Wiring Diagram - Fedders AFPB24B1 Instruction Manual

Wiring Diagram

11 12
POWER SUPPLY TABLE
kW Phase No. of MBTUH Heat
230 Supply 208/230 Load
VAC Circuits Amps
0 1 1 - -
5* 1 1 12.6 / 17.1 20.9
10* 1 1 25.6 / 34.1 41.7
15* 1 1 or 2 38.4 / 51.2 62.5
20* 1 1 or 2 51.2 / 68.2 83.4
*kW does not include motor watts.
1
Ampacities and over current protection based on largest air handler motor load. Refer to specific name plate for exact ampacity and overcurrent protection size.
Minimum wire ampacity values are used for sizing field power conductors. Refer to the National Electrical Code (latest version), Article 310, for sizing conductors. When more than three current-carrying
conductors are in the same conduit, the conductor's ampacity MUST be derated. See Note 8 of Table 310 for ampacity adjustment factors.
1
Maximum size fuse or HACR-type circuit breaker for field wiring protection.
1
Wire size based on 75°C copper wire with no more than three current-carrying conductors in the same conduit. All wiring MUST conform to the National Electrical Code and all local codes.
SINGLE CIRCUIT SUPPLY
Min. Max. Wire Ground
1 1
1
Wire Fuse Size Size
Ampacity Size AWG MM AWG MM
2
5.0 15 14 2.1 14 2.1
30 30 10 5.3 10 5.3
57 60 6 13.3 10 5.3
83 90 4 21.2 8 8.4
6 13.3
109 110 2 33.6
Min. Wire Max. Fuse
1 1
Ampacity Size
2 Ckt1 Ckt2 Ckt3 Ckt1 Ckt2 Ckt3
– – – – – –
– – – – – –
– – – – – –
57 26 – 60 30 –
57 53 – 60 60 –
9
DUAL CIRCUIT SUPPLY
1
Wire Size Ground Size
1
Ckt1 Ckt2 Ckt3 Ckt1
AWG MM 2 AWG MM 2 AWG MM 2 AWG MM 2
– – – – – – – –
– – – – – – – –
– – – – – – – –
6 13.3 10 5.3 – – 10 5.3 10
6 13.3 6 13.3 – – 10 5.3 10
1
Ckt2 Ckt3
AWG MM 2 AWG MM 2
– – – –
– – – –
– – – –
5.3 – –
5.3 – –
