Land Pride PS25120 Operator's Manual

Land Pride PS25120 Operator's Manual

Primary seeder
Hide thumbs Also See for PS25120:

Advertisement

Quick Links

Download this manual
Primary Seeder
PS25120
30186
Table of Contents
Read the Operator's Manual entirely. When you
!
see this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Cover photo may show optional equipment
not supplied with standard unit.
© Copyright 2014
313-156M
Operator's Manual
Printed
4/03/14

Advertisement

loading

Related Manuals for Land Pride PS25120

Summary of Contents for Land Pride PS25120

  • Page 1 Table of Contents Primary Seeder PS25120 30186 313-156M Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! Cover photo may show optional equipment not supplied with standard unit.
  • Page 2 Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land Pride reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
  • Page 3 Land Pride products. Download the appropriate App on your Refer to Parts Manual QR smart phone, open the App, point your Locator on this page for phone on the QR code and take a picture. detailed instructions. 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 4 Allow only Allow implement to cool before Remove all tools and unused parts enough slack in the chain to working on it. from implement before operation. permit turning. Do not use safety chain for towing. PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 5 Inhaling smoke from any type of wheels, use wheel handling chemical fire is a serious health equipment adequate for the hazard. weight involved. Store or dispose of unused chemicals as specified by the chemical manufacturer. 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 6 Spray soapy water on the surface where the label is to all damaged or missing labels. Order new labels from your be placed. nearest Land Pride dealer. To find your nearest dealer, Peel backing from label. Press firmly onto the surface. visit our dealer locator at www.landpride.com.
  • Page 7 Table of Contents Important Safety Information 818-337C 12787 Excessive Speed Hazard 818-339C High Pressure Fluid 12787 Hazard 12787 818-340C Negative Tongue Weight Hazard 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 8 Table of Contents Important Safety Information 818-543C Guard Missing 30190 (Beneath Chain Guard) 818-336C 12789 Caution Cylinder lock 30186 818-338C Caution General Safety 838-111C 30190 Moving Parts PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 9 Table of Contents Introduction Introduction Land Pride welcomes you to the growing family of new Serial Number product owners. Model No. _____________Serial No. _______________ This Primary Seeder has been designed with care and For quick reference and prompt service, record model built by skilled workers using quality materials.
  • Page 10 Dealer Preparations Tractor Requirements Read and understand the Operator’s Manual. An Your PS25120 is designed for tractors in the Category 2 understanding of how this machine works will aid in the class. Horsepower rating of the tractor should not be less assembly and setup.
  • Page 11 (#8) in the very bottom hole when storing the stand for transporting and field use. 15225 Parking Stand Installation Figure 1-2 Acremeter Installation Refer to Figure 1-3: Screw acremeter (#1) fully onto the right-hand drive shaft. Hand tighten. 15257 Acremeter Installation Figure 1-3 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 12 (#19 & #20). Do not tighten. 12737 2. Attach straight fittings (#26) to 3/8" x 19'-10" long hydraulic hoses (#23) and tighten. Spring Hose Loop Assembly Figure 1-5 3. Tighten quick couplers (#27) to fittings (#26). PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 13 12. Position hose clamps (#28 & #29) as shown and 15258 fasten together with 5/16" carriage bolt (#30) and hex End Wheel Hydraulic Schematic flange nut (#31). Tighten nut to the correct torque. Figure 1-7 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 14 5/16"-18 x 3/4" GR5 cap screw (#2), 5/16" lock of "Hydraulic Lift Cylinders" on page 14. washer (#3), and 5/16" USS flat washer (#4). Tighten cap screw to the correct torque. 7. Repeat steps 1 to 7 for the right-hand side. PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 15 Accumulator Hydraulic Schematic 15. Position hose clamps (#15 & #14) as shown and Figure 1-10 fasten together with 5/16" carriage bolt (#16) and hex flange nut (#17). Tighten nut to the correct torque. 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 16 (#31). Tighten nut to the correct torque. 13. Secure cylinder hoses and accumulator hoses to the tongue using one of the plastic cable ties. 14. Verify all nuts have been tighten to the correct torque. PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 17 Bolt Sizes”. Figure 2-2 Check tire pressure Page 35 Inspect the feed cups and seed tubes for foreign Page 21 matter. Set speed change sprocket for drive type desired. Page 21 Set seed rate. Page 22 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 18 Adjust turnbuckle to level seeder by loosening jam nuts and turning the center section. Retighten jam nuts when 11652 level. Turnbuckle Adjustment (End Wheel Unit) Pull-Type with Front Wheel Units Figure 2-5 Use tongue hydraulic cylinder to level the seed box. PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 19 NOTE: Understand that having the cylinders become gradually out of time is different than having 12741 air trapped in the system from improper bleeding. Each condition is corrected differently. Cylinder Lock Figure 2-6 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 20 (E) with the box lid closed. 13279 Seed Level Indicator Figure 2-9 PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 21 Seeding should not be done in wet conditions as soil will stick to the rollers. 11. After seeding the first 50 feet, stop and check to see that the seeder is adjusted properly. 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 22 The PS25120 has a ground driven seed delivery system. The power to drive the seeder comes from the forward momentum of the tractor. As the tractor moves forward the ground driven front roller compactor transfers power, via chain driven sprockets, to the seed metering system.
  • Page 23 4. Reinstall drive chains and adjust drive idler to snug area to fall through to help eliminate plugging. up the chains. Tighten idler arm nut. 5. Replace chain guard. 12745 12746 High Range Low Range Speed Change Figure 3-2 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 24 -0- setting. Seed cup damage may occur. Gate Handle Rotated To This Position Fully Opens Gate To Clean Out Seed. Gate Handle (Shown In Highest Position) 11648 30183 Seed Rate Adjustment Seed Cup Settings Figure 3-4 Figure 3-3 PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 25 It may be necessary to make minor seeding rate adjustments to compensate if seeder has been accurately calibrated and is seeding more or less seed than desired. 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 26 High Range Low Range Kentucky Blue Grass (Pounds per 1000 Square Feet) High Range 10.0 10.5 Low Range IMPORTANT: Do Not operate seed rate adjustment lever at -0- cup setting. Seed cup damage may occur. PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 27 Wheatgrass - Western (Pounds per Acre) High Range Low Range Wheatgrass - Western (Pounds per 1000 Square Feet) High Range Low Range IMPORTANT: Do Not operate seed rate adjustment lever at -0- cup setting. Seed cup damage may occur. 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 28 Kentucky Blue Grass (Kilograms per 1000 Square Meters) High Range 11.3 14.0 16.9 20.0 23.2 26.5 29.9 33.3 36.6 39.8 43.0 45.9 48.7 51.2 IMPORTANT: Do Not operate seed rate adjustment lever at -0- cup setting. Seed cup damage may occur. PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 29 21.1 23.1 25.0 26.8 28.4 29.8 31.0 31.9 Low Range 10.0 11.0 11.9 12.8 13.6 14.3 14.9 15.3 IMPORTANT: Do Not operate seed rate adjustment lever at -0- cup setting. Seed cup damage may occur. 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 30 5. Repaint parts where paint is worn or scratched to 6. Replace any worn, damaged, or illegible safety labels by prevent rust. Ask your Land Pride dealer for aerosol obtaining new labels from your Land Pride Dealer. touch-up paint. Paint is also available in touch-up bottles with brush, quarts, and gallon sizes by adding 7.
  • Page 31 Type of Lubrication: Chain Lube Quantity = As required. Do not overlubricate. 12227 Hours Wheel Arm Pivot Shafts Type of Lubrication: Multi-Purpose 12753 Seasonally Wheel Bearings Type of Lubrication: Wheel Bearing Grease Quantity = Repack 12754 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 32 Allow seed cups to air dry completely before putting seeder back into service. Type of Lubrication: Graphite Powder 37010 Land Pride # 821-042C (1 lb. Container) Quantity = Mix as needed, 1 teaspoon of powdered graphite for every bushel of seed in the seed box. Hours...
  • Page 33 1 1/2" Sealed, greaseable Front Roller Mounting Tube 12 3/4" OD x 1/4" wall Rear Packer Rollers 52 ea. 11 3/8" notched, cast iron, each free floating Rear Packer Roller Bearings 1 1/4" sealed, greaseable 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 34 Table of Contents Section 5: Specifications 12743 3-Point & Pull-Type With Seeder Lowered To Ground 12966 Pull-Type with End Wheels 12967 Pull-Type with Front Wheels PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 35 Rear packer rollers are spring loaded for additional down pressure, and to stay in contact with the ground. #40 Roller chain All drives utilize #40 roller chain for smooth running. Vacuum sealed acremeter Vacuum sealed to keep dirt out. Acremeter to plan seed requirements. 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 36 Feed cup sprocket locked up or twisted Check for foreign matter lodged in feed cup sprocket seed cup drive shaft Rollers not turning freely Check for trash or mud build up on roller ends PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 37 1-1/2" - 12 1330 2970 2190 4820 3560 Torque tolerance + 0%, -15% of torquing values. Unless otherwise specified use torque values listed above. Tire Inflation Chart Tire Size 9.5L x 15" 8-Ply Rib Implement 4/03/14 PS25120 Primary Seeder 313-156M...
  • Page 38 Table of Contents Section 8: Torque & Tire Inflation Charts PS25120 Primary Seeder 313-156M 4/03/14...
  • Page 39 This Warranty is limited to the repair or replacement of any defective part by Land Pride and the installation by the dealer of any such replacement part, and does not cover common wear items. Land Pride reserves the right to inspect any equipment or parts which are claimed to have been defective in material or workmanship.
  • Page 40 Corporate Office: P.O. Box 5060 Salina, Kansas 67402-5060 USA www.landpride.com...
