. This is the wireless network which your camera will connect to. Unplug the Ethernet cable from your network camera and click “Next”. Please wait a moment for the camera to detect the connection.
- Page 11 Enter a name and password for your camera. The password will be used later to log in to your camera remotely via its cloud ID, web interface or via the EdiView smartphone app. Click “OK” to continue. The next screen will indicate that setup is complete. The camera is operational and ready for use.
-
Page 12: Iii-2. Wps (Wi-Fi Protected Setup)
III-2. WPS (Wi-Fi Protected Setup) The WPS button is a quick and easy method to establish a secure wireless connection between your network camera and your wireless router/access point. Press and hold the WPS button on your wireless router/access point for the correct length of time to activate its WPS. -
Page 13: Iii-3. Web-Based Management Interface
III-3. Web-Based Management Interface When you are using the same local network as your camera, you can use the web-based management interface to view or configure the camera. If you are not on the same local network as your network camera (e.g. - Page 14 You may be prompted to allow a Java add-on to run. Please click the message where it says “click here” and then click “Run Add-on”. If any other security warnings/prompts appear, please select “Run” or “Allow” or similar, depending on your browser. Enter the username and password for your network camera (default username: admin default password: 1234).
-
Page 15: Iii-4. Myedimax.com
III-4. Myedimax.com You can use your network camera’s Myedimax.com cloud ID to monitor your camera remotely using a web browser from any Internet connection. The network camera’s green LED must display on for this function to work. Identify your network camera’s cloud ID. The cloud ID is displayed in EdiView Finder (see III-1.) and on the product label on the bottom of the network camera (see I-4.). - Page 16 You may be prompted to allow a Java add-on to run. Please click the message where it says “click here” and then click “Run Add-on”. If any other security warnings/prompts appear, please select “Run” or “Allow” or similar, depending on your browser. Enter your camera’s password (default password: 1234) and click “OK”...
-
Page 17: Iii-5. Ediview App
III-5. EdiView App You can use the free EdiView smartphone app to monitor your camera remotely using a smartphone from any Internet connection. The network camera’s green LED must display on for this function to work. Search the Apple app store or Google Play for “EdiView”. Download and install the EdiView app. - Page 18 Select your network camera, enter the password when prompted (default password is 1234) and tap “OK”. iOS:...
- Page 19 Android: Android users select the camera name and tap “Done”. iOS users tap “Live” from the menu across the bottom of the screen. Android:...
- Page 20 iOS: For more detailed guidance on using the EdiView app, please refer to the user manual.
- Page 21 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 22 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2006/95/EC, 2011/65/EC. Français: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2006/95/CE, 2011/65/CE. Čeština: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanoveními směrnic 2006/95/ES, 2011/65/ES.
- Page 23 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directive 2006/95/EC, and directive 2011/65/EC(RoHS) . Equipment: Wireless Day & Night Pan & Tilt Network Camera Model No.:...
- Page 24 Notice According to GNU General Public License Version 2 This product includes software that is subject to the GNU General Public License version 2. The program is free software and distributed without any warranty of the author. We offer, valid for at least three years, to give you, for a charge no more than the costs of physically performing source distribution, a complete machine-readable copy of the corresponding source code.
- Page 25 intact all the notices that refer to this License and to the absence of any warranty; and give any other recipients of the Program a copy of this License along with the Program. You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in exchange for a fee.
- Page 26 6. Each time you redistribute the Program (or any work based on the Program), the recipient automatically receives a license from the original licensor to copy, distribute or modify the Program subject to these terms and conditions. You may not impose any further restrictions on the recipients’...
